MPMan PC39 HD Mode d'emploi

PC39HD

Page of 41 2

1.PARTS OF THE CAMCORDER 5

2.PREPARING FOR USING 5

I

NSTALLING THE BATTERY 5

C

HARGING THE BATTERY 7

I

NSERTING THE MEMORY CARD 6

S

ETTING THE LANGUAGE 8

S

ETTING THE DATE AND TIME 10

M

ONITOR SCREEN DISPLAY 11

3.USING THIS CAMCORDER 14

T

URNING THE CAMCORDER ON AND OFF 14

C

HANGE THE MODE 15

R

ECORDING A VIDEO CLIP 15

T

AKING STILL IMAGES 16

U

SING THE SELF-TIMER 17

U

SING THE FLASH 18

R

ECORDING AUDIO 19

4.USING THE MENU IN RECORD MODE 19

M

ENU IN CAPTURE MODE 19

M

ENU IN VIDEO MODE 22

Page of 41 3

SETUP MENU 23

5.PLAYBACK 25

P

LAYING BACK MOVIE CLIPS 25

P

LAYBACK STILL IMAGE 26

P

LAYING BACK AUDIO FILES 26

O

THER FUNCTION IN PLAYBACK MODE 27

6. MAKING CONNECTIONS 29

C

ONNECTING THE CAMCORDER TO A TV 29

C

ONNECTING THE CAMCORDER TO A HDTV 30

C

ONNECTING THE CAMCORDER TO A PC 32

7. SOFTWARE INSTALLATION 33

I

NSTALLING THE SOFTWARE 33

8. TROUBLESHOOTING 38

9. TECHNICAL SPECIFICATIONS 39

Page of 41 4

Thank you for purchasing this product. Please read these operating

instructions carefully in order to use the digital video camera correctly.

Keep the instructions in a safe place after reading so that you can refer to

them later.

Precautions

Before using the camcorder, please ensure that you read and understand

the safety precautions described below.

• Do not try to open the case of the camcorder or attempt to modify this

camcorder in any way. Maintenance and repairs should be carried out

only by authorized service providers.

• Keep the camcorder away from water and other liquids. Do not use the

camcorder with wet hands. Never use the camcorder in the rain or snow.

Moisture creates the danger of electric shock.

• Use only the recommended power accessories. Use of power sources not

expressly recommended for this equipment may lead to overheating,

distortion of the equipment, fire, electrical shock or other hazards.

Page of 41 5

1. Parts of the camcorder

1: Zoom switch

2: Capture /voice

record button

3: Power button

4: Power LED

5: Video record mode

6: Charging LED

7: Mode dial

8: AV out jack

9: Earphone jack

10: DC in jack

11: USB Jack

12: HDMI jack

13 : Display button

14: Speaker

15: LCD screen

16: Menu button

Page of 41 6

17:Joystick/ OK button

18: Delete/ Flash button

19: Compensating LED

20: Flash strobe

21: Microphone

22: Lens

23: Battery cover

24: Tripod socket

2. Preparing for using

Installing the Battery

1. Slide the battery cover.

2. Place the accessory lithium-ion

battery into the compartment. Note

that the metallic contacts must be

Page of 41 7

aligned with the contacts in the compartment.

3. After the battery is properly installed, replace the battery cover.

Charging the battery

Please charge the battery at least 8 hours for first time use.

a) Power OFF; connect the AC-adaptor to the camcorder DC in jack.

b) Plug the AC-adaptor to the electrical outlet.

c) Charging starts when charging LED turns BLUE. The charge indicator

light turns OFF when charging is

completed.

d) Disconnect the camcorder.

Inserting the Memory Card

This camcorder has an internal memory of

32MB, it can only record a few pictures or

movie clips. If you want record more you have to use a SD or MMC card

Page of 41 8

(The MAX.SD/MMC card that this camcorder could support is up to

16GB ).Turn off the camcorder before inserting or removing the memory

card. Be sure to orient the card correctly when inserting it. Never try to

force the memory card into the slot when you feel resistance. The memory

card has a write protect switch, which used to protect data from accidental

deletion. Therefore, whenever you want to record, format or delete files in

the SD card, disable the write protection beforehand.

1. Turn off the camcorder.

2. Slide the battery cover and then you will see the SD card slot.

3. Insert the memory card as illustrated.

4. Close the battery cover.

• To release the memory card press the edge of the card gently.

Format the memory card

It is important to format the memory card when it is the first time you use

this camcorder. All data will be deleted including protected files. Be sure to

download important files to your computer before formatting.

1: Turn the power on, and set the camcorder to the Setup Menu.(See the

details on page 22 )

Page of 41 9

2: Push the joystick upward or downward to select [Format] then push the

joystick rightward to launch the submenu.

3: Push the joystick upward or downward to select the item [YES] and then

press the OK button to erase all data.

Setting the Language

When using the camcorder for the first time after purchasing it, be sure to

choose a language and set the date & time before using the camcorder.

1: Turn the power on, and set the camcorder to the Setup Menu.(See the

details on page 22 )

2: Push the joystick upward or downward to select [Language] then move

the joystick rightward to launch the submenu.

3: Push the joystick upward or downward to select the desired language

and then press the OK button to confirm the setting.

4: Press the MENU button to close the menu.

Page of 41 10

Setting the date and time

1: Turn the power on, and set the camcorder to the Setup

Menu. (See the details on page 22)

2: Push the joystick upward or downward to select

[Date/Time] then push the joystick rightward to launch

the submenu: Date Format, Date Setup.

3: Select a date format by using the joystick. And then

select [Date Setup].

4: Push the joystick upward or downward to change the highlighted value.

Push the joystick leftward or rightward to move the cursor between

settings.

5: Press the OK button to confirm the setting.

6: Press the MENU button to close the menu.

• The date and time can be only added to still images by setting the

function [Date Stamp] in capture menu.

Page of 41 11

Monitor screen display

Capture

Page of 41 12

Video record mode

Page of 41 13

Playback mode

Page of 41 14

3. Using this camcorder

Turning the Camcorder On and Off

1. Open the LCD panel to power on the camcorder and close the L CD

panel to turn off the camcorder.

2. You can also press the POWER button to turn on the camcorder and

press it again to turn the camcorder off.

To save battery power, the LCD monitor automatically turns off 30 seconds

after the last control accessed (factory-preset setting). Press any button

other than the power button to turn on the LCD monitor. After the power

saving function has been active for the set time, the power will turn off

completely. Press the Power button to power the camera back on. You can

change the power-off time by setting the function [Auto off] in the Setup

menu.

Page of 41 15

Change the record mode

There are four record modes in this camcorder.

Rotate the mode dial to set the camcorder to

different mode.

Recording a video clip

1: Turn on the camcorder and set the camcorder to video record mode

(

).

2: Zooming:

Display Title Description

Capture mode For taking still photos.

Video mode For recording movie clips.

Audio mode For recording audio files.

Playback mode For playback record files.

Page of 41 16

Moving the Zoom switch rightward or leftward to zoom in or zoom out the

screen.

The value of magnification level appears on the LCD monitor.

3: Press the VIDEO RECORD button to start recording.

4: Press the VIDEO RECORD again to end the recording. If the memory is

full the video camera will stop recording automatically.

• On the upper of the LCD monitor displays the recorded time.

• When the light is insufficient press the FLASH/DELETE button to

turn on the compensating LED and when the light is enough press the

FLASH/DELETE button to turn off the compensating LED.

Taking still images

1. Set the camcorder to capture mode, the icon appears on the LCD

screen.

2. Zooming:

Moving the Zoom switch rightward or leftward to zoom in or zoom out

the screen.

The value of magnification level appears on the LCD

monitor.

3． Hold the camcorder steady and then press the CAPTURE/VIOCE

Page of 41 17

RECORD button down to take a picture.

Using the Self-timer

Use the self-timer to set a delay from the time the shutter button is pressed

to the time the image is shot.

1: Turn the power on, and set the camcorder to the Capture mode.

2: Press the MENU button to display the capture menu.

3: Using the joystick to select the item [Self Timer]. And move the joystick

rightward to launch the submenu:

Disable: Don’t use self-timer.

10 Seconds: The shutter release will delay for 10 seconds.

20 Seconds: The shutter release will delay for 20 seconds.

4: Move the joystick upward or downward to select the self timer.

5: Press the OK button to confirm the setting, and then press the MENU

button to close the menu.

6: Press the CAPTURE/ VIOCE REICORD button to take picture.

Page of 41 18

Using the Flash

The flash is not only for taking pictures when there is insufficient light, but

also for when the subject is in shade or with backlight conditions. Pressing

the Delete/flash button cycles your camera through the various flash

modes. The flash will not activate during continuous shooting or movie

recording.

1: Set the camcorder to the Capture mode.

2: Press the FLASH/DELETE button to change the flash mode.

Each time the flash button is pressed, the flash icon changes.

Auto: Automatically turn on/of

Flash on: Force on the flash

Flash off: Force off the flash

3: Press the SHUTTER button to take a picture.

• When the battery level is low the flash strobe will not work.

• The LCD screen is black when the flash is charging. The next image

can be shot only when charging is completed.

Page of 41 19

Recording audio

1: Turn the camcorder on and set it to audio record mode.

2: Press the CAPTURE/VIOCE RECORD button to start recording.

3: Press the CAPTURE/VIOCE RECORD again to end the recording. If the

memory is full the video camera will stop recording automatically.

• On the center of the LCD monitor displays the recorded time.

• There is no menu in audio record mode.

4.Using the menu in record mode

When a menu is displayed, the joystick is used to make the desired setting.

The audio record mode doesn’t have a menu.

Menu in capture mode

1: Turn on the camcorder and set it to capture

mode.

2: Press the MENU button to display the menu.

3: Move the joystick upward or downward to select an item.

Page of 41 20

4: Push the joystick rightward to enter the submenu.

5: Use the joystick to select the desired item.

6: Press the OK button to confirm the setting.

7: Press the MENU button to close the menu.

Capture menu list

Menu item Function

Resolution There are five options for choice:

[12M]/[8M] /[5M]/[3M]/[0.3M].

Quality Select a lower image quality to decrease the image size in

order to capture more images. There are three options for

choice:[Super] /[Fine] /[Normal].

White

Balance

Adjust the white balance to suit different light sources.

There five items for option: [Auto]/[Daylight]/ [Cloudy] /

[Fluorescent] / [Tungsten].

Color

Effect

Set the color effect to add a color tone to the picture.

[color]: Reflects the true color of the object.

[Sepia]: Adds a sepia color tone to the picture.

La page charge ...

MPMan PC39 HD Mode d'emploi

MPMan PC39 HD Mode d'emploi

dans d''autres langues

Documents connexes

Autres documents
