Beam User Manual

Iridium Extreme PTT

Grab ‘N’ Go Kits

Pictured: Iridium Extreme®

PTT Grab ‘N’ Go Corded Kit

(PTTGNG-C1)

Iridium Extreme PTT Grab ‘N’ Go Kits

Installation and User Manual

Product names:

Iridium Extreme PTT Grab ‘N’ Go Corded Large Kit

Iridium Extreme PTT Grab ‘N’ Go Corded + UPS Large Kit

Iridium Extreme PTT Grab ‘N’ Go Wireless Large Kit

Iridium Extreme PTT Grab ‘N’ Go Wireless + UPS Large Kit

Iridium Extreme PTT Grab ‘N’ Go Privacy Handset Kit

Iridium Extreme PTT Grab ‘N’ Go Privacy Handset + UPS Kit

Iridium Extreme PTT Grab ‘N’ Go Corded Small Kit

Iridium Extreme PTT Grab ‘N’ Go Wireless Small Kit

Manual Part #: USRMAN008403

Manual revision: 3

Release date: August 2018

Beam Communications Pty Ltd

5/8 Anzed Court, Mulgrave,

Victoria, 3170, AUSTRALIA

Information furnished by Beam Communications Pty Ltd is believed to be accurate and reliable. However, no responsibility

is assumed by Beam for its use, or for any infringement of patents or other rights of third parties, which may result from its

use. No license is granted by implication or otherwise under any patent or patent rights of Beam. Beam reserves the right to

change specications at any time without notice.

Iridium Extreme PTT Grab ‘N’ Go Grab ‘n’ Go Kits User Manual

Beam Communications

Beam Communications, a wholly owned subsidiary of

World Reach Limited (WRR), listed on the Australian Stock

Exchange, is a world leader in design, manufacture and

distribution of specialized communications equipment for

the Iridium Satellite Network.

Beam’s commitment to be at the forefront has continued

to increase its share of the global satellite communications

market. Its premium distribution network spans the world.

Recognized as a leading provider of satellite

communication solutions, Beam specializes in Voice,

Data, Tracking and customized solutions. Beam develops

innovative products and services to meet market

demands and niche applications.

Beam’s leading edge products are deployed in a wide range

of markets including Maritime, Transport, Government,

Defence, Mining, Construction, Forestry, Emergency Services,

Relief Aid, Telemetry and Rural Telephony.

Supported by a dedicated team of professionals, Beam has

developed solid relationships with its peers and network of

distributors worldwide.

Beam Communications Pty Ltd

5/8 Anzed Court, Mulgrave,

Victoria, 3170, AUSTRALIA

Web: www.beamcommunications.com

Info: info@beamcommunications.com

Support: suppor[email protected]

Tel: +61 3 8588 4500

Fax: +61 3 9560 9055

General Operation (Wireless Handset only) 15

Dock Loudspeaker Operation

(Corded and Wireless Handset)

PTT Grab ‘n’ Go Case - Phone Mode 18

PTT Grab ‘n’ Go Case - PTT Mode 19

DriveDOCK Extreme Button LED Status

(PTT Mode)

DriveDOCK Extreme Button LED Status (Phone

Mode)

DriveDOCK Extreme Button Action & Response

(Phone Mode)

DriveDOCK Extreme Button Action & Response

(PTT Mode)

Technical Notes 23

Type Acceptance 24

Radio and Television Interference 24

Important Safety and Handling Information 26

Informations importantes de sécurité et de

manutention

Specications 30

Beam Warranty Conditions 32

Contents

Beam Communications 3

Contents 4

Conventions in this Manual 5

Terminology

Kit Contents 6

Safety Warnings 6

Product Overview 8

Dock PTT Mode versus Phone mode 9

Iridium Extreme PTT Grab ‘N’ Go Kits

- Large case

Iridium Extreme PTT Grab ‘N’ Go Kits

- Small case

Beam WIRELESS PTT HANDSET 11

Wireless PTT Parts & functions 11

Wireless Charging Cradle Parts & Functions 11

Beam CORDED PTT HANDSET 12

Beam Privacy Handset 13

Iridium Extreme® PTT Operation 13

Connecting to the Iridium network 13

PTT Mode 13

Phone Mode 13

PTT Operation 13

PTT Session Status 14

Using SOS 14

Iridium Extreme PTT Grab ‘N’ Go Grab ‘n’ Go Kits User Manual

Conventions in this Manual

Warnings, cautions and notes appear throughout this

manual are represented by following conventions.

WARNING / CAUTION:

This symbol and associated text indicate a

warning note providing information to prevent

damage to equipment or personal injury.

IMPORTANT / NOTE:

This symbol and associated text indicate a note

providing general operating information.

INTERFERENCE:

All wireless phones may get interference, which

could aect performance.

Terminology

TERM DESCRIPTION

Bluetooth ® The Bluetooth® word, mark and logos

are owned by Bluetooth® SIG, Inc. Other

trademharks and trade names are those of

their respective owners.

PTT Push-To-Talk

Eagle Extreme Docks Conguration Tool - MS

Windows Install

GPS Global Positioning System

HF Hands-free

Mobile Originating Describes a call initiated by the DriveDOCK

Extreme

Mobile

Terminating

Describes an incoming call being answered by

the DriveDOCK Extreme

Iridium Extreme®

PTT device

The Iridium Extreme PTT Satellite telephone

Dock Beam DriveDOCK Extreme

Corded Handset Beam Corded Push-To-Talk Handset

Wireless Handset Beam Wireless Push-To-Talk Handset

The ® symbol, mark and logos are owned

by the respective companies of which the

symbol follows. Any use of such marks by

Beam Communications is under license. Other

trademarks and trade names are those of their

respective owners.

RF Radio Frequencies

AT Attention command

SMA Sub Miniature version A co-axial RF connection

RP-SMA Reverse Polarity – Sub Miniature connectors.

FCC Federal Communications Commission.

Independent agency of the US government that

regulates communications.

RSS Radio Standards Specications. Industry Canada’s

documents that describe the processes and

requirements for compliance of radio apparatus.

Grab ‘N’ Go Kit Variants

Your chosen Extreme PTT Grab ‘n’ Go Case contains the

following:

PTTGNG-C1 - Iridium Extreme PTT Grab ‘N’ Go Corded Large Kit

PTTGNG-W1A - Iridium Extreme PTT Grab ‘N’ Go Wireless Large

PTTGNG-P - Iridium Extreme PTT Grab ‘N’ Go Privacy Handset Kit

PTTGNG-C1B - Iridium Extreme PTT Grab ‘N’ Go Corded + UPS Large Kit

PTTGNG-W1AB - Iridium Extreme PTT Grab ‘N’ Go Wireless + UPS Large

PTTGNG-PB - Iridium Extreme PTT Grab ‘N’ Go Privacy Handset + UPS Kit

PTTGNGS-C1 - Iridium Extreme PTT Grab ‘N’ Go Corded Small Kit

PTTGNGS- W1A - Iridium Extreme PTT Grab ‘N’ Go Wireless Small Kit

Optional Extreme Dock Accessories

The following optional accessories are available for your

Iridium Extreme PTT Grab ‘N’ Go Large Kits:

• RST060 - Battery (Bracket required)

See your service provider for pricing and availability of the

above quality BEAM accessories.

Additional Information

For the latest in supporting software and documentation

for Extreme PTT DriveDOCK please visit

www.beamcommunications.com/support/drivedockextreme

Other Resources Available Online

- Iridium Antenna Installation Guide and User Manual

- DriveDOCK Extreme User Manual and Quick Start Guide

- Iridium PTT Extreme User Guide

Safety Warnings

IMPORTANT

Please read the following information carefully before using

the Iridium Extreme PTT Grab ‘N’ Go Kits. Failing to follow

instructions may compromise the safety of the product and

may result in personal injury and/or equipment damage. Please

consult your supplier if you have any further questions.

The DriveDOCK Extreme is a low power docking station for the

Iridium Extreme® or Iridium Extreme® PTT device. When ON, it will

charge the Extreme handset whilst docked in the DriveDOCK.

• Store the system in a cool and dry area.

• Do not submerge the system in water.

• Do not place foreign metal objects or debris in the system.

If debris enters into the system, please return to factory for

service.

WARNING

DO NOT open the equipment. There are no user serviceable

parts inside. If a DC power supply is to be used, the output must

comply with the Safety Extra Low Voltage (SELV) requirements

of IEC60950. All connectors must only be connected to

equipment ports which comply with the Safety Extra Low

Voltage (SELV) requirements of IEC60950.

WARNING: POTENTIALLY EXPLOSIVE ATMOSPHERES

• Turn your 9575 Extreme device and Wireless PTT Handset

OFF and DO NOT remove the battery or remove the 9575

Extreme device / Wireless PTT Handset from the cradle

when you are in any area with a potentially explosive

atmosphere.

• Obey all signs and instructions.

• Sparks from your battery in such areas could cause an

explosion or re resulting in bodily injury or even death.

• Areas with a potentially explosive atmosphere are often

but not always clearly marked. They include, but are not

Iridium Extreme PTT Grab ‘N’ Go Grab ‘n’ Go Kits User Manual

limited to:

» fuelling areas such as gasoline stations

» below deck on boats;

» fuel or chemical transfer or storage facilities;

» areas where fuel odours are present (for example,

if a gas/propane leak occurs in a car or home);

» areas where the air contains chemicals or

particles, such as grain, dust, or metal powders;

» any other area where you normally would be

advised to turn o your vehicle’s engine.

WARNING: ROAD SAFETY COMES FIRST!

Do not use a hand-held cellular terminal, satellite phone or

mobile when driving a vehicle, unless it is securely mounted

in a holder for speaker phone operation. Before making a call

with a handheld terminal, satellite phone or mobile, park the

vehicle stationary. Please obey local road laws for hands-free

speakerphone operation. Speakerphones (hands-free) must

be installed by qualied personnel. Faulty installation or

operation can constitute a safety hazard.

WARNING

Changes or modications not expressly approved by Beam

Communications could void the product warranty.

WARNING: AIR BAG EQUIPPED VEHICLES

An air bag inates with great force. Do not store or mount the

Cradle / PTT system or any of the accessories in the area over

the air bag or in the air bag deployment area.

WARNING: HEADSET USE

Headsets and earpieces used with this product are capable of

delivering sounds at loud volumes. Exposure to such sounds

can result in permanent hearing loss damage. The volume

level may vary based on conditions such as the docks volume

settings and the environment.

Please read the following safety guidelines below prior to using

a headset or earpiece:

1. Prior to using this product follow these steps:

• Before putting on the headset, turn the volume

control to its lowest level,

• Put the headset on, and then slowly adjust the

volume control to a comfortable level.

2. During the use of this product:

• Keep the volume at the lowest level possible and

avoid using the headset in noisy environments where

you may be inclined to turn up the volume;

• If increased volume is necessary, adjust the volume

control slowly.

• If you experience discomfort or ringing in your ears,

immediately discontinue using the headset and

consult a physician.

With continued use at high volume, your ears may become

accustomed to the sound level, which may result in permanent

damage to your hearing without any noticeable discomfort.

Using a headset while operating a motor vehicle, motorcycle,

watercraft may be dangerous, and is illegal in some

jurisdictions. Check your local regulations and laws.

Product Overview

The Iridium Extreme PTT Grab ‘N’ Go Kits provide a high

quality portable transport solution using the

Iridium Extreme PTT Service. Combined with Beam’s

Wireless or Corded Push-To-Talk (PTT) Handset Accessory

Kit, in conjunction with the Beam Extreme DriveDOCK, the

easy to carry cases extend the power of the Iridium

Extreme® PTT Device to the palm of your hand, whether in

or out of a vehicle, anywhere you need to go!

The inbuilt Beam PTT handset kit (wireless or corded) is

ideal for various applications such as Emergency Services,

Commercial Transportation, Mining Industry, Defence,

Government, no matter the type or size of operation,

you can depend on the Beam PTT to perform.

The Beam PTT handset key features:

• Durable and reliable mic/speaker handset

• Enhanced clean audio quality

• Compatible with existing Beam DriveDOCK Extreme

• Supports both Phone and PTT modes of the Iridium

Network

• Ability to amplify PTT audio to external cabin

loudspeaker

• Left or Right side bracket mounting to the Dock

Beam DriveDOCK Extreme requires rmware version 1.5

or higher to be compatible with the Iridium Extreme® PTT

device.

PTT Case Types:

Corded Push-To-Talk Handset

Available in the large and small case.

Wireless Push-To-Talk Handset

Avaliable in the large and small case.

Pirvacy Handset Push-To-Talk

Available only in selected models.

NOTE: Privacy Handset has the ability to receive audio via

push of a button to the Iridium PTT Extreme device.

Iridium Extreme PTT Grab ‘N’ Go Grab ‘n’ Go Kits User Manual

Dock PTT Mode versus Phone mode

FUNCTION EXTREME DOCK in PTT MODE

Wired Alert Loop Disabled (No alert/SOS functionality exists in the 9575 Extreme device when in PTT mode.)

Mute Function

Disabled. If the button is pressed during PTT mode, the mute button will ash 3 times in ORANGE

and sound the “Triple beep rising tones” to the Dock buzzer & the current loudspeaker to indicate

the 9575 Extreme device is in PTT mode.

Bluetooth®Audio Disabled

Privacy Handset Please refer to page 18 and 19 for a detailed description.

Volume Buttons

During PTT mode, the volume changes aect BOTH the dock’s external speaker AND the PTT

handset’s speaker.

Tracking

Tracking is not supported during PTT mode (both instant tracking and interval tracking messages

are suspended).

Track Button

Disabled. If the Track button is pressed during PTT mode, the mute button will ash 3 times in

ORANGE and sound the “Triple beep rising tones” to the Dock buzzer & the current loudspeaker to

indicate the 9575 Extreme device is in PTT mode.

Horn Alert Disabled

Entertainment Mode Disabled

Cabin Handsfree

audio

Disabled

When the 9575 Extreme device is in PPT mode, some of the Extreme Dock functions are altered (please refer to pg. 18-19 for

more details):

IMPORTANT

During PTT mode, all Alert Loop functionality is DISABLED. If the alert loop is triggered in PTT mode there are no messages sent, no

beeping tones, no ashing LED.

Antenna Cable

Large Hard Case

Small Hard Case

Antenna Cable

Speaker

Lid close stopper

RST705 Magnetic mount

antenna with cable

RST705 Magnetic mount

antenna with cable

DriveDOCK Extreme

Please note the Iridium Extreme

9575/PTT device is not included.

DriveDOCK Extreme

Please note the Iridium Extreme

9575/PTT device is not included.

Microphone

Iridium Extreme PTT Grab ‘N’ Go Kits - Large case

Handset Parts & Functions

Iridium Extreme PTT Grab ‘N’ Go Kits - Small case

Handset Parts & Functions

Beam Privacy

Handset

Beam Wireless

PTT Handset

Beam Wireless

PTT Handset

Beam Corded

PTT Handset

PTT615 - Magnetic

Mount Antenna

PTT615 - Magnetic

Mount Antenna

Beam Corded

PTT Handset

RST060 - Battery + bracket

Optional

Speaker

The Speaker is behind

the DriveDOCK Extreme

Car Cigarette DC Power

Car Cigarette DC

Power

Please note the Beam

Privacy Handset is not

included.

Please note the Magnetic

Mount Antenna is only

fitted to the Wireless Kit.

Please note the Magnetic

Mount Antenna is only

fitted to the Wireless Kit.

Iridium Extreme PTT Grab ‘N’ Go Grab ‘n’ Go Kits User Manual

Beam Wireless PTT Handset

Wireless PTT Handset Parts & Functions

1 - Volume down: adjusts speaker audio louder - minimum setting

2 - Volume up: adjusts speaker audio louder

3 - PTT button: press to talk - programmed for 3 quick beeps when

pressed.#

4 - Microphone: talk in a normal strength voice about 3 to 5cm (2”) from

microphone port

5 - Orange button: Not used. Reserved for future use.

6 - Talkaround button (grey button): Press to talk around#

7 - ON/OFF: hold for 5 seconds to turn ON/OFF. Intuitive tones sound.

8 - DC charging: Wireless PTT handset will beep to notify correct seating

when first placed in gateway cradle. The status LED may momentary

blink every 10 seconds to indicate charge status. Constant blue

means charged. (The lithium battery will charge on at ambient

temperature of 0° - 45 °C)

9 - Headset port: use with headsets/accessories**. Mutes speaker.

10 - Earpiece jack: allows private listening via 3.5mm earpieces while

muting the speaker.

11 - Speaker: Audio will still be delivered with handset in charging

cradle

12 - Status light: glows blue when fully operational. Flashes when “out

of range” or when its paired unit is off.

13 - Antenna connector: allows connection of long range external

antenna or replacement of short range internal type included

in the kit (note: using a dierent antenna connection may void

warranty)

14 - Function button: press for 1 second = manual ON/OFF, double

press = Find Me™ or long press for 8 seconds ON power on until

occassional blink = master reset to erase current device pairing.

15 - Interface connector (RJ45 port): connect to the DriveDOCK

Extreme for single PTT configuration. Connect to a Y-connector for

a dual PTT configuration(note: requires additional optional Wireless

PTT100A handset).

16 - Blue buttons ‘+’ & ‘-’: Not used. Reserved for future use.

# When out of range the unit will sound a slow beeping tone alert.

** Buy separately as needed - see full user manual.

Wireless Charging Cradle Parts & Functions

+ -

Part No: PTT-W1A

15 13

12 14

98 10

321

BOTTOM VIEW

Products not shown to size - for illustrative purposes only

Satellite Antenna installation

Install satellite antenna (RST705) on the roof of a vehicle

or depending on your installation preference ensuring

unobstructed view.

PTT Antenna installation

For Grab and Go cases with the external antenna as

standard or as an optional accessory, install the PTT antenna

(PTT615) on a vehicle’s roof for better signal reception to the

wireless PTT handset.

NOTE: When installing the RST705 Satellite Antenna and the

PTT615 antenna on the roof of the vehicle, they must be at

least 30cm/12” apart.

WARNING

The Beam Wireless PTT Handset and charging cradle are designed to

radiate low levels of radio energy in accordance with global government

approved regulatory standards. It features Adaptive Power Output. APO

automatically adjusts the RF power output in accordance with signal

required. This features limits and reduces extraneous radiated radio energy.

This also helps minimize battery consumption and extends battery shelf life.

Do not touch the antenna when operational. Keep Secure Microphone

antenna 25mm (1”) or more away from your face and body to ensure

exposure levels remain at or below the maximum levels. Keep your body at

least 20cm/8” from external antennas connected to the charging cradle.

Ne touchez pas l’antenne lorsque opérationnel. Gardez sécurisé antenne

de microphone 25mm (1“) ou plus loin de votre visage et le corps pour

assurer des niveaux d’exposition restent égales ou inférieures aux teneurs

maximales. Gardez votre corps au moins 20cm/8 “des antennes externes

connectés à l’unité de chargeur wireless.

IMPORTANT

Always attach the antenna to the charging cradle before

connecting the interface cable.

Beam Corded PTT Handset

The Beam Corded Handset contains a microphone and speaker for

independent conversation up to a stretched distance of 1m from

the Dock.

The status light will be ON whenever the PTT button has been pressed.

Microphone

Status Light

Handset

Loudspeaker

Optional

Earpiece

Jack

PTT: Push-To-Talk

Button

Orange Button

(Disabled)

PTT Handset retaining Clip

Iridium Extreme PTT Grab ‘N’ Go Grab ‘n’ Go Kits User Manual

Beam Privacy Handset

Available on selected models only

Iridium Extreme® PTT Operation

Connecting to the Iridium network

Insert the Iridium Extreme® PTT device into the Dock, and ensure

the Dock is powered on (via vehicle key or alternative power

source). The dock will detect and boot the Extreme PTT device to its

last known mode.

PTT Mode

To switch from Phone Mode to PTT Mode:

1. Press the left soft key, labelled Menu.

2. Press the left soft key, labelled Select.

3. Wait for the device to switch to PTT Mode.

4. The transition to PTT mode takes approximately 10 seconds.

A “PTT” designation will appear at the top center of the screen

when the transition is complete and the device will identify

your Home Talkgroup at the bottom of your screen (e.g.,

Talkgroup 1).

Phone Mode

To change from PTT Mode back to Phone Mode:

1. Press the left soft key (on the Iridium Extreme

® PTT device)

2. Select the Switch to Phone option at the top of the menu list.

PTT Operation

To start a Push-to-Talk call, push and hold the Push-to-Talk (PTT)

Button on the Beam handset, and continue to hold the button

until you are granted the floor to talk. Initially, you will hear a

series of connecting tones that will beep on one second intervals,

followed by either a Talk Tone (three notes in ascending tone in

rapid succession) or a Reject Tone (two notes in descending tone in

rapid succession) that will occur if the service is busy or unavailable

(a corresponding message will be displayed on the screen when

this occurs).

After receiving the Talk Tone, continue holding the PTT Button and

be sure to keep the button pressed while you are speaking and to

release it when you are nished. You will have up to 20 seconds

to speak during each transmission before the oor becomes

Mounting Cup

Privacy Handset

open for others to speak.

If you have configured your device with Talk Timer Enabled, the

time remaining to speak in the current talk period is displayed on

the screen below the Device Name.

When 20 seconds has elapsed, Time Expired is displayed on the

screen and the device moves to the OPEN status, giving others in

the talkgroup session a chance to speak.

PTT Session Status

A talkgroup is a collection of Iridium Extreme® PTT devices that

have been provisioned to transmit content to each other within a

specified geographic area(s). Refer to the Iridium Extreme

® PTT User

Guide for more information.

When your Iridium Extreme

® PTT device is monitoring a talkgroup

(not in Scan State), the screen displays one of four states: IDLE,

LISTENING, TALKING and OPEN.

IDLE: When a talkgroup is not active in the network, the devices

that have the talkgroup as their Home Talkgroup will display IDLE.

LISTENING: When a talkgroup is active and a participant has the

floor, the devices that are participating in the talkgroup will display

LISTENING.

TALKING: When a talkgroup is active and a participant has the floor,

the device that has the floor will display TALKING.

OPEN: When a talkgroup is active but no one has the floor, the

devices that have the talkgroup as their Home Talkgroup will display

OPEN.

Using SOS

If you attempt to press the SOS button while in PTT Mode, you

will receive the following notication: “WARNING! Must go to

Phone Mode for SOS.”

To change the Iridium service to Phone mode, Press the left

soft key (on the Iridium Extreme

® PTT device), labelled Phone,

to switch to Phone Mode. While transitioning, you will be

prompted to “Press SOS again when in Phone Mode”. You must

press the SOS button again in Phone Mode to successfully

initiate an SOS call.

IMPORTANT

The Dock Alert loop will not trigger an alarm while the phone is in

PTT mode

Tracking Functionality

When in PTT mode, the tracking functionality (interval and

instant tracking messages) is DISABLED.

Navigating to Phone Mode to Dial

If you attempt to dial a phone number while in Push-To-Talk

mode, you will receive the following notication: “Dialing not

supported. Must go to Phone mode to dial”.

Iridium Extreme PTT Grab ‘N’ Go Grab ‘n’ Go Kits User Manual

Press the left soft key, labelled Phone to switch to Phone Mode.

As you are transitioning, you will be prompted to “Dial number

again when in Phone Mode”. Numbers dialled in PTT Mode must be

re-entered once you switch to Phone Mode, and the call must be

initiated in Phone Mode to connect successfully.

IMPORTANT

For a comprehensive description of all the features of the Push-

To-Talk functionality in the 9575 Extreme device, see the Iridium

Extreme

® PTT User manual.

General Operation

(Wireless Handset only)

Power On & O

The Wireless PTT Handset and charging cradle powers on with the

BEAM Extreme Dock. Note that the Wireless PTT Handset does not

power off when the Extreme Dock is turned off. You can manually

turn off the charging cradle by pressing the front grey button for

3 seconds and the blue status LED will switch off. You can do the

same on the Wireless PTT Handset by pressing the red button. The

handset will sound a de-escalating tone. To power On, press the red

button and releasing the button once the LED status lights turn on

and the handset will sound an escalating tone. The blue status LED

on both units will flash momentarily and then go solid once they’re

connected.

PTT-W1A (primary unit)

Pairing a new PTT-W1A handset to a gateway crhadle

Each Beam Wireless Push-To-Talk handset is uniquely connected

to a specific gateway cradle in the factory. This ensures that all

communications between the two units are secure and cannot be

compromised or interfered with by a third party. In the event of a

Wireless PTT handset being lost, it can be permanently disconnected

from the gateway cradle by connecting with a new replacement unit.

How to pair:

1. Switch ON the DriveDOCK Extreme and make sure that the

PTT-W1A gateway cradle and handset are turned ON.

2. Hold the Wireless PTT handset while pressing both the blue

volume controls until the blue LED flashes and you hear it

beep, after 5-8 seconds. With the Gateway cradle and PTT

handset switched on, hold the Wireless PTT handset while

pressing both the blue volume controls until the blue LED

flashes and you hear it beep, after 5-8 seconds.

3. Place the Wireless PTT handset back into the gateway cradle.

After a few seconds the Wireless PTT handset will sound a

confirmation two-tone and paring has completed.

4. LED will be a solid blue once paired.

Find Me™ Feature

The Wireless PTT handset Find Me™ feature allows a misplaced/

lost handset or its user to be audibly located by sounding a loud

continuous alert tone through the Wireless PTT handset.

To activate, press the gateway function button twice within

1-second. the loud alert tone will immediately start to sound. It can

be deactivated by the user momentarily pressing the Wireless PTT

button on the handset or the function button on the gateway cradle.

Optional Accessory: Wireless PTT100A (Secondary unit)

Pairing a PTT100A to the PTT-W1A gateway cradle

The Wireless PTT100A is an optional accessory. Using the Y-connector

included in the kit, the PTT100A Wireless handset must be paired

to the primary PTT-W1A gateway cradle to enable the dual PTT

configuration (see image).

How to pair:

1. Switch ON the DriveDOCK Extreme and make sure that the

PTT-W1A gateway cradle and PTT100A handset is turned ON.

2. Remove the primary Wireless PTT-W1A handset from the

gateway cradle.

3. Hold the secondary Wireless PTT-W1A handset while pressing

both the blue volume controls for 5-8 seconds, until the blue

LED flashes and you hear it beep.

4. Place the Wireless PTT100A handset back into the PTT-W1A

gateway cradle and after a few seconds the Wireless PTT100A

handset will sound a confirmation two-tone and pairing has

completed.

5. LED will be a solid blue once paired.

NOTE:

PTT100A charging cradle grey button only acts as an ON/OFF

button. Find Me™ feature is only available via the PTT-W1A

Handset and when triggered on the PTT-W1A an alert will sound

on both the PTT100A and PTT-W1A handsets.

Talkaround - Available only on Dual Mode models

Talkaround allows users to converse amongst the Wireless PTT

handsets connected to the main gateway cradle without their audio

being transmitted over the satellite network. It is activated by pressing

the ‘grey’ button on top of the Wireless PTT handset.

Volume Control

When you first activate the unit you should first ensure your handset

volume is set to a comfortable listening level. You may then adjust

the Wireless PTT Handset volume by pressing the two left volume

buttons to decrease. There are 5 listening levels. The minimum level is

not zero but is designed so you can still quietly hear radio traffic and

not inadvertently turn off the audio.

Transmitting/Receiving

Use the handset like any two-way radio speaker microphone. i.e. press

the PTT button to talk and release to listen. A short talk permit tone

sequence will sound when activated. Speak with a normal strong

clear voice about 3-5cm (2”) from the microphone port. Too hard or

too soft will degrade the clarity of transmission.

NOTE: When the Wireless Handset is in the cradle, all functionality is

disabled and will switch to charging mode. To make or receive calls,

the user must take the Wireless PTT Handset out of the cradle. If in use

in a vehicle, please ensure to clip the handset to your shirt for safety.

Out of Range Indication

The Wireless PTT Handset provides the user with audible feedback

should the user move out of range from their vehicle. If you walk out

of range the red status LED will flash. If you then push the PTT an

alert tone will sound to let you know your call is not getting through.

Depending on your location, you may find you need to walk back

about 10 meters closer to your vehicle to re-connect.

Talk Permit Tone

The Wireless PTT Handset provides talk permit tones so users know

when to start speaking so that words are not lost at the start of a

Iridium Extreme PTT Grab ‘N’ Go Grab ‘n’ Go Kits User Manual

transmission. If the channel is busy, no channel grant or you are out

of range, the user will hear the Wireless Handset talk permit tones

followed by the radio BUSY or Out of Range tone.

Charging Confirmation Tone

The Wireless PTT Handset provides the user with a discrete tone

whenever the handset is returned to the charging cradle. This discrete

tone ensures the user has a positive indication that the handset is

charging and seated correctly in the cradle.

Earpiece Operation

The Wireless PTT Handset provides the user with a weather protected

3.5mm earpiece jack to allow use of industry standard earpieces

thereby providing additional privacy of communications. A range

of earpiece styles are available to suit individual user preferences.

Plugging in an earpiece disables the internal loudspeaker.

Headset Accessory

The 6 pin industrial connector at the bottom of the wireless handset

also allows the use of a variety of heavy duty and lightweight

headsets and application specific audio accessories to enhance

your communications capability. Use either the headset/accessory’s

integral PTT or use the wireless handset to transmit. The internal

speaker is immediately disabled when a headset is plugged in.

N.B. See page 8 for safety warning regarding use of headsets.

Accessory Mic Boost

Users can increase an audio accessory’s microphone gain on the

handset models fitted with the Hirose accessory port to cater for

sensitivity requirements or variations in headset manufacturer’s

specifications. To activate the higher sensitivity, the Wireless Handset’s

blue VOLUME UP button should be held down while powering up.

The user will thereafter hear 2 short confirmation beeps at the end of

each start up tone sequence. To revert to normal sensitivity, the unit

should be powered up with the VOLUME DOWN blue button held

down.

NOTE: This does NOT affect the sensitivity of the handsets normal

internal front cover microphone.

Dock Loudspeaker Operation

(Corded and Wireless Handset)

The BEAM DriveDOCK Extreme includes the standard loudspeaker (as

used in normal Phone hands-free calling). This loudspeaker can also be

configured to provide audio in PTT operation. This provides an extra

output in addition to the handset.

To use the DriveDOCK Extreme loudspeaker with the handset:

1. Press/hold the Dock Ringer button for 2 seconds. This will

change to the DriveDOCK Extreme loudspeaker mode, and will

be signified by playing the triple rising tone in the DriveDOCK

Extreme speaker and PTT speaker. Also the Ringer LED will flash

GREEN 3 times.

2. Audio is now set to output on both the DriveDOCK Extreme

speaker and the handset.

To revert to using the handset speaker only:

1. Press/hold the Dock Ringer button for 2 seconds. This will

change to the handset speaker mode, and will be signified by

playing the triple rising tone in the Wireless Handset speaker

(not the DriveDOCK Extreme speaker). Also the Ringer LED will

flash GREEN 3 times.

2. Audio is now set to be silent to the DriveDOCK Extreme

loudspeaker. The audio output setting is saved even when the

dock is switched off.

MODE

Default Mode

Mode 1. HFI (Hands Free

- External Speaker and

Mic Only)

Mode 2. Corded/

Wireless PTT Handset

Only (HFI Disabled)

Mode 3. Corded/Wire-

less PTT Handset and

External Speaker Only

Use Mode 1 or Mode 3.

with Privacy Handset

and HFI

Switch Modes

While in a call press the

Ringer button for 2-3

seconds to move to

mode 2.

While in a call press the

Ringer button for 2-3

seconds to move to

mode 3.

While in a call press the

Ringer button for 2-3

seconds to move to

mode 1.

Visual Indicator

Phone Mode: Mute button

not lit

Phone Mode: Mute button

Red

Phone Mode: Mute button

Red

Per Mode 1 or 3

External Speaker Yes No Yes

Yes (Privacy Handset

in cup)

External Microphone Yes No No

Yes (Privacy Handset

in cup)

PTT Handset (Speaker/

Mic)

Speaker Only Yes Yes No

Privacy Handset No No No Yes

Incoming Ring Alert

External Speaker and PTT

handset

External Speaker and PTT

handset

External Speaker and PTT

handset

External Speaker Only

Answer a Call

9575 Green Send key

Single Press on PTT button

9575 Green Send key

Single Press on PTT button

9575 Green Send key

Single Press on PTT button

9575 Green Send key (HFI)

9575 Green Send key and

Uncup Privacy Handset

directly

Reject a Call

9575 Red End key

Double Press on PTT

button

9575 Red End key

Double Press on PTT

button

9575 Red End key

Double Press on PTT

button

9575 Red End key

End Call

9575 Red End key

Double Press on PTT

button

9575 Red End key

Double Press on PTT

button

9575 Red End key

Double Press on PTT

button

9575 Red End key

PTT Grab ‘n’ Go Case - Phone Mode

Iridium Extreme PTT Grab ‘N’ Go Grab ‘n’ Go Kits User Manual

MODE Mode 1: Default Mode

External Speaker with Corded/

Wireless Handset

Mode 2: Corded/Wireless Hand-

set Only

Mode 1: With Privacy Handset

Only

Switch Modes

Press the Ringer button for 2-3

seconds, to move to mode 2

Press the Ringer button for 2-3

seconds, to move back to mode 1

External Speaker Yes No Yes (Privacy Handset in cup)

External Microphone No No Yes (Privacy Handset in cup)

PTT Handset (Speaker/Mic) Yes Yes* No

Privacy Handset No No Yes

Make a PTT Call Press PTT button Press PTT button

Press 9575 convenience key

(Privacy Handset uncupped)

* NOTE: When the PTT handset is in the cradle, all functionality is disabled and will switch to charging mode. To make or receive

calls, the user must take the wireless PTT handset out of the cradle. If in use in a vehicle, please ensure to clip the handset to your shirt

for safety.

PTT Grab ‘n’ Go Case - PTT Mode

GREEN ORANGE

Flashing

Telephony mode

detected from 9575

PTT mode detected

from 9575

GREEN RED BLUE ORANGE

ILLUMINATED N/A

Mic / Uplink

audio Mute

N/A N/A

GREEN RED BLUE ORANGE

FLASHING (slow)

Incoming call

ringing

N/A N/A

Privacy

Handset or

Intelligent

Handset in

use.

FLASHING (fast) N/A N/A

Ring tone

playback

N/A

BLUE ORANGE

ILLUMINATED

Connected with a paired BT device.

Ready for accepting incoming call or

switch to an active call

N/A

FLASHING (fast) Searching a paired BT device N/A

FLASHING (slow) BT device is being used in a call N/A

ALTERNATING

Bluetooth® in Discovery Mode

Blue Orange

BLUE ORANGE

FLASHING (slow) N/A

Error Mode (Check

Error log codes in

Eagle)

ALL BUTTONS BLUE ORANGE

FLASHING (slow) N/A

Charge Only Mode

– all LEDs ash (2 at

a time)

DriveDOCK Extreme Button LED Status (Phone Mode)

DriveDOCK Extreme Button LED Status

(PTT Mode)

La page charge ...

Beam PTTGNG-W1AB2 Le manuel du propriétaire

Marque: Beam

Modèle: PTTGNG-W1AB2

Catégorie: Téléphones

Taper: Le manuel du propriétaire

Ce manuel convient également à

Télécharger le PDF

rapport

dans d''autres langues

English: Beam PTTGNG-W1AB2 Owner's manual

Beam PTTGNG-W1AB2 Le manuel du propriétaire

Ce manuel convient également à

Beam PTTGNG-W1AB2 Le manuel du propriétaire

dans d''autres langues

Documents connexes

Autres documents
