ProScan PLT 7044-K-C Manuel utilisateur

User Manual

PLT7044K-C



 8VHU0DQXDO



Key points喚

This manual includes security measures and correct operating methods. For personal safety, please make sure to read this

manual before using. Thank you!

The machine adopts capacitive touch screen, you can just touch it by finger or click with capacitive pen for operation. (Never use

the sharp objects to click the screen, or the touch screen may be damaged).

Do not put the device at any high temperature, high humidity or dusty place.

Do not drop or crash the device to prevent the violent impacting between the display and the capacitive touch screen. Or the

customers have to take the consequence by themselves.

Please choose the suitable volume and never make the too loud volume .If you feel uncomfortable please turn down the volume

or stop to use the device soon.

Please charge if you meet those situations as below:

AǃLow battery on the battery icon. BǃThe system turns off automatically.

CǃThe keys do not work. Dǃ“ ” is battery charging.

ǏNoteǐ:Don’t use the different type charger or it may make the device burned. We assume no liability for the damage.

Please contact with our agent if you need the original adaptor.

In the charging processˈthe device may be warning up a little (not too hot), this is normal, and it won’t effect functions.

Do not disconnect the device while formatting, downloading or uploading, or it may make the error.

Our company won’t bear the duty for the loss of the memory erasing on account of the damage, repair or some other reason.

Please operate the device according to the user manual rightly and backup the important data in time.

Do not dismantle this device by yourself, and do not polish it with alcohol, dilution, or benzene.

Do not use this device where electronics is forbidden, such as on the airplane.

Do not use this device while walking and driving, avoiding traffic accident.

USB is for transferring data but NOT for charging.

Virus can damage this device. So please use proper computer antivirus and keep it updated.

For any support needed for this device please contact the company or the authorized distributor. Any unauthorized dismantling of

the device will make the warranty null and void.

We reserve the right to keep the change of the products, the specification and design is subject to change without notice!

240V 50/60Hz 0.4A

USB Cable

Packing List:

Please check box for the following items

1. Device

2. User Manual

3. Product Warranty

4. Power Adaptor

5.

Other accessories can be purchased at local retailers

The accessories may not be compatible with other devices

Power Adaptor Specification:

INPUT:

AC 100-

OUTPUT: 5.0V

1.5A

6. OTG Cable

7. Keyboard & Case Included

Device description

Touch screen You can click and drag in the touch screen.

Camera

You can take photos and videos etc..

Volume

-

Turn down the volume.

+ Turn up the volume.

POWER

Keep pressing button over 2 seconds for power on/ off, press

button once to turn on screen from sleep mode .

microSD

card

microSD card slot.

TIPS 1. When the battery is low, it will power off automatically.

2. Shutdown illegally, when you restart, device would scan and repair the disk. The screen will stay at the progress bar

for a long time .

Note The pictures in the user manual are just for your reference, about the “ ” item, please according to the real products.

DC jack: Connect the power cable to charge to

the device.

Micro USB: Micro-5pin connector

Earphone jack: 3.5mm standard earphone jack.

1

3

4

5

6

8

7

2

3

1

2

4

5

6

7

8

RESET: Reset the device.

9

8

9

Setting up for the first time

Charging your device

For first-time use, you need to charge the device for ten hours.

After that you can recharge the device as needed.

Connect the DC-in jack to your device and plug the AC adapter into any AC outlet.

TIPS :

1. This device adopts built-in polymer battery. Only the specified charger should be used.

2. It is normal for the device s surface to become warm during charging or long

periods of use. All devices are factory tested before release.

3. If you do not use this set for a long time, please charge/release it once

one month to avoid deep discharge. The damage caused by battery over-consuming is not included in the warranty.

Battery Saving

To save battery running life, please see below key points. With below suggestions, batt

ery can run longer time after fully charged

each time.

1. When device is not in use, press power button once to go to sleep mode.

2. Shut down the applications when not in use.

3. Turn off WLAN when not in use

4. Shut off application sync selection

5. Set a shorter time for display backlight

6. Reduce brightness of display

Power On

Keep pressing power button over 2 seconds, device will start up opening screen, Android system is activating and enter the main

screen.

Sleep Mode

After devise is on, press power button once and it goes to sleep mode. The screen is now on standby and under low battery

consumption. To wake up device, press one more time power button.

Power off and Forced Shut down

When you are not using the device, keep pressing power button over 2 seconds, the

screen will display “shut down”, select “Yes” to power off unit completely.

If device is hanging, use a small pin to

press Reset hole, it will forced shut down and the

device will power on again.

Operation of Touch Panel

Click -- Use finger or capacity panel pen to touch once, so as to select or activate function, or select menu or turn on applications.



 8VHU0DQXDO



Tap and hold -- Tap over 2 seconds, it will turn on option list

Slide -- Slide up, down, left or right for fast scrolling browsing page and display screen

Drag – drag an icon and relocate the position



 8VHU0DQXDO



Double Click – Double click to enlarge or shrink the display size of picture or under browsing webpage.

Shut --Use two fingers at same time on touch panel, to enlarge or to shrink the display scale.

Home Screen

Google Search

List of last running applications

Back to Home screen

Back to previous screen

Display of icons and device status, click to turn on notification screen

Shortcut to application

Enter applications page



 8VHU0DQXDO



Home screen with a set of 5 screens, slide left/ right to view individual screen

¾ Change of Wallpaper

1. Tag home screen, it will pop-up wallpaper selection

2. Select preloaded wallpapers or picture as wallpaper

3. Click “setup” to confirm

¾ Add shortcut on Home screen

1. Enter in application page, tag the icon of application

2. Locate the icon to designated position or locate it in another screen

¾ Add Widget in Home Screen

1. Enter application page and slide to Widget page

2. Slide left / right to select widget

3. ag designated widget and locate it in home screen

Remark :˖Some widgets is linked to internet service, be careful it will occur data cost

Some widgets might only be used in certain countries or under assigned service providers

¾ Relocate the shortcut on Home screen

1. Tag the application icon and move

2. Move icon to the designated position

¾ Cancel shortcut on Home screen

1. Tag the application icon, recycle bin displays on upper screen

2. Drag icon to recycle bin

3. When icon changes to red, let go



 8VHU0DQXDO



¾ Notification screen

In home screen or under running application, select right side notification screen, check device status and set up below options˖

Icon Icon Description

WiFi signal Wifi connection, icon is full under strong signal

Battery Status of battery or if device is being charged

USB Connection To show if USB port is connected

Soft keyboard Turn on soft keyboard, for word typing

Screen shot Press power button with volume down simultaneously to take screen shot

Applications

Internet Browsing

Browse internet and bookmark the website

Remark ˖Web browser and bookmark might be different in different countries or different service providers



 8VHU0DQXDO



¾ Browsing webpage

1. Enter application page, select ”Browser” Icon

2. To brows certain webpage, select URL and input website address, and select “confirm”

3. See below browsing options˖

ķ Open new window

ĸ Shut down current webpage

Ĺ Go to Next or Previous webpage

ĺ Accessing webpage, icon becomes “X” when webpage shows

Ļ Detail message of webpage

ļ Enter webpage address or related words

Ľ Bookmark current page

ľ Search message

Ŀ Open bookmark and current visited webpage

ŀ Option list of browser



 8VHU0DQXDO



¾ Browser setting

When browsing webpageˈclick upper right cornerĀ āˈadjust setting in the option menu

¾ Current visited webpage

1. Enter application page, click ”Browser”

2. Select bookmark

Æ current visited history

3. Select webpage

Email

Send and Receive email

¾ Setting of email account

1. Enter application page and click ”Email”

2. Enter email address and password

3. Select next step ( for personal email account) or manual setting (for commercial email account)

4. Follow and input the requested setting

5. For setting more than one email account, select

Æ setting Æ add email account, repeat steps 2-4.

After email account setting, message will be received in device. For more than one email account, switch email account for operation,

to receive and send out message.



 8VHU0DQXDO



¾ Sending outgoing message

1. Enter application page and select “Email”Æ

2. Type in Recipients ˗Manual input email addressˈuse “ ;” or “,” to separate more than one recipients

3. Type in Subject

4. Type in message in content

5. Select for attachments

6. Select

and send out message

Remark ˖If user is offlineˈmessage cannot be sent out

¾ Check email message

In email account, user can check downloaded message, go online to check new messages.



 8VHU0DQXDO



Audio player

Click “Musicāin application page

Music will be categorized by artists, album, and play list. It will display all music insideĀSongsā. Click the song and it will play

automatically.



 8VHU0DQXDO



¾ Lyrics Sync

Lyrics Sync is available in audio player.

1. Copy the LRC file of song in Memoryˈthe lyric file must be same as song name.

e.g, “Rolling In The Deep.mp3”ˈthe lyric file must be ”Rolling In The Deep.lrc”

2. When playing songˈclick to turn on Lyrics Sync.

Video player

Click “Videoāin application page.

Video player will search for all supported video files in the device, click the designated video file to play.

Camera

The built-in front camera can take picture and video file.

¾ Take picture

1. ClickĀCameraāin application page, device is default at picture taking, icon isĀ

ā

2. To take pictureˈclick Ā ā

¾ Video shooting

1. Select recording in video fileˈclickĀ ā

2. Click Ā

āto record video file.

3. Click Ā āagain to stop recording

App stores

SlideMe

Camera Setting

In camera mode

click for set up click to select set up options

File Explorer

Go to application page and click Explorer

Check file

In

Explorer user can check and manage files in SD Card Internal Memory and USB

Connect USB port with OTG cable

it shall detect USB device such as memory stick, click Explorer to check files

File operation

1. Go to application page and click

Explorer

2. Select file or file path

3. Press file or folder over 2 seconds

user can operate it through options

4. Select Multi

select file or folder select Editor perform function in option list it can manage files under option list.

Management of application files

Installation of applications

In Android system

all application files and game files are in APK format APK files can be installed through TF card, internal memory

or download from and similar third party providers.

1. APK installation from device

download APK file from computer, saved it in TF card or in device through OTG cable. Click the APK

file under

ApkInstaller in application page complete installation. The application icon will be shown in application page.

2. Installation through

Connect device with WiFi Click icon select APK file for installation.

Uninstall APK file

1. Go to application page and click

ApkInstaller

2. Select “Manage”

3. Click APK file to uninstall.

Shut down running application

1. Click to have all the running applications.

2. Finger across the special application you want to shut down.

Or you may shut down all of them one by one.

Connecting to a PC:

• You can connect with PC by USB cable attached with the device.

You can transfer your personal data to the PC.

• Connect the PC and the device, it will change to the USB mode,

in this state, realize the files transfer function between the PC and

the device.

Connecting a USB device:

• USB devices are supported, such as a keyboard, mouse through the USB port.

• View media files on USB storage with installed photo, music or video applications.

Caution : Before removing this USB storage,

make sure your device is not accessing data from the USB storage.

Inserting the Micro SD card:

You may install a Micro SD card to expand your device’s storage space.

1. This device supports Micro SD card up to 32GB capacity.

2. Insert the Micro SD card as shown.

Note : Ensure that the Micro SD card is inserted all the way into the card slot.

Caution : Before removing this card, make sure your device is not accessing data on

the card.

Connecting to the Network:

Wi-Fi wireless setup:

Enter the setting interface, and turn on the Wi-Fi item.

The device will automatically search any accessible nearby wireless networks.

microSD

Commonly used settings

Press the setup icon to enter the setting.

Wi-Fi: Click ON or OFF to open or close Wi-Fi.

When open Wi-Fi the system will scan the wifi signal around automatically.

Meanwhile, users could add network manually as well.

More:

1. VPN: The users can connect to some special websites by VPN setting.

2. Portable hotspot: You must connect the cable to network (by RJ45

connector) then you can enter the option to open or close the Portable Wi-Fi

hotspot , you can also take this device as a Wi-Fi Router.

3. Mobile networks:

Connect a USB 3G Dongle setting

To insert a USB 3G dongle, the device will

connect the Internet automatically. A 3G icon will be displayed on the screen.

(Please make sure the 3G SIM card is matching with the 3G dongle well)

Remark1 After turning on Portable Wi-Fi hotspot Wi-Fi will close automatically.

Remark2 When you use 3G to connect internet you must shut off Wi-Fi first.

La page charge ...

ProScan PLT 7044-K-C Manuel utilisateur

Ce manuel convient également à

ProScan PLT 7044-K-C Manuel utilisateur

dans d''autres langues

Documents connexes

Autres documents
