Wacker Neuson BS500-4 Parts Manual

Taper
Parts Manual
A nameplate listing the Model Number, Item Number, Revision, and Serial Number is
attached to each unit. Please record the information found on this plate so it will be available
should the nameplate become lost or damaged. When ordering parts or requesting service
information, you will always be asked to specify the model, item number, revision number,
and serial number of the unit.
Ein Typenschild mit Typ, Artikelnummer, Version und Maschinen-Nummer ist an jedem
Gerät angebracht. Die Daten von diesem Schild bitte notieren, damit sie auch bei Verlust
oder Beschädigung des Schildes noch vorhanden sind. Der Typ, die Artikel-Nummer, die
Versions- Nummer und die Maschinen-Nummer sind bei der Ersatzteilbestellung oder
Nachfragen bezüglich Service-Informationen stets erforderlich.
Una placa de identificación con el modelo, número de referencia, nivel de revisión y número
de serie ha sido añadida en cada máquina. Favor de anotar los datos en la placa en caso
de que la placa de identificación sea destruida o perdida. En todos los pedidos para
repuestos necesita siempre el modelo, el número de referencia, el nivel de revisión y el
número de serie de la máquina en cuestión.
Une plaque signalétique mentionnant le modèle, le numéro de référence, le niveau de
revision et le numéro de série est fixée sur chaque machine. Veuillez noter les informations
relevées sur cette plaque de façon à ce qu’elles soient toujours disponibles si la plaque
signalétique venait à être perdue ou endommagée. Lorsq ue vous commandez des pièces
détachées ou vous sollicitez des informations après-vente, on vous demandera toujours de
préciser le modèle, le numéro de référence, le niveau de revision et le numéro de série de
la machine.
My machine’s numbers are / Die Nummern meines Gerätes sind /
Los números de mi máquina son / Les numéros de ma machine son :
BS 500-4
Nameplate
Typenschild
Plaque signalétique
Placa de Identificación
0009329 - 101
3
Part Numbers appearing in boldface type are recommended spare parts. This means that
these parts are subject to wear under normal operating conditions and may require periodic
service or replacement. It is recommended that these items be stocked to meet the
expected service requirements of this model. Actual stocking quantities of these and other
parts used in more extensive repairs will depend on the service practices of each customer.
Bei den in den Ersatzteillisten fettgedruckten Nummern handelt es sich um empfohlene
Ersatzteile. Dies bedeutet, daß diese Teile bei normalen Anwendungsbedingungen
natürlicher Abnutzung ausgesetzt sind und gelegentlich ersetzt oder überarbeitet werden
müssen. Es wird geraten, diese Teile auf Lager bereit zu haben, um für Service-Arbeiten an
diesem Gerät vorbereitet zu sein. Lagerbestände für diese und andere Teile, welche für
ausgiebigere Reparaturarbeiten benötigt werden, können je nach Service-Gewohnheiten
der einzelnen Kunden variieren.
Los números de partes en negritas en las Listas Ilustradas de Partes son los repuestos
recomendados, ésto quiere decir que estas partes se desgastarán bajo circunstancias de
funcionamiento normales y pueden requerir servicio periódico o su reemplazo. Se
recomienda que el cliente mantenga un abastecimiento adecuado de estas partes para
poder satisfacer la demanda requerida por el servicio a la máquina. La cantidad de
repuestos que el cliente necesitará para reparaciones dependerá de la póliza de servicio de
cada cliente.
Les numéros de pièces imprimés en caractères gras dans les Listes des Pièces Détachées
de ce manuel sont les pièces détachées recommandées par la Wacker. Cela veut dire que
ces pièces sont sujettes à usure dans des conditions de travail normales et peuvent
nécessiter de l’entretien ou leur remplacement. Nous recommandons que vous disposez
d’un stock de ces pièces pour pouvoir satisfaire la demande d’entretien de cette machine.
Le client doit decider lui-même de la quantité exacte de pièces de rechange qu’il disposera
dans ses stocks.
This machine may be covered by one or more of the following patents:
Dieses Gerät ist unter einem oder mehreren der folgenden Patente geschützt:
Puede ser que las patentes a continuación sean válidas para esta máquina:
Cette machine peut être protégée sous les brevets d’invention ci-dessous :
Part Numbers - Boldface / Patents
Fettgedruckte Artikelnummern / Patente
BS 500-4
Números de partes en negritas / Patentes
Numéros de pièce - en caractères gras / Brevets d’Invention
4
0009329 - 101
Governor Control
Regler
Regulador
Régulateur
8
Crankcase cpl.
Kurbelgehäuse kpl.
Cárter compl.
Carter compl.
12
Guide Cylinder cpl.
Führungszylinder kpl.
Cilindro de Guía compl.
Cylindre de Guidage compl.
14
Ramming Shoe Kit
Stampfeinsatz
Placa de Pisón
Sabot de Frappe
18
Engine Guarding
Motorschutzbleche
Blindajes del Motor
Protecteurs du Moteur
20
Labels
Aufkleber
Calcomanias
Autocollants
22
Roller Kit
Satz-Transportrolle
Juego de Rodillo de Transporte
Jeu de Rouleau de Transport
24
Engine-WM 90
WM 90 Motor
Motor WM 90
Moteur WM 90
27
Ignition
Zündung
Encendido
Allumage
28
Carburetor cpl.
Vergaser kpl.
Carburador compl.
Carburateur compl.
30
Starter
Starter
Arrancador
Démarreur
34
Governor
Regler
Regulador
Régulateur
36
Intake/Exhaust
Einlass/Auspuff
Admisión/Escape
Admission/Échappement
38
Crankshaft/Piston
Kurbelwelle/Kolben
Cigueñal/Pistón
Vilebrequin/Piston
42
BS 500-4
Table of Contents
Inhaltsverzeichnis
Indice
Table des matières
0009329 - 101
5
BS 500-4
Table of Contents
Inhaltsverzeichnis
Indice
Table des matières
0009329 - 101
7
Governor Control
Regler
BS 500-4
Regulador
Régulateur
8
0009329 - 101
Ref.
Pos.
Part No.
Artikel Nr.
Qty.
St.
Description
Beschreibung
Descripción
Description
Measurem./Abm.
Torque/Drehm.
Norm
Sealant
Schmierstoff
1 0155653 1
Silencing cover
Abdeckung
Tapa de protección
Couvercle pour amortissage des bruits
2 0111461 1
Air cleaner cover cpl.
Deckel-Luftfilter kpl.
Tapa-filtro del aire compl.
Couvercle-filtre à air compl.
7 0116744 2
Shockmount
Puffer
Amortiguador
Silentbloc
8 0114792 1
Air filter
Luftfilter
Filtro del aire
Filtre à air
9 0095294 1
Prefilter element
Vorfilterelement
Elemento del prefiltro
Elément du prénettoyeur
10 0096034 1
Plug (threaded)
Schraubverschluß
Tapón roscado
Bouchon
M20 x 1,5
47Nm/35ft.lbs
11 0102274 2
Shockmount
Puffer
Amortiguador
Silentbloc
13 0011543 4
Socket head screw
Zylinderschraube
Tornillo hueco
Vis à six-pans creux
M8 x 20
34Nm/25ft.lbs
DIN 912
S3
14 0012083 1
Ring seal
Dichtungsring
Anillo sellador
Rondelle à étancher
A20 x 24 DIN 7603
15 0011541 2
Socket head screw
Zylinderschraube
Tornillo hueco
Vis à six-pans creux
M8 x 30
23Nm/17ft.lbs
DIN 912
S3
16 0154423 1
Cable
Kabel
Cable
Câble
17 0012360 4
Hexagonal head cap screw
Sechskantschraube
Tornillo hexagonal
Boulon à tête hexagonale
M8 x 12
23Nm/17ft.lbs
DIN 933
S3
18 0110375 1
Fuel hose
Kraftstoffleitung
Manguera de combustible
Tuyau de carburant
3/16 x 12,38in
20 0011553 4
Socket head cap screw
Zylinderschraube
Tornillo cilíndrico
Vis à tête cylindrique
M6 x 16
17Nm/13ft.lbs
DIN 912
S3
21 0058381 6
Lock washer
Federring
Federring
Rondelle de ressort
6 DIN 6796
22 0011341 1
Hexagonal head cap screw
Sechskantschraube
Tornillo hexagonal
Boulon à tête hexagonale
M8 x 40
3Nm/2ft.lbs
DIN 931
23 0010622 1
Flat washer
Scheibe
Arandela elástica
Rondelle de ressort
B8,4 DIN 125
24 0010624 1
Flat washer
Scheibe
Arandela elstica
Rondelle de ressort
B6,4 DIN 125
25 0012356 2
Hexagonal head cap screw
Sechskantschraube
Tornillo hexagonal
Boulon à tête hexagonale
M6 x 10
7Nm/5ft.lbs
DIN 933
S2
26 0105194 1
Washer
Scheibe
Arandela
Rondelle
M8 x 1,5in
27 0010367 1
Hexagon nut
Sechskantmutter
Tuerca hexagonal
Écrou hexagonal
M8 DIN 985
28 0033198 1
Lock washer
Federring
Federring
Rondelle de ressort
B8 DIN 6796
29 0155775 1
Inner cable
Inneres Kabel
Cable interior
Câble intérieur
29 0155774 1
Outer casing
Äussere Umhüllung
Envoltura exterior
Gaine extérieure
30 0118148 1
Throttle control
Gasregler
Acelerador
Commande des gaz
BS 500-4
Governor Control
Regler
Regulador
Régulateur
0009329 - 101
9
Governor Control
Regler
BS 500-4
Regulador
Régulateur
10
0009329 - 101
Ref.
Pos.
Part No.
Artikel Nr.
Qty.
St.
Description
Beschreibung
Descripción
Description
Measurem./Abm.
Torque/Drehm.
Norm
Sealant
Schmierstoff
31 0081072 1
Fuel tank cap cpl.
Kraftstofftankdeckel kompl
Tapa del tanque de combustible compl
Chapeau de réservoir à carburant compl.
32 0155454 1
Fuel tank
Kraftstofftank
Depósito de combustible
Réservoir de carburant
33 0086312 1
Ring seal
Dichtungsring
Anillo sellador
Rondelle à étancher
34 0112179 1
Fuel Filter Kit
Kraftstofffiltersatz
Juego-Filtro de Combustible
Jue-Filtre à Carburant
35 0110586 1
Bushing spacer
Abstandshlse
Espaciador
Entretoise
37 0157115 1
Throttle cable bracket
Gasreglerkonsole
Ménsula del cable del acelerador
Support
38 0155657 1
Guide handle
Führungsbügel
Manija
Poignée
41 0114066 1
Fuel Valve w/Bushing Kit
Satz-Kraftstoffhahn m/Buchse
Juego-grifo de combustible con buje
Jeu-robinet de carburant avecdouille
50 0011553 2
Socket head cap screw
Zylinderschraube
Tornillo cilíndrico
Vis à tête cylindrique
M6 x 16
17Nm/13ft.lbs
DIN 912
51 0155075 1
Air duct
Luftleitblech
Conducto de aire
Conduite d'air
BS 500-4
Governor Control
Regler
Regulador
Régulateur
0009329 - 101
11
Ref.
Pos.
Part No.
Artikel Nr.
Qty.
St.
Description
Beschreibung
Descripción
Description
Measurem./Abm.
Torque/Drehm.
Norm
Sealant
Schmierstoff
1 0011535 4
Socket head screw
Zylinderschraube
Tornillo hueco
Vis à six-pans creux
M10 x 25
49Nm/36ft.lbs
DIN 912
S2
2 0114794 1
Crankcase cover
Kurbelgehäusedeckel
Tapa del cárter
Couvercle de carter
3 0039026 1
O-Ring
O-Ring
Anillo-O
Joint torique
174 x 3
4 0072061 1
Needle bearing
Nadellager
Rodamiento de agujas
Roulement à aiguilles
5 2003022 2
Retaining ring
Sicherungsring
Anillo de retención
Bague d'arrêt
35 x 1,5 DIN 471
6 2003021 2
Ball bearing
Kugellager
Rodamiento de bolas
Roulement à billes
7 2003023 2
Retaining ring
Sicherungsring
Anillo de retención
Bague d'arrêt
72 x 2,5 DIN 472
8 0111476 1
Crank gear
Kurbeltrieb
Engranaje cigueñal
Commande à manivelle
64T/27,5
9 0089591 1
Connecting rod cpl.
Pleuel kpl.
Biela compl.
Bielle compl.
10 0045190 1
Ball bearing
Kugellager
Rodamiento de bolas
Roulement à billes
11 2001041 1
Retaining ring
Sicherungsring
Anillo de retención
Bague d'arrêt
25 x 1,2 DIN 471
12 0112078 1
Crankcase
Kurbelgehäuse
Cárter
Carter
13 0039020 1
Needle bearing
Nadellager
Rodamiento de agujas
Roulement à aiguilles
S7
14 2003021 1
Ball bearing
Kugellager
Rodamiento de bolas
Roulement à billes
15 0039050 1
Shaft seal
Wellendichtring
Sello del eje
Bague d'étanchéité
16 0110232 1
Clutch drum
Fliehkraftglocke
Campana de embrague
Carter d'embrayage
17 0117567 1
Pin
Stift
Pasador
Goupille
M8 x 20
BS 500-4
Crankcase cpl.
Kurbelgehäuse kpl.
Cárter compl.
Carter compl.
0009329 - 101
13
Ref.
Pos.
Part No.
Artikel Nr.
Qty.
St.
Description
Beschreibung
Descripción
Description
Measurem./Abm.
Torque/Drehm.
Norm
Sealant
Schmierstoff
1 0031880 1
O-Ring
O-Ring
Anillo-O
Joint torique
96 x 3
G3
2 0103403 1
Guide cylinder
Führungszylinder
Cilindro de guía
Cylindre de guidage
3 0110528 1
Clamp
Schelle
Abrazadera
Agrafe
5,25in ID
14Nm/10ft.lbs
4 0102862 1
Bellows
Faltenbalg
Fuelle
Soufflet
5 0150263 1
Protective pipe
Schutzrohr
Tubo de protección
Tube de protection
6 0011344 7
Hexagonal head cap screw
Sechskantschraube
Tornillo hexagonal
Boulon tte hexagonale
M8 x 55
24Nm/18ft.lbs
DIN 931
S3
7 0112195 7
Flat head screw
Senkschraube
Tornillo de cabeza perdida
Vis à tête conique
M6 x 40 DIN 7991
8 0089790 2
Push-in plug
Stopfen
Tapón
Bouchon
0,640 x 0,170
9 0039785 1
Piston pin
Kolbenbolzen
Pasador de pistón
Axe de piston
10 0103404 1
Ram
Führungskolben
Pistón
Piston
11 0113813 1
Spring cylinder
Federzylinder
Cilindro de resorte
Cylindre de ressort
12 0010644 1
Lock washer
Federring
Federring
Rondelle de ressort
B10 DIN 127
13 0110537 1
Clamp
Schelle
Abrazadera
Agrafe
5,75in ID
14Nm/10ft.lbs
14 0110170 1
Gasket
Dichtung
Junta
Joint
15 0013971 1
Sightglass
Ölschauglas
Mirilla del nivel de aceite
Verre-regard d'huile
7Nm/5ft.lbs
16 0011533 4
Socket head cap screw
Zylinderschraube
Tornillo cilíndrico
Vis à tête cylindrique
M10 x 35
43Nm/32ft.lbs
DIN 912
S2
17 0102750 1
Bushing
Buchse
Buje
Douille
18 0102699 2
Spring Set
Federsatz
Juego de resorte
Jeu de ressort
19 0103399 1
Piston guide
Kolbenführung
Guía de pistón
Guide de piston
20 0110196 1
Lock nut
Sicherungsmutter
Contratuerca
Contre-écrou
M16 x 1,5
176Nm/130ft.lbs
DIN 985
21 0102748 1
Bushing
Buchse
Buje
Douille
22 0117838 1
Gasket
Dichtung
Junta
Joint
23 0117450 1
Spring cover
Kappe
Tapa
Couvercle
24 0153427 1
Lifting handle
Tragegriff
Manija de levante
Poignée de relèvement
25 0153420 2
Spacer
Abstandsstück
Espaciador
Entretoise
BS 500-4
Guide Cylinder cpl.
Führungszylinder kpl.
Cilindro de Guía compl.
Cylindre de Guidage compl.
0009329 - 101
15
Ref.
Pos.
Part No.
Artikel Nr.
Qty.
St.
Description
Beschreibung
Descripción
Description
Measurem./Abm.
Torque/Drehm.
Norm
Sealant
Schmierstoff
26 0011301 2
Hexagonal head cap screw
Sechskantschraube
Tornillo hexagonal
Boulon à tête hexagonale
M12 x 50
86Nm/63ft.lbs
DIN 931
27 0031565 2
Lock washer
Federring
Federring
Rondelle de ressort
A12 DIN 6796
28 0154374 1
Lifting Handle Kit
Tragegriffsatz
Manija de levante compl.
Poignée de relèvement compl.
30 0010366 2
Hexagon nut
Sechskantmutter
Tuerca hexagonal
Écrou hexagonal
M12 DIN 985
31 0012983 2
Plow bolt
Senkschraube
Tornillo avellanado
Vis à tête fraisée
M12 x 110
BS 500-4
Guide Cylinder cpl.
Führungszylinder kpl.
Cilindro de Guía compl.
Cylindre de Guidage compl.
0009329 - 101
17
Ref.
Pos.
Part No.
Artikel Nr.
Qty.
St.
Description
Beschreibung
Descripción
Description
Measurem./Abm.
Torque/Drehm.
Norm
Sealant
Schmierstoff
1 0155224 1
WM 90 engine
WM 90 Motor
Motor WM 90
Moteur WM 90
2.8 hp
74 0011572 2
Socket head cap screw
Zylinderschraube
Tornillo cilíndrico
Vis à tête cylindrique
M4 x 10
3Nm/2ft.lbs
DIN 912
84 0011543 8
Socket head screw
Zylinderschraube
Tornillo hueco
Vis à six-pans creux
M8 x 20
24Nm/18ft.lbs
DIN 912
109 0033198 12
Lock washer
Federring
Federring
Rondelle de ressort
B8 DIN 6796
208 0156163 1
Guard
Schutz
Protector
Protection
209 0155505 1
Guard
Schutz
Protector
Protection
211 0011544 1
Socket head screw
Zylinderschraube
Tornillo hueco
Vis six-pans creux
M8 x 16
24Nm/18ft.lbs
DIN 912
212 0011542 2
Socket head screw
Zylinderschraube
Tornillo hueco
Vis à six-pans creux
M8 x 25
28Nm/21ft.lbs
DIN 912
221 0156954 2
Hose clamp
Schlauchschelle
Abrazaderas de manguera
Agrafe de tuyau
1/4in
BS 500-4
Engine Guarding
Motorschutzbleche
Blindajes del Motor
Protecteurs du Moteur
0009329 - 101
21
Roller Kit
Satz-Transportrolle
BS 500-4
Juego de Rodillo de Transporte
Jeu de Rouleau de Transport
24
0009329 - 101
Ref.
Pos.
Part No.
Artikel Nr.
Qty.
St.
Description
Beschreibung
Descripción
Description
Measurem./Abm.
Torque/Drehm.
Norm
Sealant
Schmierstoff
1 0086572 1
Roller Transport Kit
Satz-Transportrolle
Juego-rodillo de transporte
Jeu-rouleau de transport
3 0011553 4
Socket head cap screw
Zylinderschraube
Tornillo cilíndrico
Vis à tête cylindrique
M6 x 16
17Nm/13ft.lbs
DIN 912
4 0010368 4
Hexagon nut
Sechskantmutter
Tuerca hexagonal
Écrou hexagonal
M6 DIN 985
BS 500-4
Roller Kit
Satz-Transportrolle
Juego de Rodillo de Transporte
Jeu de Rouleau de Transport
0009329 - 101
25
Ref.
Pos.
Part No.
Artikel Nr.
Qty.
St.
Description
Beschreibung
Descripción
Description
Measurem./Abm.
Torque/Drehm.
Norm
Sealant
Schmierstoff
10 0158643 1
Flywheel
Schwungrad
Volante
Volant
11 0158644 1
Ignition coil
Zündspule
Bobina de encendido
Bobine d'allumage
30 0156433 2
Bolt w/washer
Bolzen mit Scheibe
Perno con arandela
Boulon avec rondelle
60 0044807 1
Engine switch-1 wire
Motorschalter-1 Draht
Interruptor del motor-1 alambre
Interrupteur de moteur-à 1 fil
70 0158645 2
Screw w/washer
Schraube mit Scheibe
Tornillo con arandela
Vis avec rondelle
75 0071404 1
Clamp
Schelle
Abrazadera
Agrafe
100 0158646 1
Spark plug
Zündkerze
Bujía
Bougie d'allumage
BS 500-4
Ignition
Zündung
Encendido
Allumage
0009329 - 101
29
Ref.
Pos.
Part No.
Artikel Nr.
Qty.
St.
Description
Beschreibung
Descripción
Description
Measurem./Abm.
Torque/Drehm.
Norm
Sealant
Schmierstoff
0 0158647 1
Carburetor
Vergaser
Carburador
Carburateur
900 0158648 1
Screen
Sieb
Tamiz
Tamis
901 0158649 1
Cover
Deckel
Tapa
Couvercle
902 0158650 1
Cover
Deckel
Tapa
Couvercle
903 0158651 1
Throttle shaft
Drosselwelle
Eje de mariposa
Arbre des gaz
904 0158652 1
Throttle valve
Drosselklappe
Válvula de estrangulación
Étrangleur
905 0158653 1
Choke shaft cpl.
Chokewelle kpl.
Eje estrangulador compl.
Arbre étrangleur compl.
906 0158654 1
Clip
Befestigung
Clip
Clip
907 0158655 1
Choke valve
Drosselventil
Válvula estranguladora
Soupape d'étranglement
908 0158656 1
Fuel inlet needle
Einlaßnadel
Aguja de admisión
Aiguille d'admission
909 0158657 1
Ball
Kugel
Bola
Bille
910 0158658 1
Gasket
Dichtung
Junta
Joint
911 0158659 1
Gasket
Dichtung
Junta
Joint
912 0158660 1
Diaphragm
Membran
Diafragma
Membrane
914 0159160 1
Diaphragm
Membran
Diafragma
Membrane
915 0159161 1
Screw
Schraube
Tornillo
Vis
916 0159162 5
Screw
Schraube
Tornillo
Vis
917 0159163 1
Screw
Schraube
Tornillo
Vis
918 0159164 1
Screw
Schraube
Tornillo
Vis
919 0159165 1
Adjusting spring
Justierfeder
Resorte de ajuste
Ressort d'ajustage
920 0159166 1
Spring
Feder
Resorte
Ressort
921 0159167 1
Spring
Feder
Resorte
Ressort
925 0159168 1
Pin
Stift
Pasador
Goupille
926 0159169 1
Lever
Hebel
Palanca
Levier
927 0159170 1
Welch plug
Blindstopfen
Tapón
Bouchon
BS 500-4
Carburetor cpl.
Vergaser kpl.
Carburador compl.
Carburateur compl.
0009329 - 101
31
Ref.
Pos.
Part No.
Artikel Nr.
Qty.
St.
Description
Beschreibung
Descripción
Description
Measurem./Abm.
Torque/Drehm.
Norm
Sealant
Schmierstoff
929 0159171 1
Idle speed screw
Leerlaufeinstellschraube
Tornillo de velocidad de ralenti
Vis de régime de ralenti
931 0159172 2
Screw
Schraube
Tornillo
Vis
940 0159173 1
Screen
Sieb
Tamiz
Tamis
941 0159174 1
Plug
Stopfen
Tapón
Bouchon
942 0159175 1
Ring
Ring
Anillo
Anneau
943 0159176 1
Spring
Feder
Resorte
Ressort
945 0159177 1
Throttle stop
Anschlag
Detenedor
Butée
946 0159178 1
Throttle lever
Gashebel
Palanca de regulador
Levier des gaz
948 0159179 1
Spacer
Abstandsstück
Espaciador
Entretoise
949 0159180 1
Washer
Scheibe
Arandela
Rondelle
BS 500-4
Carburetor cpl.
Vergaser kpl.
Carburador compl.
Carburateur compl.
0009329 - 101
33
Ref.
Pos.
Part No.
Artikel Nr.
Qty.
St.
Description
Beschreibung
Descripción
Description
Measurem./Abm.
Torque/Drehm.
Norm
Sealant
Schmierstoff
1 0158597 1
Spring
Feder
Resorte
Ressort
2 0158598 1
Starter reel
Seilscheibe
Disco de cuerda
Disque pour corde
3 0158599 1
Rope
Seil
Cuerda
Corde
4 0117260 1
Starter handle
Anwerfgriff
Empuñadura del arranque
Poignée du lanceur
5 0117261 2
Ratchet (pawl)
Ratsche
Trinquete
Cliquet
6 0158600 1
Spring-friction
Reibfeder
Resorte de fricción
Ressort de friction
7 0083887 2
Friction spring
Reibfeder
Resorte de fricción
Ressort de friction
10 0158601 1
Blower housing
Lüftergehäuse
Cubierta
Bouclier
11 0158602 1
Starter pulley
Starterscheibe
Polea
Poulie de démarrage
20 0158603 1
Label
Aufkleber
Calcomania
Autocollant
24 0158604 1
Plate
Platte
Placa
Plaque
25 0158605 1
Plate
Platte
Placa
Plaque
35 0117263 1
Ratchet guide
Führung
Guía
Ancre
40 0156455 4
Flange bolt
Flanschbolzen
Perno de reborde
Boulon à bride
49 0083891 1
Setscrew
Gewindestift
Tornillo
Vis
60 0158606 1
Cylinder baffle
Leitblech
Deflector
Déflecteur
80 0156645 1
Flange bolt
Flanschbolzen
Perno de reborde
Boulon à bride
110 0158607 1
Engine fan
Motorgebläserad
Ventilador del motor
Ventilateur du moteur
210 0158608 1
Starter-recoil
Reversierstarter
Arrancador
Démarreur
220 0156645 3
Flange bolt
Flanschbolzen
Perno de reborde
Boulon à bride
230 0053612 4
Flange bolt
Flanschbolzen
Perno de reborde
Boulon à bride
M6 x 12
10Nm/7ft.lbs
BS 500-4
Starter
Starter
Arrancador
Démarreur
0009329 - 101
35
Ref.
Pos.
Part No.
Artikel Nr.
Qty.
St.
Description
Beschreibung
Descripción
Description
Measurem./Abm.
Torque/Drehm.
Norm
Sealant
Schmierstoff
10 0159181 1
Governor lever
Reglerhebel
Palanca del gobernador
Levier régulateur
20 0156103 1
Governor shaft
Reglerwelle
Eje de regulador
Arbre régulateur
30 0159182 1
Governor rod
Reglerstange
Varilla
Tringle
35 0159183 1
Bushing
Buchse
Buje
Douille
40 0159184 1
Spring
Feder
Resorte
Ressort
50 0156106 2
Clip
Befestigung
Clip
Clip
60 0077397 1
Bolt w/washer
Bolzen mit Scheibe
Perno con arandela
Boulon avec rondelle
70 0159185 1
Weight
Gewicht
Peso
Poids
80 0159186 1
Governor spring
Reglerfeder
Resorte del regulador
Ressort régulateur
200 0159187 1
Speed control module
Drehzahlregler
Controlador de velodicad
Régulateur de vitesse
201 0159188 1
Control base plate
Grundplatte
Basa
Base
207 0156645 2
Flange bolt
Flanschbolzen
Perno de reborde
Boulon à bride
210 0159189 1
Pan head screw
Flachkopfschraube
Tornillo de cabeza de cono achatado
Vis ber
213 0159190 1
Spacer
Abstandsstück
Espaciador
Entretoise
215 0159191 1
Spring-return
Ausdrückbolzenfeder
Resorte retractor
Ressort de rappel
230 0053649 1
Pan head screw
Flachkopfschraube
Tornillo de cabeza de cono achatado
Vis ber
M6 x 30
240 0053650 1
Nut
Mutter
Tuerca
Écrou
M6
252 0159192 1
Washer
Scheibe
Arandela
Rondelle
260 0159193 1
Pan head screw
Flachkopfschraube
Tornillo de cabeza de cono achatado
Vis ber
265 0159194 1
Spring
Feder
Resorte
Ressort
280 0159195 1
Screw
Schraube
Tornillo
Vis
BS 500-4
Governor
Regler
Regulador
Régulateur
0009329 - 101
37
Ref.
Pos.
Part No.
Artikel Nr.
Qty.
St.
Description
Beschreibung
Descripción
Description
Measurem./Abm.
Torque/Drehm.
Norm
Sealant
Schmierstoff
10 0159196 1
Camshaft
Nockenwelle
Arbol de levas
Arbre à cames
34 0159197 1
Pin
Stift
Pasador
Goupille
35 0159198 1
Lever
Hebel
Palanca
Levier
36 0084336 1
Pin
Stift
Pasador
Goupille
37 0159199 1
Ring
Ring
Anillo
Anneau
38 0159200 1
Spring-return
Ausdrückbolzenfeder
Resorte retractor
Ressort de rappel
50 0159201 2
Tappet
Stößel
Alzaválvulas
Poussoir
60 0159202 2
Valve spring
Ventilfeder
Resorte de válvula
Ressort de soupape
70 0159203 2
Spring
Feder
Resorte
Ressort
80 0159204 1
Intake valve
Einlaßventil
Válvula de admisión
Soupape d'admission
90 0159205 1
Exhaust valve
Auslaßventil
Válvula de escape
Soupape d'échappement
95 0114036 4
Valve
Ventil
Válvula
Soupape
210 0159206 2
Push rod
Stoßstange
Levantaválvula
Poussoir de soupape
220 0159207 2
Rocker arm
Kipphebel
Balancín
Culbuteur
230 0117237 2
Bolt
Bolzen
Perno
Boulon
240 0117238 2
Nut
Mutter
Tuerca
Écrou
260 0159208 1
Plate
Platte
Placa
Plaque
310 0159209 1
Muffler cpl.
Auspufftopf kpl.
Silenciador compl.
Pot d'Echappement compl.
340 0159210 1
Exhaust gasket
Auspuffdichtung
Junta de escape
Joint d'échappement
351 0075270 2
Flange nut
Flanschmutter
Tuerca de reborde
Ecrou de bride
365 0159211 2
Flange bolt
Flanschbolzen
Perno de reborde
Boulon à bride
366 0159212 2
Bolt w/washer
Bolzen mit Scheibe
Perno con arandela
Boulon avec rondelle
528 0159213 1
Plate
Platte
Placa
Plaque
530 0159214 2
Carburetor gasket
Vergaserdichtung
Junta de carburador
Joint de carburateur
550 0159215 1
Gasket
Dichtung
Junta
Joint
BS 500-4
Intake/Exhaust
Einlass/Auspuff
Admisión/Escape
Admission/Échappement
0009329 - 101
39
1 / 1

dans d''autres langues
