LG 49LV570H Le manuel du propriétaire

www.lg.com

Please read this manual carefully before operating

your TV and retain it for future reference.

32LV560H

32LV570H

40LV560H

40LV570H

43LV560H

43LV570H

49LV560H

49LV570H

55LV560H

55LV570H

65LV570H

Safety and Reference

LED TV*

* LG LED TVs are LCD TVs with LED backlighting.

OWNER’S MANUAL

P/NO : MFL69885518 (1705-REV02)

*MFL69885518*

2

ENGLISH

Warning! Important Safety

instructions

Read these instructions. Keep these instructions.

Heed all warnings. Follow all instructions.

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

CAUTION: TO REDUCE THE RISK OF ELECTRIC

SHOCK DO NOT REMOVE COVER (OR BACK).

NO USER SERVICEABLE PARTS INSIDE. REFER

TO QUALIFIED SERVICE PERSONNEL.

The symbol is intended to alert the user

to the presence of uninsulated dangerous

voltage within the product’s enclosure that

may be of sufficient magnitude to constitute a

risk of electric shock to persons.

The symbol is intended to alert the user to

the presence of important operating and

maintenance (servicing) instructions in the

literature accompanying the device.

WARNING: TO REDUCE THE RISK OF FIRE

AND ELECTRIC SHOCK, DO NOT EXPOSE THIS

PRODUCT TO RAIN OR MOISTURE.

• Do not use this apparatus near water.

• Clean only with dry cloth.

• Do not block any ventilation openings. Install in

accordance with the manufacturer’s instructions.

• Do not install near any heat sources such

as radiators, heat registers, stoves, or other

apparatus (including amplifiers) that produce

heat.

• Do not defeat the safety purpose of the

polarized or grounding-type plug. A polarized

plug has two blades with one wider than the

other. A grounding type plug has two blades

and a third grounding prong. The wide blade or

the third prong are provided for your safety. If

the provided plug does not fit into your outlet,

consult an electrician for replacement of the

obsolete outlet.

• Protect the power cord from being walked on

or pinched particularly at plugs, convenience

receptacles, and the point where they exit from

the apparatus.

• Only use attachments/accessories specified by

the manufacturer.

• Use only with the cart, stand, tripod, bracket, or

table specified by the manufacturer, or sold with

the apparatus. When a cart is used, use caution

when moving the cart/apparatus combination to

avoid injury from tip-over.

• Unplug this apparatus during lightning storms

or when unused for long periods of time.

• Refer all servicing to qualified service personnel.

Servicing is required when the apparatus has

been damaged in any way, such as power-supply

cord or plug is damaged, liquid has been spilled

or objects have fallen into the apparatus, the

apparatus has been exposed to rain or moisture,

does not operate normally, or has been dropped.

• Do not press strongly upon the panel with a

hand or a sharp object such as a nail, pencil, or

pen, or make a scratch on it.

• Do not stick metal objects or any other

conductive material into the power cord. Do

not touch the end of the power cord while it is

plugged in.

• Keep the packing anti-moisture material or

vinyl packing out of the reach of children.

Anti-moisture material is harmful if swallowed.

If swallowed, induce vomiting and go to the

nearest hospital. Additionally, vinyl packing can

cause suffocation. Keep it out of the reach of

children.

• Concerning the Power Cord (Can differ by

country): Check the specification page of this

owner’s manual to be certain concerning

current requirements. Do not connect too

many devices to the same AC power outlet as

this could result in fire or electric shock. Do not

overload wall outlets. Overloaded wall outlets,

loose or damaged wall outlets, extension cords,

frayed power cords, or damaged or cracked

wire insulation are dangerous. Any of these

conditions could result in electric shock or fire.

Periodically examine the cord of your device,

and if its appearance indicates damage or

deterioration, unplug it, discontinue use of

the device, and have the cord replaced with

an exact replacement part by an authorized

servicer. Protect the power cord from physical or

mechanical abuse, such as being twisted, kinked,

pinched, closed in a door, or walked upon. Pay

3

ENGLISH

particular attention to plugs, wall outlets, and

the point where the cord exits the device. Do not

move the TV with the power cord plugged in. Do

not use a damaged or loose power cord. Be sure

do grasp the plug when unplugging the power

cord. Do not pull on the power cord to unplug

the TV.

• To reduce the risk of fire or electrical shock,

do not expose this product to rain, moisture

or other liquids. Do not touch the TV with

wet hands. Do not install this product near

flammable objects such as gasoline or candles,

or expose the TV to direct air conditioning.

• Do not use high voltage electrical equipment

near the TV (e.g., a bug zapper). This may result

in product malfunction.

• Do not expose to dripping or splashing and

do not place objects filled with liquids, such as

vases, cups, etc. on or over the apparatus (e.g.,

on shelves above the unit).

• Grounding (Except for devices which are not

grounded.) Ensure that you connect the earth

ground wire to prevent possible electric shock

(i.e., a TV with a three-prong grounded AC plug

must be connected to a three-prong grounded

AC outlet). If grounding methods are not

possible, have a qualified electrician install a

separate circuit breaker. Do not try to ground

the unit by connecting it to telephone wires,

lightning rods, or gas pipes.

• As long as this unit is connected to the AC wall

outlet, it is not disconnected from the AC power

source even if the unit is turned off.

• Do not attempt to modify this product in any

way without written authorization from LG

Electronics. Unauthorized modification could

void the user’s authority to operate this product.

• Outdoor Antenna Grounding (Can differ by

country): If an outdoor antenna is installed,

follow the precautions below. An outdoor

antenna system should not be located in the

vicinity of overhead power lines or other electric

light or power circuits, or where it can come in

contact with such power lines or circuits as death

or serious injury can occur. Be sure the antenna

system is grounded to provide some protection

against voltage surges and built-up static

charges. Section 810 of the National Electrical

Code (NEC) in the U.S.A. provides information

with respect to proper grounding of the mast

and supporting structure, grounding of the

lead-in wire to an antenna discharge unit, size

of grounding conductors, location of antenna

discharge unit, connection to grounding

electrodes and requirements for the grounding

electrode. Antenna grounding according to the

National Electrical Code, ANSI/NFPA 70

• Moving Make sure the product is turned off,

unplugged, and all cables have been removed.

It may take 2 or more people to carry larger TVs.

Do not press or put stress on the front panel of

the TV.

• Ventilation Install your TV where there is proper

ventilation. Do not install in a confined space

such as a bookcase. Do not cover the product

with cloth or other materials while plugged. Do

not install in excessively dusty places.

• Take care not to touch the ventilation openings.

When watching the TV for a long period, the

ventilation openings may become hot. This does

not affect the performance of the product or

cause defects in the product.

• If you smell smoke or other odors coming from

the TV, unplug the power cord and contact an

authorized service center.

• If water or another substance enters the

product (like an AC adapter, power cord, or TV),

disconnect the power cord and contact the

service center immediately. Otherwise, this may

result in fire or electric shock.

• Do not install this product on a wall if it could be

exposed to oil or oil mist. This may damage the

product and cause it to fall.

• Use only an authorized AC adapter and power

cord approved by LG Electronics. Otherwise, this

may result in fire, electric shock, malfunction, or

product deformation.

• Never disassemble the AC adapter or power

cord. This may result in fire or electric shock.

• Handle the adapter carefully to avoid dropping

or striking it. An impact could damage the

adapter.

4

ENGLISH

• Keep the product away from direct sunlight.

• Never touch this apparatus or antenna during a

lightning storm.

• When mounting a TV on the wall, make sure not

to install the TV by hanging the power and signal

cables on the back of the TV.

• Do not allow an impact shock, any objects to fall

into the product, and do not drop anything onto

the screen.

• DISCONNECTING THE DEVICE FROM THE MAIN

POWER The power plug is the disconnecting

device. In case of an emergency, the power plug

must remain readily accessible.

• Make sure the power cord is connected securely

to the power plug on the TV.

• Batteries Store the accessories (battery, etc.) in a

safe location out of the reach of children.

• This apparatus uses batteries. In your community

there might be regulations that require you

to dispose of these batteries properly due to

environmental considerations. Please contact

your local authorities for disposal or recycling

information.

• Do not dispose of batteries in a fire.

• Do not short circuit, disassemble, or allow the

batteries to overheat.

• Cleaning When cleaning, unplug the power

cord and wipe gently with a soft cloth to prevent

scratching. Do not spray water or other liquids

directly on the TV as electric shock may occur.

Do not clean with chemicals such as alcohol,

thinners, or benzene.

Preparing

• Image shown may differ from your TV.

• Your TV’s OSD (On Screen Display) may differ

slightly from that shown in this manual.

• The available menus and options may differ from

the input source or product model that you are

using.

• New features may be added to this TV in the

future.

• The items supplied with your product may vary

depending upon the model.

• Product specifications or contents of this manual

may be changed without prior notice due to

upgrade of product functions.

• For an optimal connection, HDMI cables and

USB devices should have bezels less than 10 mm

(0.39 inches) thick and 18 mm (0.7 inches) width.

• Use an extension cable that supports USB 2.0 if

the USB cable or USB flash drive does not fit into

your TV’s USB port.

• Use a certified cable with the HDMI logo

attached. If you do not use a certified HDMI

cable, the screen may not display or a

connection error may occur.

• Recommended HDMI cable types (3m or less)

- High-Speed HDMI®/™ cable

- High-Speed HDMI®/™ cable with Ethernet

B

A

B

*A 10 mm (0.39 inches)

*B 18 mm (0.7 inches)

• Do not use any unapproved items to ensure the

safety and lifespan of the product.

• Any damages or injuries by using unapproved

items are not covered by the warranty.

• Some models appear to have a thin film on the

screen. It is actually part of the screen; do not

remove it.

• When attaching the stand to the TV set, place

the screen facing down on a cushioned table or

flat surface to protect the screen from scratches.

• Make sure that the screws are fastened tightly.

(If they are not fastened securely enough, the TV

may tilt forward after being installed.)

• Do not fasten the screws with excessive force

otherwise they may be worn out and become

loose.

5

ENGLISH

Lifting and Moving the TV

When moving or lifting the TV, read the following

to prevent the TV from being scratched or

damaged and for safe transportation regardless of

its type and size.

• It is recommended to move the TV in the box or

packing material that the TV originally came in.

• Before moving or lifting the TV, disconnect the

power cord and all cables.

• When holding the TV, the screen

should face away from you to

avoid damage.

• Hold the top and bottom of the TV frame firmly.

Make sure not to hold the transparent part,

speaker, or speaker grille area.

• Use at least two people to move

a large TV.

• When transporting the TV by

hand, hold the TV as shown in the

following illustration.

• When transporting the TV, do not expose the TV

to jolts or excessive vibration.

• When transporting the TV, keep the TV upright;

never turn the TV on its side or tilt towards the

left or right.

• When handling the TV, be careful not to damage

the protruding buttons.

• Avoid touching the screen at all times, as

this may result in damage to the screen.

• Do not place the product on the floor

with its front facing down without

padding. Failure to do so may result in

damage to the screen.

• Do not move the TV by holding the cable

holders, as the cable holders may break,

and injuries and damage to the TV may

occur. (Depending upon model)

Using the Button

You can operate the TV functions, using the

button.

or

Basic Functions

(Type A)

Power On (Press)

Power Off

1

(Press and Hold)

Volume Control

Channels Control

(Type B)

Power On / Off

(Press)

1 If the menu button is on the screen, pressing

and holding the joystick button will let you exit

the menu.

Adjusting the Menu

When the TV is turned on, press the button one

time. You can adjust the Menu items using the

button. (Depending upon model)

Turns the power off.

Accesses the setting menu.

Clears on-screen displays and returns to TV

viewing.

Changes the input source.

6

ENGLISH

Mounting on a Table

1 Lift and tilt the TV into its upright position on a

table.

- Leave a 10 cm (4 inches) (minimum) space from

the wall for proper ventilation.

10 cm

(4 inches)

2 Connect the power cord to a wall outlet.

• Do not place the TV near or on sources

of heat, as this may result in fire or other

damage.

• Do not apply foreign substances (oils,

lubricants, etc.) to the screw parts when

assembling the product. (Doing so may

damage the product.)

Adjusting the Angle of the TV to Suit

View

(Depending upon model)

Swivel 20 degrees to the left or right and adjust the

angle of the TV to suit your view.

20˚20˚

• When adjusting the angle of the TV,

watch out for your fingers.

- Personal injury may occur if hands or

fingers are pinched. If the product is

tilted too much, it may fall, causing

damage or injury.

Attaching the TV to a desk

(Depending upon model)

If mounting the TV on a table, make sure it is

installed according to the method outlined in

‘Attaching the TV to a desk’.

The TV should be attached to a desk so it cannot

be pulled in a forward/backward direction,

potentially causing injury or damaging the

product.

[TYPE 1-1]

4-Screws

(Not provided as parts of the product.)

Stand

Desk

[TYPE 1-2]

4-Screws

(Not provided as parts of the product.)

Stand

Desk

7

ENGLISH

[TYPE 1-3]

4-Screws

(Not provided as parts of the product.)

Stand

Desk

• Screw: M5 x L (*L: Table depth + 8~10 mm)

ex) Table depth: 15 mm, Screw: M5 x L25

[TYPE 2-1]

2-Screws, 2-Washers, 2-Nuts

(provided as parts of the product.)

Stand

Desk

[TYPE 2-2]

2-Screws, 2-Washers, 2-Nuts

(provided as parts of the product.)

Stand

Desk

[TYPE 2-3]

2-Screws, 2-Washers, 2-Nuts

(provided as parts of the product.)

Stand

Desk

8

ENGLISH

Using the kensington security system

(Depending upon model)

The Kensington security system connector is

located at the rear of the TV. For more information

of installation and using, refer to the manual

provided with the Kensington security system

or visit http://www.kensington.com. Connect the

Kensington security system cable between the TV

and a table.

Securing the TV to a Wall (optional)

(Depending upon model)

1 Insert and tighten the eye-bolts or TV brackets

and bolts on the back of the TV.

- If there are bolts inserted at the eye-bolts

position, remove the bolts first.

2 Mount the wall brackets with the bolts to the

wall. Match the location of the wall bracket and

the eye-bolts on the rear of the TV.

3 Connect the eye-bolts and wall brackets tightly

with a sturdy rope or cable. Make sure to keep

the rope parallel to the flat surface.

• Make sure that children do not climb on or

hang on the TV.

• Use a platform or cabinet that is strong and

large enough to support the TV securely.

• Brackets, bolts, and ropes are optional. You

can obtain additional accessories from your

local dealer.

Mounting on a Wall

An optional wall mount can be used with your

LG Television. Consult with your local dealer for

a wall mount that supports the VESA standard

used by your TV model. Carefully attach the wall

mount bracket at the rear of the TV. Install the wall

mount bracket on a solid wall perpendicular to the

floor. If you are attaching the TV to other building

materials, please contact qualified personnel to

install the wall mount. Detailed instructions will

be included with the wall mount. We recommend

that you use an LG brand wall mount. The LG wall

mount is easy to adjust or to connect the cables.

When you do not use LG’s wall mount bracket,

use a wall mount bracket where the device is

adequately secured to the wall with enough space

to allow connectivity to external devices. If you are

using a non-adjustable mount, attach the mount

to the wall. Attach the cables to the TV first, then

attach the TV to the mount.

10 cm

(4 inches)

Make sure to use screws and wall mounts that

meet the VESA standard. Standard dimensions for

the wall mount kits are described in the following

table.

9

ENGLISH

Model

32LV560H

32LV570H

40LV560H

40LV570H

43LV560H

43LV570H

49LV560H

49LV570H

55LV560H

55LV570H

65LV570H

VESA (A x B) 200 x 200 300 x 300 300 x 300

Standard screw M6 M6 M6

Number of

screws

4 4 4

Wall mount

bracket

(optional)

LSW240B

MSW240

LSW350B

MSW240

LSW350B

A

B

• Remove the stand before installing the

TV on a wall mount by performing the

stand attachment in reverse.

• When using the wall mount, it is recommended

that you apply a piece of tape over the Stand

holes to prevent dust and bugs from entering

the holes. (Depending upon model)

stand hole

Connections (Notifications)

You can connect various external devices to the TV.

Supported external devices are: HD receivers, DVD

players, VCRs, audio systems, USB storage devices,

PC, gaming devices, and other external devices. For

more information on external device’s connection,

refer to the manual provided with each device.

• If you record a TV program on a DVD recorder or

VCR, make sure to connect the TV signal input

cable to the TV through a DVD recorder or VCR.

For more information about recording, refer to

the manual provided with the connected device.

• The external device connections shown may

differ slightly from illustrations in a manual.

• Connect external devices to the TV regardless

about the order of the TV port. If you connect a

gaming device to the TV, use the cable supplied

with the gaming device.

• If you connect a gaming device to the TV, use the

cable supplied with the gaming device.

• Refer to the external equipment’s manual for

operating instructions.

• In PC mode, there may be noise associated

with the resolution, vertical pattern, contrast

or brightness. If noise is present, change the PC

output to another resolution, change the refresh

rate to another rate or adjust the brightness and

contrast on the PICTURE menu until the picture

is clear.

• When connecting via a wired LAN, it is

recommended to use a CAT 7 cable. (Depending

upon model)

Connecting to an Antenna or Cable

Connect an antenna, cable, or cable box to watch

TV while referring to the following. The illustrations

may differ from the actual items and an RF cable is

optional.

• Make sure not to bend the copper wire of the RF

cable.

Copper wire

• Complete all connections between devices, and

then connect the power cord to the power outlet

to prevent damage to your TV.

• Use a signal splitter to use 2 TVs or more.

• DTV Audio Supported Codec: MPEG, Dolby

Digital.

10

ENGLISH

Other Connections

Connect your TV to external devices. For the best

picture and audio quality, connect the external

device and the TV with the HDMI cable.

• HDMI Audio Supported Format: Dolby Digital

(32 kHz / 44.1 kHz / 48 kHz), PCM (32 kHz / 44.1

kHz / 48 kHz / 96 kHz / 192 kHz) (Depending on

model)

• Use only with the 3 pole 3.5 mm stereo jack.

• Do not connect your headphones or earphones

to the port for connecting an external speaker.

Remote Control

(Some buttons and services may not be provided

depending upon models or regions.)

The descriptions in this manual are based on the

buttons on the remote control. Please read this

manual carefully and use the TV correctly.

To install batteries, open the battery cover, replace

batteries (1.5 V AAA) matching the and ends

to the label inside the compartment, and close the

battery cover. Failure to match the correct polarities

of the battery may cause the battery to burst or

leak, resulting in fire, personal injury, or ambient

pollution. To remove the batteries, perform the

installation actions in reverse. This remote uses

infrared light. When in use, it should be pointed in

the direction of the TV’s remote sensor.

A

(Power) Turns the TV on or off.

Not functional.

Selects the remote’s operating mode: TV.

Selects the remote’s operating mode: DVD.

Changes the input source.

Not functional.

Number button Enters numbers. Also supports

characters.

(Dash) Inserts a dash between numbers such as

2-1 and 2-2.

Tunes to the last channel or input viewed.

Adjusts the volume level.

Switches between Letter and Number

input modes.

Selects a closed caption.

Turns the TV off in a set amount of time.

Deletes letters and numbers.

Mutes all sounds.

Scrolls through the saved channels.

Moves to the previous or next screen.

11

ENGLISH

B

Displays and removes Pro:Centric

Application.

Shows information on the current program

through Pro:Centric Application.

Displays the program event according to

time scheduler of Pro:Centric Application.

Navigation button (up / down / left / right) Scrolls

through menus or options.

Selects menus or options and confirms your

input.

Returns to the previous screen.

Accesses the main menu.

Clears all on-screen displays and returns to

TV viewing.

These access special functions in some

menus.

, , , , Control buttons for media contents

Accesses the AV devices connected to the TV;

Opens the SIMPLINK menu.

Not functional.

Analog mode: Selects MTS sound (Mono, Stereo

or SAP) DTV mode: Changes the audio language.

Settings

To select picture mode

• PICTURE • Picture Mode

Select the picture mode optimized for the viewing

environment or the program.

• Vivid Heightens contrast, brightness and

sharpness to display vivid images.

• Standard Displays images in standard levels of

contrast, brightness and sharpness.

• APS APS (Auto power saving) mode reduces

power consumption by dimming control.

• Cinema / Game Displays the optimum picture

for a movie or a game.

• Sports Optimised picture mode for sports

matches. The pitch and kits are presented in

vibrant colours, with crystal-clear images even

for fast movements.

• Depending upon input signal, the available

range of picture modes may differ.

• Picture Mode change may modify Motion

Eye Care settings and it can affect energy

consumption.

To set additional picture options

• PICTURE • Picture Options

Adjusts detailed setting for images.

• Noise Reduction Eliminates noise in the picture.

• MPEG Noise Reduction Eliminates noise

generated while creating digital picture signals.

• Black Level Adjusts the brightness and contrast

of the screen to suit the black level of the input

picture by using the blackness (black level) of

the screen.

• Real Cinema Optimizes the screen for movie

viewing.

• Motion Eye Care Saves power consumption by

adjusting the brightness corresponding to the

movement of the image on the screen.

• Depending upon input signal or other picture

settings, the range of detailed items for

adjustment may differ.

12

ENGLISH

Licenses

Supported licenses may differ by model. For more

information about licenses, visit www.lg.com.

Manufactured under license from Dolby

Laboratories. Dolby, Dolby Vision, Dolby Audio,

and the double-D symbol are trademarks of

Dolby Laboratories.

The terms HDMI and HDMI High-Definition

Multimedia Interface, and the HDMI logo are

trademarks or registered trademarks of HDMI

Licensing LLC in the United States and other

countries.

This DivX Certified® device has passed rigorous

testing to ensure it plays DivX® video.

To play purchased DivX movies, first register your

device at vod.divx.com. Find your registration

code in the DivX VOD section of your device

setup menu.

DivX Certified® to play DivX® video up to HD

1080p, including premium content.

DivX®, DivX Certified® and associated logos are

trademarks of DivX, LLC and are used under

license.

Covered by DivX Patents 7,295,673; 7,515,710;

RE45,052; and others available at [www.divx.com/

patents]

Open Source Software Notice

Information

To obtain the source code under GPL, LGPL, MPL,

and other open source licenses, that is contained in

this product, please visit http://opensource.lge.com.

In addition to the source code, all referred license

terms, warranty disclaimers and copyright notices

are available for download.

LG Electronics will also provide open source code

to you on CD-ROM for a charge covering the cost

of performing such distribution (such as the cost of

media, shipping, and handling) upon email request

to [email protected]. This offer is valid for three

(3) years from the date on which you purchased

the product.

Updating Firmware

(Depending upon model)

You can update the firmware for the product by

downloading the latest firmware.

1 Download the latest firmware at partner.lge.

com. (Signing up for a membership and log-in

required)

2 Create a folder named “LG_DTV” or “lg_dtv” on a

USB memory device.

3 Move the downloaded file to the folder that you

have created on the USB memory device.

4 Connect the USB memory device to the USB

port on your TV.

5 When a pop-up window appears, start the

update by following the instructions.

13

ENGLISH

Troubleshooting

The software may be updated for improvement

in performance. The customer is responsible to

ensure the compatibility of their equipment with

any LG Electronics software. If needed, please

consult with LG Electronics and update new

software versions according to the guidance

provided by LG Electronics.

• Cannot control the TV with the remote control.

- Check if anything such as tape has been placed

over the receiver.

- Check if there is any obstacle between the

product and the remote control.

- Replace the batteries with new fresh ones.

• No image display and no sound is produced.

- Check if the product is turned on.

- Check if the power cord is connected to a wall

outlet.

- Check if there is a problem in the wall outlet by

connecting other products.

• The TV turns off suddenly.

- Check the power control settings.

The power supply may be interrupted.

- Check if the Off Time / Sleep Timer feature is

activated in the TIME settings.

- If there is no signal while the TV is on, the TV

will turn off automatically after 15 minutes of

inactivity.

• Abnormal Display

- If the TV feels cold to the touch, there may

be a small flicker when it is turned on. This is

normal; there is nothing wrong with TV. Some

minute dot defects may be visible on the

screen, appearing as tiny red, green, or blue

spots. However, they have no adverse effect on

the TV’s performance. Avoid touching the LCD

screen or holding your finger(s) against it for

long periods of time. Doing so may produce

some temporary distortion effects on the

screen.

- This panel is an advanced product that contains

millions of pixels. In a very few cases, you could

see fine dots on the screen while you’re viewing

the TV. Those dots are deactivated pixels and

do not affect the performance and reliability

of the TV.

- Displaying a still image for a prolonged period

of time may cause an image sticking. Avoid

displaying a fixed image on the TV screen for a

extended length of time.

• Generated Sound

- Cracking noise A cracking noise that occurs

when watching or turning off the TV is

generated by plastic thermal contraction

due to temperature and humidity. This noise

is common for products where thermal

deformation is required.

- Electrical circuit humming/panel buzzing

A low level noise is generated from a high-

speed switching circuit, which supplies a

large amount of current to operate a product.

It varies depending upon the product.

This generated sound does not affect the

performance and reliability of the product.

Specifications

Product specifications may be changed without

prior notice due to upgrade of product functions.

Television System

ATSC, NTSC-M, 64 & 256 QAM

Program Coverage

VHF 2-13, UHF 14-69, DTV 2-69, CATV 1-135,

CADTV 1-135

External Antenna Impedance

75 Ω

Environment condition

• Operating Temperature

0 °C to 40 °C

• Operating Humidity

Less than 80 %

• Storage Temperature

-20 °C to 60 °C

• Storage Humidity

Less than 85 %

14

ENGLISH

RGB (PC), HDMI (PC) supported mode

(Use HDMI IN 1 for PC mode)

Resolution

Horizontal

Frequency (kHz)

Vertical

Frequency (Hz)

640 x 350 31.46 70.09

720 x 400 31.46 70.08

640 x 480 31.46 59.94

800 x 600 37.87 60.31

1024 x 768 48.36 60.00

1152 x 864 54.34 60.05

1360 x 768 47.71 60.01

1280 x 1024 * 63.98 60.02

1920 x 1080 * 67.50 60.00

* FHD : 40/43/49/55LV560H,

40/43/49/55/65LV570H

HDMI (DTV) supported mode

Resolution

Horizontal

Frequency (kHz)

Vertical

Frequency (Hz)

640 x 480p

31.46 59.94

31.50 60.00

720 x 480p

31.47 59.94

31.50 60.00

1280 x 720p

44.96 59.94

45.00 60.00

1920 x 1080i

33.72 59.94

33.75 60.00

1920 x 1080p

26.97 23.97

27.00 24.00

33.71 29.97

33.75 30.00

67.43 59.94

67.50 60.00

Supported Photo Formats

• Category: 2D (.jpeg, .jpg, .jpe)

[Available file type]

SOF0: Baseline,

SOF1: Extend Sequential,

SOF2: Progressive

[Photo size]

Minimum: 64

x 64,

Maximum:

Normal Type: 15,360 (W) x 8,640 (H),

Progressive Type: 1,920 (W) x 1,440 (H)

• Category: BMP

[Available file type] .bmp

[Photo size] Minimum: 64 x 64,

Maximum: 9,600 x 6,400

• Category: PNG

[Available file type] Interlace, Non-Interlace

[Photo size]

Minimum: 64 x 64,

Maximum: Interlace: 1,200 x 800,

Non-Interlace: 9,600 x 6,400

• BMP and PNG format files may be slower to

display than JPEG.

• Non-standard photo/image file may not be

displayed.

Supported Audio Formats

• File type: mp3

[Bit rate] 32 Kbps - 320 Kbps

[Sample freq.] 16 kHz - 48 kHz

[Support] MPEG-1, MPEG-2, Layer2, Layer3

• File Type: AAC

[Bit rate] Free Format

[Sample freq.] 8 kHz ~ 48 kHz

[Support] ADIF, ADTS

• File Type: M4A

[Bit rate] Free Format

[Sample freq.] 8 kHz ~ 48 kHz

[Support] MPEG-4

• File Type: OGG

[Bit rate] Free Format

[Sample freq.] ~ 48 kHz

[Support] Vorbis

• File Type: WMA

[Bit rate] 128 Kbps ~ 320 Kbps

[Sample freq.] 8 kHz ~ 48 kHz

[Support] WMA7, 8, 9 Standard

• File Type: WMA 10 Pro

[Bit rate] ~ 768 Kbps

[Channel / Sample freq.]

M0: up to 2 Channel / 48 kHz (Except LBR mode),

M1: up to 5.1 Channel / 48 kHz,

M2: up to 5.1 Channel / 96 kHz

[Support] WMA 10 Pro

15

ENGLISH

Supported Video Formats

Maximum: 1,920 x 1,080 @ 30p (only Motion JPEG

640 x 480 @ 30p)

• .asf, .wmv

[Video] MPEG-2, MPEG-4 Part2, DivX3.11, DivX4,

DivX5, DivX6, XViD, H.264/AVC, VC1(WMV3, WVC1),

MP43

[Audio] WMA Standard, WMA9(Pro), MP3, AAC,

AC3, 3D WMV Single Stream

• .divx, .avi

[Video] MPEG-2, MPEG-4 Part2, DivX3.11, DivX4,

DivX5, DivX6, XViD, H.264/AVC

[Audio] HE-AAC, LPCM, ADPCM, MPEG-1 Layer I,

MPEG-1 Layer II, Dolby Digital, MPEG-1 Layer III

(MP3), *DTS

• .ts, .trp, .tp, .mts, .m2ts

[Video] H.264/AVC, MPEG-2, AVS, VC1

[Audio] MPEG-1 Layer I, MPEG-1 Layer II, MPEG-1

Layer III (MP3), Dolby Digital, Dolby Digital Plus,

AAC, HE-AAC, *DTS

• .vob

[Video] MPEG-1, MPEG-2

[Audio] Dolby Digital, MPEG-1 Layer I, MPEG-1

Layer II, DVD-LPCM

• .mp4, .m4v, .mov

[Video] MPEG-2, MPEG-4 Part2, DivX3.11, DivX4,

DivX5, DivX6, XVID, H.264/AVC

[Audio] AAC, MPEG-1 Layer III (MP3), *DTS

• .mkv

[Video] MPEG-2, MPEG-4 Part2, DivX3.11, DivX4,

DivX5, DivX6, XVID, H.264/AVC

[Audio] HE-AAC, Dolby Digital, MPEG-1 Layer III

(MP3), *DTS, LPCM

• motion JPEG

[Video] MJPEG

[Audio] LPCM, ADPCM

• .mpg, .mpeg, .mpe

[Video] MPEG-1, MPEG-2

[Audio] MPEG-1 Layer I, MPEG-1 Layer II, Dolby

Digital, LPCM

• .dat

[Video] MPEG-1, MPEG-2

[Audio] MP2

• .flv

[Video] Sorenson H.263, H.264/AVC

[Audio] MP3, AAC, HE-AAC

• .3gp, .3gp2

[Video] H.264/AVC, MPEG-4 Part2

[Audio] AAC, AMR(NB/WB)

*DTS: Depending upon model

16

ENGLISH

Regulatory

FCC NOTICE

(For USA)

This equipment has been tested and found to

comply with the limits for a Class B digital device,

pursuant to Part 15 of the FCC Rules. These limits

are designed to provide reasonable protection

against harmful interference in a residential

installation. This equipment generates, uses

and can radiate radio frequency energy and, if

not installed and used in accordance with the

instructions, may cause harmful interference

to radio communications. However, there is no

guarantee that interference will not occur in a

particular installation. If this equipment does

cause harmful interference to radio or television

reception, which can be determined by turning

the equipment off and on, the user is encouraged

to try to correct the interference by one or more of

the following measures:

- Reorient or relocate the receiving antenna.

- Increase the separation between the

equipment and the receiver.

- Connect the equipment to an outlet on a circuit

different from that to which the receiver is

connected.

- Consult the dealer or an experienced radio/TV

technician for help.

This device complies with part 15 of the FCC

Rules. Operation is subject to the following two

conditions: (1) this device may not cause harmful

interference and (2) this device must accept any

interference received, including interference that

may cause undesired operation of the device. Any

changes or modifications in construction of this

device which are not expressly approved by the

party responsible for compliance could void the

user’s authority to operate the equipment.

FCC Radio Frequency Interference

Requirements (for UNII devices)

High power radars are allocated as primary users

of the 5.25 to 5.35 GHz and 5.65 to 5.85 GHz bands.

These radar stations can cause interference with

and/or damage this device. This device cannot be

co-located with any other transmitter.

FCC RF Radiation Exposure Statement

[For having wireless function (WLAN, Bluetooth,...)]

This equipment complies with FCC radiation

exposure limits set forth for an uncontrolled

environment. This transmitter must not be

colocated or operating in conjunction with any

other antenna or transmitter. This equipment

should be installed and operated with minimum

distance 20 cm (7.8 inches) between the radiator

and your body. Users must follow the specific

operating instructions for satisfying RF exposure

compliance.

Industry Canada Statement

(For Canada)

[For having wireless function (WLAN, Bluetooth,...)]

This device complies with Industry Canada’s

applicable licence-exempt RSSs. Operation is

subject to the following two conditions:

(1) This device may not cause interference; and

(2) This device must accept any interference,

including interference that may cause undesired

operation of the device.

IC Radiation Exposure Statement

(For Canada)

[For having wireless function (WLAN, Bluetooth,...)]

This equipment complies with IC radiation

exposure limits set forth for an uncontrolled

environment. This equipment should be installed

and operated with minimum distance 20 cm (7.8

inches) between the antenna & your body.

NOTE: THE MANUFACTURER IS NOT RESPONSIBLE

FOR ANY RADIO OR TV INTERFERENCE CAUSED

BY UNAUTHORIZED MODIFICATIONS TO THIS

EQUIPMENT. SUCH MODIFICATIONS COULD

VOID THE USER’S AUTHORITY TO OPERATE THE

EQUIPMENT.

17

ENGLISH

(For Canada)

[For product having the wireless function using 5

GHz frequency bands]

• The device for operation in the band 5150–5250

MHz is only for indoor use to reduce the

potential for harmful interference to co-channel

mobile satellite systems;

• For devices with detachable antenna(s), the

maximum antenna gain permitted for devices in

the bands 5250-5350 MHz and 5470-5725 MHz

shall be such that the equipment still complies

with the e.i.r.p. limit;

• For devices with detachable antenna(s), the

maximum antenna gain permitted for devices in

the band 5725-5850 MHz shall be such that the

equipment still complies with the e.i.r.p. limits

specified for point-to-point and non-point-to-

point operation as appropriate; and

• The worst-case tilt angle(s) necessary to remain

compliant with the e.i.r.p. elevation mask

requirement set forth in Section 6.2.2(3) shall be

clearly indicated. (devices operating in the band

5250-5350 MHz with a maximum e.i.r.p. greater

than 200 mW)

• High-power radars are allocated as primary users

(i.e. priority users) of the bands 5250–5350 MHz

and 5650–5850 MHz and that these radars could

cause interference and/or damage to LE-LAN

devices.

NOTE TO CABLE/TV INSTALLER

(For USA and Canada)

This reminder is provided to call the CATV system

installer’s attention to Article 820-40 of the

National Electric Code (U.S.A.). The code provides

guidelines for proper grounding and, in particular,

specifies that the cable ground shall be connected

to the grounding system of the building, as close

to the point of the cable entry as practical.

WARNING!

Never place a television set in an unstable

location. A television set may fall, causing serious

personal injury or death. Many injuries, particularly

to children, can be avoided by taking simple

precautions such as:

• Using cabinets or stands recommended by the

manufacturer of the television set.

• Only using furniture that can safely support the

television set.

• Ensuring the television set is not overhanging

the edge of the supporting furniture.

• Not placing the television set on tall furniture

(for example, cupboards or bookcases) without

anchoring both the furniture and the television

set to a suitable support.

• Not placing the television set on cloth or other

materials that may be located between the

television set and supporting furniture.

• Educating children about the dangers of

climbing on furniture to reach the television set

or its controls.

If your existing television set is being retained

and relocated, the same considerations as above

should be applied.

Symbols

Refers to alternating current(AC).

Refers to direct current(DC).

Refers to class II equipment.

Refers to stand-by.

Refers to “ON” (power).

Refers to dangerous voltage.

18

ENGLISH

IR OUT Using Guide

Suitable / Not Recommend remote-controller data format

Item Data format code Note

Suitable Data Format

NEC, Toshiba Full Repeat Code Format

Single : Enable

Repeat : Enable

Philips RC5, RC6 Code Format

Zenith Code Format

Not Recommend Data Format

Matsushita, RCA Code Format Single : Enable

Repeat : Disable

Sony 12/15/20 bit, Mitsubishi Code Format

Sharp, JVC, R-step, Philips RCMM, RECS-80,

XMP Code Format

Single : Disable

Repeat : Disable

IR Receiver specifications

Carrier frequency 37.9 KHz

Peak Wavelength 940 nm

Minimum burst length Min. 300 us

Minimum gap time is required of Min. 350 us

Data word length Max. 100 ms

Minimum gap time in the data stream is needed of Min. 50 ms

Parameter Symbol Conditions Min Typ Max Unit

High Level Out Pulse Width Twh

Burst Wave = 600

Period = 1.2

400 - 800

Low Level Out Pulse Width Twl 400 - 800

If not use the remote-controller with data formats recommended, IR output signals will be suppressed

automatically by IR receiver. In this case, LG does not guarantee IR working function. To make sure of

this matter, here are two methods as below.

- Use the remote-controller with suitable data formats.

- Use the IR dongle receiver of the set-top box.

LG Customer Information Center

For inquires or comments, visit www.lg.com or call;

1-855-286-2456

CANADA

1-888-865-3026

USA, Commercial User

The model and serial numbers of the TV are located

on the back and on one side of the TV. Record them

below should you ever need service.

MODEL

SERIAL

Declaration of Conformity

Trade Name LG

Model 32LV560H-UA, 32LV570H-UA,

40LV560H-UA, 40LV570H-UA,

43LV560H-UA, 43LV570H-UA,

49LV560H-UA, 49LV570H-UA,

55LV560H-UA, 55LV570H-UA,

65LV570H-UA

Responsible

Party

LG Electronics Inc.

Address 1000 Sylvan Ave. Englewood

Cliffs NJ 07632 U.S.A

TEL 201-266-2534

La page charge ...

LG 49LV570H Le manuel du propriétaire

LG 49LV570H Le manuel du propriétaire

dans d''autres langues

Documents connexes
