Wireless Audio - Soundbar

Imagine the possibilities

Thank you for purchasing this Samsung product.

To receive more complete service, please register your product at

www.samsung.com/register

User manual

HW-J370

Wireless Subwoofer (PS-WJ470)

Wireless Receiver Module (SWA-7000S)

HW-J370-ZC_ENG_0319.indd 1HW-J370-ZC_ENG_0319.indd 1 2015-03-19  1:15:592015-03-19  1:15:59

GETTING STARTED

FEATURES

GETTING STARTED

Samsung Remote App

Hold the control of your Soundbar in the palm of your

hand with an Android smart device and the Samsung

Audio Remote app. This convenient app lets you control

all the Soundbar's basic functions such as power,

volume, and the media controls, as well as custom

functions such as the equalizer setting.

TV SoundConnect

Connect your TV and Soundbar easily through Bluetooth

with TV SoundConnect. The absence of trailing wires

between the Soundbar and TV allows you to showcase

the slim and sleek design of both systems, while

maintaining a clean look in your living environment. Easily

control the Soundbar and TV from a single TV remote.

USB Host Support

You can connect and play music files from external USB

storage devices such as MP3 players, USB flash

memory, etc. using the Soundbar's USB HOST function.

Bluetooth Function

You can connect a Bluetooth device to the Soundbar

and enjoy music with high quality stereo sound, all

without wires!

LICENSES

Manufactured under license from Dolby Laboratories.

Dolby and the double-D symbol are trademarks of Dolby

Laboratories.

For DTS patents, see http://patents.dts.com.

Manufactured under license from DTS Licensing Limited.

DTS, the Symbol, & DTS and the Symbol together are

registered trademarks, and DTS 2.0 Channel is a

HW-J370-ZC_ENG_0319.indd 2HW-J370-ZC_ENG_0319.indd 2 2015-03-19  1:16:102015-03-19  1:16:10

ENG

GETTING STARTED

SAFETY INFORMATION

SAFETY WARNINGS

TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE THE COVER (OR BACK).

NO USER-SERVICEABLE PARTS ARE INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

CAUTION

RISK OF ELECTRIC SHOCK.

DO NOT OPEN.

The lighting flash and arrowhead within the

triangle indicates that there is dangerous voltage

Inside the product.

The explanation point within the triangle

indicates that there are important instructions

accompanying the product.

WARNING

• To reduce the risk of fire or electric shock, do not expose this appliance to rain or moisture.

• To prevent injury, this apparatus must be securely attached to the floor/wall in accordance with the installation

instructions.

CAUTION

• Do not expose this apparatus to dripping or splashing. Do not put objects filled with liquids, such as vases on the

apparatus.

• To turn this apparatus off completely, you must pull the power plug out of the wall socket. Consequently, the power

plug must be easily and readily accessible at all times.

This Class B digital apparatus complies with Canadian ICES-003.

This device complies with Industry Canada licenseexempt RSS standard(s). Operation is subject to the following

two conditions: (1) this device may not cause interference, and (2) this device must accept any interference,

including interference that may cause undesired operation of the device.

Important Safety Instructions

Read these operating instructions carefully before using the unit. Follow all the safety instructions listed below. Keep

these operating instructions handy for future reference.

1) Read these instructions.

2) Keep these Instructions.

3) Heed all warnings.

4) Follow all instructions.

5) Do not use this apparatus near water.

6) Clean only with dry cloth.

7) Do not block any ventilation openings. Install in

accordance with the manufacturer's instructions.

8) Do not install near any heat sources such as

radiators, heat registers, stoves, or other

apparatus (including amplifiers) that produce

heat.

9) Do not defeat the safety purpose of the polarized

or grounding-type plug. A polarized plug has two

blades with one wider than the other. A

grounding type plug has two blades and a third

grounding prong. The wide blade or the third

prong are provided for your safety. If the provided

plug does not fit into your outlet, consult an

electrician for replacement of the obsolete outlet.

10) Protect the power cord from being walked on or

pinched particularly at plugs, convenience

receptacles, and the point where they exit from

the apparatus.

11) Only use attachment/accessories specified by

the manufacturer.

12) Use only with the cart, stand,

tripod, bracket, or table specified

by the manufacturer, or sold with

the apparatus. When a cart is

used, use caution when moving

the cart/apparatus combination to

avoid injury from tip-over.

13) Unplug this apparatus during lightning storms or

when unused for long periods of time.

14) Refer all servicing to qualified service personnel.

Servicing is required when the apparatus has

been damaged in any way, such as when the

power-supply cord or plug is damaged, liquid

has been spilled or objects have fallen into the

apparatus, the apparatus has been exposed to

rain or moisture, does not operate normally, or

has been dropped.

HW-J370-ZC_ENG_0319.indd 3HW-J370-ZC_ENG_0319.indd 3 2015-03-19  1:16:102015-03-19  1:16:10

GETTING STARTED

PRECAUTIONS

Ensure that the AC power supply in your house complies with the power requirements listed on the identification

sticker located on the back of your product. Install your product horizontally, on a suitable base (furniture), with enough

space around it for ventilation (3~4 inches). Make sure the ventilation slots are not covered. Do not place the unit on

amplifiers or other equipment which may become hot. This unit is designed for continuous use. To fully turn off the

unit, disconnect the AC plug from the wall outlet. Unplug the unit if you intend to leave it unused for a long period of

time.

3.9 inch 3.9 inch

2.7 inch

3.9 inch

During thunderstorms, disconnect the AC plug from the

wall outlet. Voltage peaks due to lightning could damage

the unit.

Protect the product from moisture (i.e. vases), and

excess heat (e.g. a fireplace) or equipment creating

strong magnetic or electric fields. Unplug the power

cable from the AC wall socket if the unit malfunctions.

Your product is not intended for industrial use. It is for

personal use only. Condensation may occur if your

product has been stored in cold temperatures. If

transporting the unit during the winter, wait approximately

2 hours until the unit has reached room temperature

before using.

Do not expose the unit to direct sunlight or other heat

sources. This could lead to overheating and cause the

unit to malfunction.

The battery used with this product contains chemicals

that are harmful to the environment. Do not dispose of

the battery in the general household trash. Do not

expose the battery to excess heat, direct sunlight, or fire.

Do not short circuit, disassemble, or overheat the battery.

Danger of explosion if the battery is replaced incorrectly.

Replace only with the same or equivalent type.

uri

thu

nde

rstorms

dis

connect t

plu

o not expose

nit

rect s

unl

igh

toro

WARNING: DO NOT INGEST BATTERY. CHEMICAL BURN HAZARD. The remote control supplied with

this product contains a coin/button cell battery. If the coin/button cell battery is swallowed, it can cause

severe internal burns in just 2 hours and can lead to death. Keep new and used batteries away from

children. If the battery compartment does not close securely, stop using the remote and make sure to

keep it away from children. If you think the battery might have been swallowed or placed inside any part of the body,

seek immediate medical attention.

HW-J370-ZC_ENG_0319.indd 4HW-J370-ZC_ENG_0319.indd 4 2015-03-19  1:16:102015-03-19  1:16:10

ENG

GETTING STARTED

Figures and illustrations in this User Manual are

provided for reference only and may differ from actual

product appearance.

CONTENTS

2 GETTING STARTED

2 Features

3 Safety Information

6 What’s Included

7 DESCRIPTIONS

7 Top / Front Panel

8 Rear / Bottom Panel

9 Remote Control

11 INSTALLATION

11 Installing the Wall Mount

11 Installation Precautions

12 Installing the Bracket without Referring to the

Wall-Mount Installation Guide

13 Detaching the Wall Mount

14 CONNECTIONS

14 Connecting the Subwoofer and

SWA-7000S to the Main Unit

15 Connecting the Surround Speakers

16 Connecting to a TV

16 Connecting to a TV Using a Digital Optical

Cable

17 TV SoundConnect

19 Connections with External Devices

19 AUX Cable

19 Optical Cable

20 USB

22 FUNCTIONS

22 Input Mode

23 Bluetooth

26 Software Update

27 TROUBLESHOOTING

27 Troubleshooting

28 APPENDIX

28 Specifications

HW-J370-ZC_ENG_0319.indd 5HW-J370-ZC_ENG_0319.indd 5 2015-03-19  1:16:112015-03-19  1:16:11

GETTING STARTED

WHAT’S INCLUDED

BEFORE READING THE USER’S MANUAL

Note the following terms before reading the user manual.

+ Icons used in this manual

Icon Term Definition

Caution

Indicates a situation where a function does not operate or settings may be canceled.

Note

Indicates tips or instructions on the page that help you operate a function.

Check for the supplied accessories shown below.

Remote Control /

Lithium Battery (3V : CR2032)

Power Cord : 3EA DC Adapter Optical Cable

(Wall Mount L)

(Wall Mount R)

USB Cable

User Manual /

Quick Guide

Bracket-Wall Mount

Holder-Screw 1: 2EA Holder-Screw 2: 2EA Wall Mount Guide

● The appearance of the accessories may differ slightly from the illustrations above.

● Use the dedicated USB cable to connect external USB devices to the unit.

+ Speaker Components

Surround Speaker : 2EA Subwoofer Speaker Cable : 2EA

Wireless Receiver

Module (SWA-7000S)

HW-J370-ZC_ENG_0319.indd 6HW-J370-ZC_ENG_0319.indd 6 2015-03-19  1:16:112015-03-19  1:16:11

ENG

DESCRIPTIONS

TOP / FRONT PANEL

(Power) Button

Turns the power on and off.

VOL. - / +

Controls the volume level.

The numeric value of the volume level appears in

the front panel display.

Display

Displays the current mode.

● If there is no input from the product or

remote control for 25 seconds, the display

will dimmer automatically.

(Source) Button

Selects the D.IN, AUX, BT, TV, or USB

input.

● While the unit is powered on,

pressing the

(Source) button

for more than 3 seconds sets the

button to act as the

( Mute)

button. To cancel the

( Mute)

button setup, press the

(Source) button for more than 3

seconds again.

● When you plug in the AC cord, the power button will begin working in 4 to 6 seconds.

● When you turn on this unit, there will be a 4 to 5 second delay before it produces sound.

● If you want to enjoy sound only from the Soundbar, you must turn off the TV's speakers in the Audio Setup

menu of your TV. Refer to the owner's manual supplied with your TV.

DESCRIPTIONS

HW-J370-ZC_ENG_0319.indd 7HW-J370-ZC_ENG_0319.indd 7 2015-03-19  1:16:132015-03-19  1:16:13

DESCRIPTIONS

REAR / BOTTOM PANEL

AUX IN

OPTICAL IN

(USB Port)

Connect USB devices here to play

files on the devices.

OPTICAL IN (D.IN)

Connect to the digital (optical) output

of an external device.

AUX IN

Connect to the Analog output of

an external device.

DC 24V (Power Supply In)

Connect the DC power adaptor to

the power supply jack, and then

connect the AC power adaptor

plug to a wall outlet.

LABEL

● When disconnecting the power cable of the AC power adaptor from a wall outlet, pull the plug.

Do not pull the cable.

● Do not connect this unit or other components to an AC outlet until all connections between components

are complete.

HW-J370-ZC_ENG_0319.indd 8HW-J370-ZC_ENG_0319.indd 8 2015-03-19  1:16:142015-03-19  1:16:14

ENG

DESCRIPTIONS

REMOTE CONTROL

AUTO POWER

Press the AUTO POWER button. Each time the button is pressed, the selection

changes as follows : OFF - POWER LINK  ON - POWER LINK.

* Auto Power Link

Synchronizes the Soundbar to a connected Optical source via the Optical

jack so it turns on automatically when you turn on your TV.

(See page 16)

Repeat

Press to set the Repeat function during music playback from a USB device.

OFF - REPEAT : Cancels Repeat Playback.

TRACK - REPEAT : Repeatedly play a track.

ALL - REPEAT : Repeatedly play all tracks.

RANDOM - REPEAT : Plays tracks in random order.

(A track that has already been played may be played again.)

Mute

You can turn the volume down to 0 with the push of a button.

Press again to restore the sound to the previous volume level.

SOURCE

Press to select a source connected to the Soundbar.

Skip Forward

If there is more than one file on the device you are playing, and you press

the $ button, the next file is selected.

SOUND CONTROL

Press to select TREBLE, BASS, or AUDIO SYNC. Then, use the

buttons to adjust the Treble or Bass volume from -6 to +6.

Press and hold the SOUND CONTROL button for about 5 seconds to adjust

the sound for each frequency band. 150Hz, 300Hz, 600Hz, 1.2KHz, 2.5KHz,

5KHz and 10KHz are selectable and each can be adjusted to a setting between

-6 and +6.

If the Soundbar is connected to a digital TV and the video appears out of sync

with the audio, press the SOUND CONTROL button to sync the audio with the

video. Use the

buttons to set the audio delay between 0 ms and 300

ms. In USB mode, TV mode, and BT mode, the Audio Sync function may not

available.

● Soundbar is a Samsung proprietary name.

● Operate the TV using the TV's remote control.

HW-J370-ZC_ENG_0319.indd 9HW-J370-ZC_ENG_0319.indd 9 2015-03-19  1:16:152015-03-19  1:16:15

DESCRIPTIONS

Bluetooth POWER

Press the Bluetooth POWER button on the remote to turn the Bluetooth

POWER On function on and off.

See pages 18 and 24 for details.

WOOFER

Press the WOOFER button. Then, use the

buttons to adjust the

Subwoofer volume

from -12, -6 to +6.

SURR. MODE

Press the SURR. MODE button on the remote to turn SURROUND SPEAKER

on and off. Each time the button is pressed, the selection changes as follows :

ON - SURROUND SPEAKER  OFF - SURROUND SPEAKER

Volume

Adjusts the volume level of the unit.

Power

Turns the Soundbar on and off.

SURR. LEVEL

Press the SURR. LEVEL button. Then, use the

buttons to adjust

the Surround Speaker volume from -6 to +6.

Play / Pause

Press the

button to pause a file temporarily.

Press the

button again to play the selected file.

Skip Back

If there is more than one file on the device you are playing, and you press

the

button, the previous file is selected.

INSTALLING THE BATTERY IN THE REMOTE CONTROL

1. Use a suitable coin to turn the

remote control's battery cover

counterclockwise to remove it

as shown in the figure above.

2. Insert a 3V lithium battery. Keep the

positive (+) pole facing up when inserting

the battery. Put the battery cover on and

align the '●' marks side by side as

shown in the figure above.

3. Use a suitable coin to

turn the remote control

battery cover clockwise

as far as it will go to fix it

in place.

HW-J370-ZC_ENG_0319.indd 10HW-J370-ZC_ENG_0319.indd 10 2015-03-19  1:16:162015-03-19  1:16:16

ENG

INSTALLATION

INSTALLING THE WALL MOUNT

You can use the wall mount bracket to mount this unit on a wall.

I NSTALLATION PRECAUTIONS

●

Install on a vertical wall only.

● For the installation, avoid a location with high temperature or humidity, or a wall that cannot sustain the weight of

the set.

● Check the strength of the wall. If the wall is not strong enough to support the unit, reinforce the wall or install the

unit on a different wall that can support the unit's weight.

● Purchase and use the fixing screws or anchors appropriate for the kind of wall you have (plaster board, iron board,

wood, etc.). If possible, fix the support screws into wall studs.

● Purchase wall mounting screws according to the type and thickness of the wall you will mount the Soundbar on.

- Diameter : M5

- Length: 1 3/8 inches or longer recommended.

● Connect cables from the unit to external devices before you install it on the wall.

● Make sure the unit is turned off and unplugged before you install it. Otherwise, it may cause an electric shock.

2 inches or more

1. Place the installation guide against the wall surface.

• The installation guide must be level.

• If the TV is mounted on the wall, install the Soundbar at least 2 inches below the TV.

2. Mark the location where the screws will go through on the wall, and then remove the installation guide. Next, drill

holes for the screws using an appropriately sized drill bit.

INSTALLATION

HW-J370-ZC_ENG_0319.indd 11HW-J370-ZC_ENG_0319.indd 11 2015-03-19  1:16:162015-03-19  1:16:16

INSTALLATION

3. Fasten the wall mounts and screws to the marked locations.

• The left and right mounts are different shapes. Make sure to position them correctly.

Wall Mounting the Sound Bar

4. Secure the two holder screws to the screw holes on the back of the Soundbar's main body, one on the left and

one on the right.

● Insert the USB cable into the back of the Soundbar before installing it on the wall.

5. Set the holder screws on the back of the Soundbar into the grooves of the wall mounts. For safe installation, make

sure to push the holder screws all the way to the bottom of the grooves.

I NSTALLING THE BRACKET WITHOUT REFERRING TO THE

WALL-MOUNT INSTALLATION GUIDE

2 inches or more

4.6 inches 5.1 inches

Minimum 9.4 ~ 9.7 inches

HW-J370-ZC_ENG_0319.indd 12HW-J370-ZC_ENG_0319.indd 12 2015-03-19  1:16:172015-03-19  1:16:17

ENG

INSTALLATION

1. Place Wall Mount L on the desired wall surface parallel to the floor as shown on the previous page. Mark the

location of the screw holes on the wall. Drill holes for the screws at the places you have marked.

2. Match the screw holes on Wall Mount L to the screw holes on the wall, and then screw one screw through the hole

in its right end. Tighten the screw until it is firmly fixed to the wall.

3. Place Wall Mount R on the desired wall surface parallel to the floor and aligned with Wall Mount L as shown on

the previous page. Mark the location of the screw holes on the wall. Drill holes for the screws at the places you

have marked.

4. Match the screw holes on Wall Mount R to the screw holes on the wall, and then screw one screw through the

hole in its right end. Tighten the screw until it is firmly fixed to the wall.

• If you are mounting the Wall Mounts beneath the TV, make sure to position the mounts 2 or more inches below

the TV and to align the mounts with the center of the TV as shown on the previous page.

5. Insert screws through the remaining holes, and then tighten.

DETACHING THE WALL MOUNT

1. Pull the Soundbar upwards as shown in the figure to separate it from the wall mounts.

Detaching the Soundbar from the

Wall Mounts

● Do not hang onto the installed unit and avoid striking or dropping the unit.

● Secure the unit firmly to the wall so that it does not fall off. If the unit falls off, it may cause an injury or

damage the product.

● When the unit is installed on a wall, please make sure that children do not pull any of the connecting

cables, as this may cause it to fall.

● For the optimal performance of a wall mount installation, install the speaker system at least 2 inches below

the TV, if the TV is mounted on the wall.

● For your safety, if you do not mount the unit on the wall, install it on a secure, flat surface where it is unlikely

to fall.

HW-J370-ZC_ENG_0319.indd 13HW-J370-ZC_ENG_0319.indd 13 2015-03-19  1:16:172015-03-19  1:16:17

CONNECTIONS

● Do not connect the power cord of this product or your TV to a wall outlet until all connections between

components are complete.

● Before moving or installing this product, be sure to turn off the power and disconnect the power cord.

CONNECTING THE SUBWOOFER AND

SWA-7000S TO THE MAIN UNIT

CONNECTING THE SUBWOOFER AND SWA-7000S

AUTOMATICALLY

The linking IDs of the SWA-7000S wireless module and the subwoofer are preset at the factory. The subwoofer and

the SWA-7000S should link (connect wirelessly) to the main unit automatically when you turn on the main unit, the

subwoofer and the SWA-7000s.

• When subwoofer and SWA-7000S are is completely connected, the blue LED Link Indicator on the subwoofer and

the SWA-7000S stops blinking.

CONNECTING THE SUBWOOFER AND SWA-7000S

MANUALLY

If the blue LED light does not stop blinking when the mainunit, subwoofer, and SWA-7000S are turned on, please reset

the linking ID by following the procedure below.

SURROUND SPEAKERS OUT

SPEAKER IMPED#0%'š

ID SET

1. Plug the power cords of the main unit, subwoofer, and SWA-7000S into an AC wall outlet.

2. Press the ID SET button on the back of the subwoofer and the SWA-7000S with a small, pointed object for 5

seconds.

• The STANDBY indicator is turned off and the LINK indicator (Blue LED) blinks quickly.

3. While the main unit is powered off (in STANDBY mode), press and hold the

(Mute) on the remote control for 5

seconds.

4. The ID SET message appears on the Soundbar's display.

5. To finalize the link, turn the main unit’s power on while the blue LED on the subwoofer and the SWA-7000S is

blinking.

• The main unit, subwoofer, and SWA-7000S should now be linked (connected).

• The Link indicator (Blue LED) on the subwoofer and SWA-7000S should be glowing continuously.

It should not be blinking.

• If the Link indicator is not solid blue, the linking process has failed. Turn off the main unit and start again from

Step 2.

CONNECTIONS

HW-J370-ZC_ENG_0319.indd 14HW-J370-ZC_ENG_0319.indd 14 2015-03-19  1:16:172015-03-19  1:16:17

ENG

CONNECTIONS

● Before moving or installing the product, be sure to turn off the power and disconnect the power cord.

● If the main unit is powered off, the wireless subwoofer will be in standby mode and the STANDBY LED on

the upper side will come on after the Link indicator (Blue LED) blinks for 30 seconds.

● If you use a device that uses the same frequency (2.4GHz/5.0GHz) as the Soundbar near the Soundbar,

interference may cause some sound interruption.

● The maximum transmission distance of the wireless signal between the main unit and the subwoofer and

the main unit and the SWA-7000S is about 32.8 ft, but may vary depending on your operating

environment. If a steel-concrete or metallic wall is between the main unit and the wireless subwoofer or the

main unit and the SWA-7000S, the system may not operate at all, because the wireless signal cannot

penetrate metal.

● If the main unit doesn't make a wireless connection, follow steps 1-5 on the previous page to re-set the

connection between the main unit, the wireless subwoofer, and the SWA-7000S.

● The wireless receiving antenna is built into the wireless subwoofer and the SWA-7000S. Keep the both

units away from water and moisture.

● For optimal listening performance, make sure that the areas around the wireless subwoofer and

SWA-7000S areas clear of any obstructions.

CONNECTING THE SURROUND

SPEAKERS

SURROUND SPEAKERS OUT

52'#-'4+/2'&#0%'š

ID SET

Surround Speaker (L) Surround Speaker (R)

Wireless Receiver

Module

● Place these speakers to the side of your listening position. If there isn't enough room, place these

speakers so they face each other. Position them about 2 to 3 feet above your ear, facing slightly

downward.

● Surround speakers must be connected to the wireless receiver module.

● Each speaker has a colored label on its back or underside. Each cable has a single colored band near its

end. Match the band on each cable to the speaker label by color, and then connect the cable to the

speaker.

HW-J370-ZC_ENG_0319.indd 15HW-J370-ZC_ENG_0319.indd 15 2015-03-19  1:16:182015-03-19  1:16:18

CONNECTIONS

CONNECTING TO A TV

CONNECTING TO A TV USING A DIGITAL OPTICAL CABLE

OPTICAL IN

OPTICAL OUT

Optical Cable

1. Connect the OPTICAL IN (Audio) jack on the Soundbar to the OPTICAL OUT jack of the TV with a digital optical

cable.

2. Press the

(Source) button on the top panel of the Soundbar or the SOURCE button on the remote control to

select the D.IN mode.

+ Auto Power Link

If you have connected the main unit to a TV with a digital optical cable, set the Auto Power function ON to have

the Soundbar turn on automatically when you turn the TV on.

AUTO POWER LINK Display

ON - POWER LINK

OFF

OFF - POWER LINK

1. Connect the Soundbar and

a TV

with a digital optical cable.

2. Press the (Source) button on the main unit’s top panel or the SOURCE button on the remote control to

select the

D.IN

mode.

3. Press the AUTO POWER button on the remote control to toggle the Auto Power Link function on and off.

● Depending on the connected device, Auto Power Link may not function.

HW-J370-ZC_ENG_0319.indd 16HW-J370-ZC_ENG_0319.indd 16 2015-03-19  1:16:192015-03-19  1:16:19

ENG

CONNECTIONS

TV SOUNDCONNECT

You can enjoy TV sound through your Soundbar when it is connected to a Samsung TV that supports the TV

SoundConnect function.

Connect

1. Turn on the TV and Soundbar.

• Turn on the menu of the TV.

• Move to Speaker Settings on "Sound" tab.

• Set the "Add New Device" menu to "On".

2. Press the (Source) button on the main unit’s top panel or the SOURCE button on the remote control to

select the TV mode.

3. On the TV, a message asking whether to enable the TV SoundConnect function appears.

4. Select <Yes> to finish connecting the TV and Soundbar using the TV's remote control.

● Switching the Soundbar’s mode from TV to another mode automatically terminates TV SoundConnect.

● To connect the Soundbar to another TV, the existing connection must be terminated.

● To terminate the existing connection, press and hold the

button on the remote for 5 seconds.

To connect to the other TV, follow Steps 1 through 4 above.

● The TV SoundConnect (SoundShare) function is supported by some Samsung TVs released from 2012 on.

Check whether your TV supports the TV SoundConnect (SoundShare) function before you begin. (For

further information, refer to the TV’s user manual.).

● If your Samsung TV was released before 2014, check the SoundShare setting menu.

● If the distance between the TV and Soundbar exceeds 32.8 ft, the connection may not be stable or the

audio may stutter. If this occurs, relocate the TV or Soundbar so that they are within operational range, and

then re-establish the TV SoundConnect connection.

● TV SoundConnect Operational Ranges:

- Recommended pairing range: within 78.7 inches.

- Recommended operational range: within 32.8 ft.

● The Play/Pause, Next, and Prev buttons on the Soundbar or Soundbar's remote do not control the TV.

HW-J370-ZC_ENG_0319.indd 17HW-J370-ZC_ENG_0319.indd 17 2015-03-19  1:16:202015-03-19  1:16:20

CONNECTIONS

+ Using the Bluetooth POWER On function

The Bluetooth POWER On function is available after you have successfully connected the Soundbar to a Bluetooth

compatible TV using TV SoundConnect. When the Bluetooth POWER On function is ON, turning the connected TV on

or off will turn the Soundbar's power on and off as well.

1. Connect the TV to your Soundbar using the TV SoundConnect function.

2. Press the Bluetooth POWER button on the Soundbar remote. ON - BLUETOOTH POWER appears on the

Soundbar's display.

• ON - BLUETOOTH POWER : The Soundbar turns on and off when you turn the TV on or off.

• OFF - BLUETOOTH POWER : The Soundbar only turns off when you turn the TV off.

● This function is supported by some Samsung TVs released from 2013 on.

HW-J370-ZC_ENG_0319.indd 18HW-J370-ZC_ENG_0319.indd 18 2015-03-19  1:16:202015-03-19  1:16:20

ENG

CONNECTIONS

CONNECTIONS WITH EXTERNAL

DEVICES

This unit comes equipped with one optical in digital jack and one audio analog in jack, giving you two ways to

connect it to an External Devices.

AUX IN

AUX OUT

OPTICAL IN

OPTICAL OUT

BD / DVD player /

Set-top box /

Game console

Optical Cable

Audio Cable

(not supplied)

AUX CABLE

1. Connect AUX IN (Audio) on the main unit to the AUDIO OUT jack of the Source Device.

2. Press the (Source) button on the top panel of the Soundbar or the SOURCE button on the remote control to

select the AUX mode.

OPTICAL CABLE

1. Connect OPTICAL IN (Audio) on the main unit to the OPTICAL OUT jack of the Source Device.

2. Press the (Source) button on the top panel of the Soundbar or the SOURCE button on the remote control to

select the D.IN mode.

HW-J370-ZC_ENG_0319.indd 19HW-J370-ZC_ENG_0319.indd 19 2015-03-19  1:16:202015-03-19  1:16:20

CONNECTIONS

USB

You can play music files located on USB storage devices through the Soundbar.

Display

USB port

1. Connect the USB device to the USB port on the back of the product.

2. Press the (Source) button on the main unit’s top panel or the SOURCE button on the remote control to

select the USB mode.

3. USB appears on the display screen.

• The Soundbar connection to the USB device is complete.

• The Soundbar automatically turns off (Auto Power Off) if no USB device has been connected for more than 25

minutes.

+ Before you connect a USB device

Be aware of the following:

● If the file name of a file or folder on a USB device exceeds 10 characters, it is not displayed on the Soundbar's

display.

● This product may not be compatible with certain types of USB storage media.

● The Soundbar supports the FAT16 and FAT32 file systems.

- The NTFS file system is not supported.

● Connect USB devices directly to the USB port of the product. Otherwise, you may encounter a USB compatibility

problem.

● Do not connect multiple storage devices to the product via a multi-card reader. It may not operate properly.

● Digital camera PTP protocols are not supported.

● Do not remove the USB device while it is

transferring files.

● DRM-protected music files (MP3, WMA) from commercial web sites cannot be played.

● External HDDs are not supported.

● Mobile phone devices are not supported.

HW-J370-ZC_ENG_0319.indd 20HW-J370-ZC_ENG_0319.indd 20 2015-03-19  1:16:222015-03-19  1:16:22

La page charge ...

Samsung HW-J370 Manuel utilisateur

Marque: Samsung

Modèle: HW-J370

Catégorie: Ensembles de haut-parleurs

Taper: Manuel utilisateur

Télécharger le PDF

rapport

dans d''autres langues

English: Samsung HW-J370 User manual

Documents connexes

Autres documents

iHome Rx2 Manuel utilisateur
