Model
DIR-110
USER MANUAL Internet Radio
HANDLEIDING Internetradio
BEDIENUNGSANLEITUNG Internetradio
MODE D’EMPLOI Radio internet
MANUAL DEL USUARIO Radio por Internet
Version: 1.0
Index:
English .................................................................................................................................................... 3
Nederlands ........................................................................................................................................... 18
Deutsch ................................................................................................................................................ 34
Français ................................................................................................................................................ 50
Español ................................................................................................................................................. 66
3
English DIR-110
1. Safety Precautions
 Do not use this device near water.
 Clean only with a slightly damp cloth.
 Do not cover or block any ventilation openings. When placing the device on a shelf, leave
5 cm (2”) free space around the whole device.
 Install in accordance with the supplied user manual.
 Don’t step on or pinch the power adaptor. Be very careful, particularly near the plugs and the
cable’s exit point. Do not place heavy items on the power adaptor, which may damage it. Keep
the entire device out of children’s reach! When playing with the power cable, they can seriously
injure themselves.
 Unplug this device during lightning storms or when unused for a long period.
 Keep the device away from heat sources such as radiators, heaters, stoves, candles and other
heat-generating products.
 Avoid using the device near strong magnetic fields.
 Electrostatic discharge can disturb normal usage of this device. If so, simply reset and restart
the device following the instruction manual. During file transmission, please handle with care
and operate in a static-free environment.
 Warning! Never insert an object into the product through the vents or openings. High voltage
flows through the product and inserting an object can cause electric shock and/or short circuit
internal parts. For the same reason, do not spill water or liquid on the product.
 Do not use in wet or moist areas such as bathrooms, steamy kitchens or near swimming pools.
 Do not use this device when condensation may occur.
 Although this device is manufactured with the utmost care and checked several times before
leaving the factory, it is still possible that problems may occur, as with all electrical appliances.
If you notice smoke, an excessive build-up of heat or any other unexpected phenomena, you
should disconnect the plug from the main power socket immediately.
 This device must be well ventilated at all time!
 This device must operate on a power source as specified on the specification label. If you are
not sure of the type of power supply used in your home, consult your dealer or local power
company.
 The socket outlet must be installed near the equipment and must be easily accessible.
 Do not overload ac outlets or extension cords. Overloading can cause fire or electric shock.
 Keep away from rodents. Rodents enjoy biting on power cords.
 Always hold the plug when pulling it out of the main supply socket. Do not pull the power cord.
This can cause a short circuit.
 Avoid placing the device on any surfaces that may be subject to vibrations or shocks.
 To protect the device during a thunderstorm, unplug the ac power adaptor.
 When the device is not in use for long periods, unplug the ac power adaptor for safety reasons.
 To clean the device, use a soft dry cloth. Do not use solvents or petrol based fluids. To remove
severe stains, you may use a damp cloth with dilute detergent.
 The supplier is not responsible for damage or lost data caused by malfunction, misuse,
modification of the device or battery replacement.
 The apparatus shall not be exposed to dripping or splashing and make sure that no objects
filled with liquids, such as vases, are placed on or near the apparatus.
 To completely disconnect the power input, the mains plug of the apparatus shall be
disconnected from the mains, as the disconnect device is the mains plug of apparatus.
 The mains plug of the apparatus should not be obstructed or should be easily accessed during
intended use.
 Battery shall not be exposed to excessive heat such as sunshine, fire or the like.
 The ventilation should not be impeded by covering the ventilation openings with items such as
newspapers, table-cloths, curtains etc.
 No naked flame sources such as lighted candles should be placed on the apparatus.
 Attention should be drawn to the environmental aspects of battery disposal.
4

The apparatus can only be used in moderate extremely cold or climates warm environments
should be avoided.

The rating label has been marked on the bottom panel of the apparatus.

This device is not intended for use by people (including children) with physical, sensory or
mental disabilities, or a lack of experience and knowledge, unless they’re under supervision or
have received instructions about the correct use of the device by the person who is responsible
for their safety.

This product is intended for household use only and not for commercial or industrial use.

Make sure the unit is adjusted to a stable position. Damage caused by using this product in an
unstable position or by failure to follow any other warning or precaution contained within this
user manual will not be covered by warranty.

Never remove the casing of this apparatus.

Never place this apparatus on other electrical equipment.

Do not use or store this product in a place where it is subject to direct sunlight, heat, excessive
dust or vibration.

Do not clean this product with water or other liquids.

Do not block or cover the slots and holes in the product.

Do not push foreign objects into the slots or holes in the product.

Do not allow children access to plastic bags.

Please check that the voltage on the type plate of your appliance corresponds with your house
electricity supply (type plate is located on the back of the unit).

Protect the power cord from being walked on or pinched, particularly at plugs, convenience
receptacles, and the point where they exit from the apparatus.

Only use attachments/accessories specified by the manufacturer.

Refer all servicing to qualified service personnel. Servicing is required when the apparatus has
been damaged in any way, such as the power supply cord or the plug, when liquid has been
spilled or objects have fallen into the apparatus, when the apparatus has been exposed to rain
or moisture, does not operate normally, or has been dropped.

Do not use a damaged power cord or plug or a loose outlet. Doing so may result in fire or
electric shock.

Warning: prolonged exposure to loud sounds from personal music players may lead to
temporary or permanent hearing loss.

To reduce the risk of electric shock, do not remove screws. The device does not contain any
user-serviceable parts. Please leave all maintenance work to qualified personnel.

It is not recommended to use headphone with the device via 3.5mm Audio
Out socket. In case of using the headphones, be reminded that excessive
sound pressure or volumes from headphones or earphones can lead to
damage to the hearing. Always adjust the volume to a pleasant, not too loud
level. If you have adjusted the volume of the headphones to be too high and
use that for an extended period, it can damage the listener’s hearing.

Where the mains plug is used as the disconnect device, the disconnect device shall remain
readily operable.

The cell batteries shall not be exposed to excessive heat such as sunshine, fire or the like.
5
2. Product Overview
6
1. Display
2. Standby
3. Mode
4. Home
5. Fav
6. Sleep
7. Left
8. Alarm
9. Right
10. Vol/Nav/Ok: Rotate=Vol/Scroll Press=Select
11. Power on/off
12. DC-IN
13. Line-out (3.5mm)
14. Aux-in (3.5mm)
15. USB Socket
16. Antenna
7
Remote Control
1. Remote Transmitter
2. Standby button
3-12. Input letters and numbers
13. Up Cursor button
14. Left cursor button
15. Right cursor button
16. Enter button
17. Down cursor button
18. Play/Pause button
19. Stop button
20. Home button
8
21. Vol+/-
22. Go back/forward one track
23. Mode selection button
24. Alarm setting button
25. Mute button
26. Dimmer button
27. Sleep button
28. Fav button
29. Language selection button
30. Fav+ button
31. EQ set tone
3. INITIAL USE
Before operation, please make sure that the VOLTAGE mentioned on the power supply is same as
the voltage of your local area.
Use the supplied mains adaptor to connect the device to a household mains socket.
Switch the device on with the power switch on the rear.
When it is the first time running the device, the system will ask you to set Language and Network
Configurations. You may setup the network connection immediately, or set it later. Use Navigate to
select the desired option. Press Navigate/OK to confirm.
Press Standby button when unit is power on, unit will go to standby mode. Press again will make it
On again.
9
4. Network configuration
1. Normal network configration
Select “Yes” for the normal Wireless Network Configuration: The select the required AP by turning
“Navigate” and confirm it by pressing “Navigate/OK”.
Enter WEP or WPA code to connect the WiFi network by select the correct character turning the
“Navigate/OK” button.
Press button to select the next character.
In this condition, press button you can turn left and delete the left chracters at the same time:
When the password is complete please press “Navigate/OK” button to confirm.
Note: Below characters are available for the radio:
Numbers (from 0-9)
English letters (from A to Z and from a to z)
Other charcters (DEL, @, Blank, !, ”, #, $, %, &, *, ’, + and (,)
2. WPS PBC network configuration
Select “Yes WPS” when you would like set up with Wireless Network (WPS PBC) feature: If you are
using a router with WPS button, you may set up the network connection simple via WPS function.
Enter it and go to press the WPS button on your router within 120 seconds.
The connection between the router and the Radio will then be configured automatically.
Select “No” when you do not want to install the network at the moment.
3. No network configuration
Pls select “NO” when you do not like to congigure the network connection at the moment.
Press “Standby” for standby. When the actual date and time is shown the network is configuration is
well done. Date and time, as well as alarms-if activated-will still are shown on the display when in
standby mode.
10
5. INTERNET RADIO
Switch on “Standby” and rotate Navigate to scroll through the main menu. Press OK (to enter sub
menus or confirm settings)
Press to return to the previous menu.
After the connection of any station is succeeded, station information’s will be shown: infomation
content can be changed with or button.
My Favorites
List of my favorite preset stations. It supports 250 favorite entries including stations and folder.
During the station playing screen, press and hold Fav on the device or “Fav. +” on the remote control
to save the station as my favorite. You may replace the previous saved station to the new one.
If the Selected station have been saved, you cannot save it again. The saved stations are showed
under this menu. You may also press Fav to enter the saved station list. You may enter the number
key on the remote control to recall the saved station.
Under the preset station list, move to your station, press OK from unit or Enter from remote control
to listen.
Enter its submenu with button, Shift Up/Down along the list, Rename, Play, or Use as Alarm
Sound (if you chose internet as alarm sound in alarm configuration).
Radio Station/Music
Station are categorized into Global Top 20, Genre and Country/Location (Australia, Canada, United
Kingdom, USA). Enter to continue the subcategories and choose the station to listen.
For each station, pressOK from unit or Enter from remote control to play directly.
Press to enter its submenu. When you choose Auto Scan, it becomes the playback of marquee
of each station in the subcategory. Each station plays 30 seconds until all have played or you press
“Select” to stop the marquee listening. Press button to view the display information of the
playing station.
Local Radio:
Stations are categorized to the country/location which the unit is operated.
History:
List of the ten recently listened stations.
Service:
Search radio station-Enter your keyword to search radio station from the list.
Add new radio by adding IP address, the added stations will be stored in My Favorite.
Note that the maximum character of the station name is 250.
6. Media Center
Select the USB/UPnP mode or playlist mode with Navigate/OK or with the Mode button.
11
UPnP
If you have set up shared media, you should see the shared media from UPnP.
If you have more than one computer sharing media, the alternatives are listed.
Select the shared media you want to play.
Use Play/Pause (18), Next/Prev (22) and Stop (19). Press Right cursor button (15) to view the display
information of the playing track.
Note: The radio can only read the track with the file name less than40charaters. the characters
should be in European Language. If you encounter failure of reading the track under UPnP mode,
youmay try to rename the file. However, if the track is still unable to play, you can try converting the
file to different formats.
USB:
From this point on, menus are generated from the folders on the USB device. It can support
WMA/MP3/AAC/AAC+/FLAC/WAV format. FLAC can support 16Bit/8K~48K Sample Rate, 64Kbps.
Brows folders with the NAV wheel or direction keys (13/14/15/17) on the remote control.
The display shows folder and file names (not necessarily track names).
Once you have found a track you want to play, press the navigate wheel on the device or press Enter
on the remote control.
Note: The USB port does not support data transfer with a computer.
My Playlist:
You can create a playlist of favourious music from UPnP. When you playing the music, press and hold
OK from unit or Enter from remote control to save it into My Playlist.
Clear My Playlist
Pls select this option for clearing the playlist. Pls confirm the questions.
7. My media U
Display and playback your own mediaU station list on the mediaU server. Set your account first.
Toactivate your own station list, follow the steps below:
Access http://www.mediayou.net/. Join my mediaU membership. Login to the website;
Enter the wireless MAC addresss of Radio to the mediaU website. This information can be obtained
in information Center > System information > Wireless Info;
When successfully configured, you are able to save and view your own mediaU station playlist(s).
Usename and password are not required to enter to the Radio.
If there are different accounts stored in Radio, you can choose the one you currently use under
Configuration menu. On the website, you may save stations to Favorite Station, set Favorite
Location/Genre and My Local City, or add stations manually. The stations can be viewed from My
Media mode on the Radio.
12
8. Information Center
Weather
There are weather information and forecasts for 2000 cities.
Select the country and then the city for the weather details.
Press / to see the weather forecasts.
The device is able to display the weather information on the standby mode. On the weather
information page, press Select to set the city to displaying on the standby mode. Then turn on the
weather display.
Financial Info
View the stock index
System Infomation
View details of units and of connect network. The information includes MAC address which you are
required to fill in when registration of “my mediaU” membership.
9. CONFIGURATION
Time Display Analog/digital
My MediaU When it is enabled, My mediaU will exist on the main menu. If various
mediaU accounts exist in the Radio, Select the default login account in here.
Network Wireless Network Configuration: Enable/disable WiFinetwork. When you
enable the WiFi network, the system will automatically select the required
AP. Enter WEP or WPA code to connect the WiFi.
Wireless Network (WPS PBC): If you are using a router with WPS/QSS
button, you may set up the network connection simple via WPS function.
Enter it and go to press the WPS/QSS button on your router within
120 seconds. The connection between the router and Music Link will then
be configured automatically.
Manual Configuration: You can choose DHPC (which IP assigned
automatically) or manually input IP address for wireless network
connection. When you select manual setting for wired connection, the
following have to be entered: SSID (nameof access point), IP Address,
subnet mask, default gateway, preferred DNS server, alternate DNS server.
Check Network When Power On: Enable/disable WiFinetwork. When you
enable the WiFinetwork, the system will automatically search the available
AP. Select required AP.
Date & Time Setup the date and time
Set time format display as 12 Hour or 24 Hour
Set date format (YYYY/MM/DD-DD/MM/YYYY-MM/DD/YYYY)
Daylight SavingTime (DST)
ON
Tips: On the model of “ON”, the time will be one hour More than the actual
time.
13
OFF
Tips: On the model of “OFF”, the time will be same as the actual time. If it
was on the model of the “Daylight Saving Time (DST) and you choose “OFF”,
the time will be deducted one hour, that’s to say, the time will be same as
the actual time.
Alarm There are three independent alarms-2 alarms of absolute time setting
(Alarm 1 and Alarm 2) and 1 alarm for relative time setting (Alarm NAP).
Press Alarm on the remote control to enter this menu directly.
Note that the alarm source is from the preset Internet radio if Alarm Sound
is set to be Internet Radio. It can only set one same IR station for Alarm 1
and Alarm 2. When the alarm is reached the unit connects to the Internet if
the set network is available. Therefore there may be some delay from the
alarm to the radio play. If no network is connection can be established
within one minute, the alarm will change to Melody automatically.
When Alarm “NAP” is set, it alarms once in 5/10/20/30/60/90/120 minutes
depending on which one you have set.
Choose Alarm Volume to configure the volume of the alarms.
Timer Countdown timer (max. 100min)
Language English/Deutsch/Espanol/Francais/Portugese/Nederlands/Italiano/Pyccknn/
Svenska/Norske/Dansk/Magyar/Cesky/Slovensky/Polski/Turkce/Suomi
Dimmer Turn on/Backlight level
Display color/monochrome
Power Mgmt Configure to go to standby mode automatically during in the menu or/and
without Wifisignal. Choose the power management timer (5/15/30mins) to
set the duration of the radio to switch standby mode automatically when
you are not controlling it. Choose Turn off to ignore the power management
function.
Sleep Timer Turn off or set the sleep timer of 15/30/60/90/120/150/180 minutes. Once
the time is set, there will be a bed icon with remaining minutes at the top
right corner and the device will turn to standby then. Press Sleep on the
remote control for the shortcut of this function.
Buffer Configure the buffer time of the music playback, 2/4/8 seconds.
Weather Activate/deactivate the weather forecast for the standby display. Choose
your preferred temperature unit (°F or °C) and then proceed entering your
location. When activated, the weather forecast is shown in turns with the
clock display on the standby screen (each 10 secs).
Local Radio Setup There is a shortcut Local Radio under Internet Radio so that you can easily
go to the station list of your location. You may Manual Setup your location,
or let the system Auto Detect your current location. The system detects the
location according to the IP address of your connected network. Press Local
Station to enter this local radio list directly.
Playback Setup Select the playback mode of media center-Off (no repeat or shuffle),
Repeat all, Repeat one, or Shuffle.
Device Default device name for DLNA is “AirMusic”. You may rename it for DLNA
setup on th PC or mobile. QR code for downlode and install “AirMusic”
control App.
Equalizer Default equalizer is Normal, you may change to Flat, Jazz, Rock,
Soundtracks, Classical, Pop, or News. Press EQ on the remote control to
swap among the EQ mode for shortcut.
14
Resume When
Power On
The system is default to resume internet radio playback if you were
listening to internet radio or media center before switch off the unit. If turn
this setting off, the system will remain in the main menu when switching on
the unit.
Software Update Update software. If there is an updated software version on the server, the
system will notify you. Before starting a software upgrade, ensure that the
unit is plugged into a stable mains power connection. Disconnecting power
during a software update may permanently damage the unit.
Reset to Default Restore the default settings. After the DIR-100 is reset, the system will
move to language is elected.
10. DLNA/UPnP
You may change the default DLNA name as you like. Theinformationbelow is the
introductionofhowtosetup media streaming from PC or other media server. Study the own
instruction of the software or apps you use to enjoy music streaming if necessary. Make sure the
music files are in the format of MP3, WHA, WAV or AAC for music streaming to the radio.
UPnP
Connect the PC to the network.
Ensure the Radio is powered on and connected to the same network.
Open the UPnP platform Windows Media Player (11 or later). Alternatively, other platforms or
serversuch as Windows Media Connection may be used.
Allow to share your media to Radio.
Add the audio files and folders you want to share with radio to the media library.
You may also enjoy the streaming music from other music server, such as smart phone (Android
platform)
Connect the mobile to the network
Search and install media sharing apps from Google Play.
Add the audio files from your mobile you want to share.
After setup the shared server, choose the music and control playback on the Radio.
DLNA
Besides UPnP, Radio supports DLNA function, you share the music files from PC or Android mobile,
and you use your PC, Android mobile or iPhone/iPad to control music playback on the Radio. (It is
not required to control each playback on the Radio.)
The PC system requirement for DLNA is Windows 7 and Windows Media Player 12. Setup as below:
First, share the media on your PC to Radio.
Control Panel > Network and Internet > Network and Sharing Center > Change Advanced Sharing >
Media streaming options
15
Open Windows Media Player to enable Allow remote control of my Player.
Right click any music in the library and choose Play to Radio.
There will be a window for controlling music playback on Radio.
You may search and install any free or commercial DLNA apps from Google Play or Apple Store if you
are using Android mobile, tablet or iPhone/iPad. It is suggested to use bubble UPnP, Twonky Beam
on Android mobile, tablet or Twonky Beam on iPhone/iPad. Some apps may not support streaming
music from iPhone/iPod but iPhone/iPod could still be used to control streaming music from other
servers.
Procedures for playing shared music on the app are as follows:
Select Radio as the player. Some apps may allow to play the music to multi players at the same time.
Select music server and choose the music. Some app can create a playlist if you choose several music.
Please note: When using DLNA music streaming function on theInternetRadio, youcan only control
the volume and standby via the unit. It is restricted to control the other functions. StopDLNA on PC,
mobile or tabletbefore you resume Internet radio’s own control.
11. AUX (Line input)
Aux in mode plays audio from an external source such as an MP3 player. To play audio with Aux in mode:
Turn the volume low on both the Radio and if adjustable, the audio source device.
Connect the external audio source to the AUX IN 3.5mm stereo socket.
Either press MODE until the display, shows AUX IN or select AUX in under Main menu.
Adjust the volume of the Radio (and, ifnecessary, the audio source device) as required.
12. FM operation
With your radio on, press the Mode button to select FM mode or press / button to select
FM mode in the menu.
Press the / button to manually tune to specific frequencies by 0.05MHz per step.
The radio also includes the scan feature of FM, allowing you to automatically tune to FMstations.
Press and holdthe button to automatically search for the next available radio station. When a
station with good signal is found, it will be automatically played.
You can search for stations in the opposite direction by pressing and holding the button.
Press the Navigate/OKrotary knob, it can automatically scan fully and store the 20 stations (the max).
Storing stations as presets
Radio can store 20 stations as presets in FM mode. To store a preset:
Tune to the station you like, press and hold the Fav button, then using the / button or
rotate the Navigate/OKrotary knobto select desired preset number, then press Vol/Nav/Okrotary
knob to store the station.
16
Playing stations saved as presets
To play a preset station:
Select the band FM of the station by pressing the Mode button or press / button to select
FM mode in the menu.
Press the Fav button to recall the preset station, then using the / button or rotate the
Navigate/OKrotary knobto browse through your presets and press the Navigate/OKrotary knob to
confirm.
13. Technical Specifications
Network 802.11b/g/n (WLAN) Encryption: WEP, WPA, WPA 2 (PSK), WPS
Streaming UPnP, DLNA
Supported filetypes WMA, MP3, OGG
Connections DC, USB (charging 5V 0.5A), 3.5mm AUX-IN, 3.5mm Line-Out
Input 100-240V~50/60 Hz, 0.15A max
Output 5.9V/2A
Batteries in remote control 2 x AAA (non included)
Power consumption 5W
Power consumption (standby) <1W
Operating Temperature 0°C-35°C
Operating position Horizontal
Power supply adaptor: (For EU only)
Manufacturer: Shenzhen Adition Audio Science & TechnologyCo, Ltd
Model Number: AD120592000EU
Use only original AC adaptor
Use only the power supply listed in the user instructions.
Dim. unit 235 x 116 x 130 mm (WxDxH)
Weight 1kg
14. Guarantee
Lenco offers service and warranty in accordance with the European law, which means that in case of
repairs (both during and after the warranty period) you should contact your local dealer.
Important note: It is not possible to send products that need repairs to Lencodirectly. Important
note: If this unit is opened or accessed by a non-official service center in any way, the warranty
expires. This device is not suitable for professional use. In case of professional use, all warranty
obligations of the manufacturer will be voided.
15. Disclaimer
Updates to Firmware and/or hardware components are made regularly. Therefore some of the
instruction, specifications and pictures in this documentation may differ slightly from your particular
situation. All items described in this guide for illustration purposes only and may not apply to particular
situation. No legal right or entitlements may be obtained from the description made in this manual.
17
16. Disposal of the Old Device
This symbol indicates that the relevant electrical product or battery should not be
disposed of as general household waste in Europe. To ensure the correct waste
treatment of the product and battery, please dispose them in accordance to any
applicable local laws of requirement for disposal of electrical equipment or
batteries. In so doing, you will help to conserve natural resources and improve
standards of environmental protection in treatment and disposal of electrical
waste (Waste Electrical and Electronic Equipment Directive).
17. Service
For more information and helpdesk support, please visit www.lenco.com
Lenco Benelux BV, Thermiekstraat1a, 6361 HB, Nuth, The Netherlands.
18
Nederlands DIR-110
1. Veiligheidsvoorschriften
 Gebruik dit apparaat niet in de buurt van water.
 Reinig het uitsluitend met een licht vochtige doek.
 Bedek of blokkeer de ventilatie-openingen niet. Wanneer u het apparaat op een schap plaatst,
dient u 5 cm (2”) vrije ruimte rondom het gehele apparaat te behouden.
 Installeer het product volgens de meegeleverde gebruikershandleiding.
 Nooit op de stroomadapter stappen of deze indrukken. Wees voornamelijk voorzichtig in de
buurt van de stekkers en het punt waar de kabel uit het apparaat komt. Plaats geen zware
voorwerpen op de stroomadapter, om beschadiging ervan te voorkomen. Houd het gehele
apparaat buiten bereik van kinderen! Wanneer kinderen met de voedingskabel spelen, kunnen zij
ernstig letsel oplopen.
 Haal de stekker uit het stopcontact tijdens onweer of wanneer u deze langere tijd niet gebruikt.
 Houd het apparaat uit de buurt van hittebronnen, zoals radiateurs, verwarmingen, kachels,
kaarsen en andere hittegenererende producten.
 Gebruik dit apparaat niet in de buurt van krachtige magnetische velden.
 Elektrostatische ontlading kan normaal gebruik van dit apparaat verstoren. U hoeft het
apparaat in dit geval slechts te resetten en opnieuw op te starten volgens de
gebruikershandleiding. Wees voorzichtig tijdens bestandsoverdracht en doe dat in een
omgeving zonder statische verstoringen.
 Waarschuwing! Steek nooit een voorwerp via de ventilatie- of andere openingen in het product.
Er is hoogspanning in het product aanwezig en als u er een object insteekt, kan dat een
elektrische schok veroorzaken en/of kortsluiting in de interne onderdelen. Mors om dezelfde
reden geen water of vloeistof op het product.
 Gebruik het toestel niet in vochtige ruimtes, zoals badkamers, stomende keukens of in de buurt
van zwembaden.
 Gebruik dit apparaat niet wanneer condensatie kan optreden.
 Alhoewel dit apparaat met grote zorg gefabriceerd en verschillende keren geïnspecteerd is
voordat het de fabriek verlaat, is het nog steeds mogelijk dat er problemen optreden, zoals met
alle elektrische apparaten. Als u rook, een overmatige hitteontwikkeling of enig ander
onverwacht verschijnsel opmerkt, moet u onmiddellijk de stekker van het netsnoer uit het
stopcontact halen.
 Dit apparaat moet te allen tijde goed worden geventileerd!
 Dit apparaat moet aangedreven worden door een voedingsbron, zoals aangegeven op het
specificatieplaatje. Als u twijfelt over het type voeding dat gebruikt wordt in uw huis, raadpleeg
dan a.u.b. uw dealer of plaatselijk energiebedrijf.
 Het stopcontact moet in de buurt van de apparatuur zijn geïnstalleerd en eenvoudig te
bereiken zijn.
 Overbelast stopcontacten of verlengsnoeren niet. Overbelasting kan brand of een elektrische
schok veroorzaken.
 Houd ze uit de buurt van knaagdieren. Knaagdieren knauwen graag aan voedingskabels.
 Houd altijd de stekker vast wanneer u deze uit het stopcontact trekt. Trek nooit aan de
voedingskabel. Dit kan tot een kortsluiting leiden.
 Vermijd om het toestel te plaatsen op een ondergrond die blootgesteld kan worden aan
trillingen of schokken.
 Om het apparaat tijdens onweer te beschermen, haalt u de netvoedingadapter uit het
stopcontact.
 Wanneer het apparaat voor een lange periode niet in gebruik is, haalt u de netvoedingadapter
om veiligheidsredenen uit het stopcontact.
 Gebruik een zacht, droog doekje om het apparaat te reinigen. Gebruik geen oplosmiddelen of
op benzine gebaseerde vloeistoffen. U kunt een vochtig doekje met verdund
schoonmaakmiddel gebruiken om hardnekkige vlekken te verwijderen.
 De leverancier is niet verantwoordelijk voor schade of verloren gegevens veroorzaakt door
storing, misbruik, modificatie van het apparaat of batterijvervanging.
19

Het apparaat mag niet worden blootgesteld aan druppels of spatten en zorg ervoor dat er geen
met vloeistof gevulde voorwerpen, zoals vazen, op of nabij het apparaat zijn geplaatst.

Om de verbinding met de stroomaansluiting volledig te verbreken, moet de stekker van het
apparaat uit het stopcontact worden gehaald, omdat de stekker van het apparaat de
hoofdschakelaar is.

De stekker van het apparaat mag niet worden belemmerd en moet tijdens gebruik eenvoudig
toegankelijk worden gehouden.

Batterijen mogen niet aan overmatige hitte, zoals zonlicht, open vuur e.d. worden blootgesteld.

De ventilatie mag niet worden gehinderd door het bedekken van de ventilatieopeningen met
voorwerpen zoals kranten, tafelkleden, gordijnen etc.

Plaats geen bronnen met een open vlam, zoals brandende kaarsen, op het apparaat.

Aandacht voor het milieu is nodig bij het verwijderen van de batterijen.

Het apparaat kan alleen worden gebruikt in gematigde klimaten. Extreem koude of warme
omgevingen moeten worden vermeden.

Het nominale specificatielabel is te vinden op het paneel aan de onderkant van het apparaat.

Dit apparaat is niet bestemd voor gebruik door mensen (inclusief kinderen) met fysieke,
zintuiglijke of geestelijke gebreken of gebrek aan kennis en ervaring, tenzij zij onder toezicht
staan of instructies hebben over het juiste gebruik van het apparaat hebben gekregen van de
persoon die verantwoordelijk is voor hun veiligheid.

Dit product is alleen voor huishoudelijk gebruik bedoeld en niet voor commercieel of
industrieel gebruik.

Verzeker u ervan dat het apparaat in een stabiele positie staat opgesteld. Schade, veroorzaakt door
het gebruik van dit product in een onstabiele positie, of door het niet naleven van waarschuwingen
of voorzorgsmaatregelen genoemd in deze handleiding, valt niet onder de garantie.

Verwijder nooit de behuizing van dit apparaat.

Plaats dit apparaat nooit op andere elektrische apparatuur.

Dit product niet gebruiken of opslaan op plaatsen waar het wordt blootgesteld aan direct
zonlicht, hitte, buitensporig veel stof of trillingen.

Reinig dit product niet met water of andere vloeistoffen.

Bedek of blokkeer de gleuven en de gaten in het product niet.

Stop geen vreemde voorwerpen in de gleuven of gaten van het product.

Geef kinderen geen gelegenheid in aanraking met plastic zakken te komen.

Controleer of de spanning op het specificatieplaatje van uw apparaat overeenkomt met het
lichtnet in uw huis (specificatieplaatje is te vinden op de achterzijde van het apparaat).

Zorg ervoor dat niemand op de voedingskabel kan gaan staan of dat de kabel kan worden
ingedrukt, voornamelijk bij stekkers, stopcontacten en het punt waar kabels uit het apparaat
komen.

Gebruik uitsluitend uitbreidingen/accessoires gespecificeerd door de fabrikant.

Laat alle reparaties over aan gekwalificeerd onderhoudspersoneel. Onderhoud is vereist als het
toestel hoe dan ook is beschadigd, zoals bijvoorbeeld het netsnoer of de stekker, wanneer er
vloeistof of een voorwerp in het apparaat is terechtgekomen, wanneer het apparaat is
blootgesteld aan regen of vocht, als het niet normaal werkt of is gevallen.

Gebruik nooit een beschadigde voedingskabel of stekker of een los stopcontact. Dit vormt
namelijk een risico op brand of elektrische schokken.

Waarschuwing: Langdurige blootstelling aan luid geluid van persoonlijke muziekspelers kan
leiden tot tijdelijke of permanente gehoorbeschadiging.

Verwijder de schroeven niet om het risico van een elektrische schok te verminderen. Het
apparaat bevat geen onderdelen die door de gebruiker kunnen worden onderhouden. Laat al
het onderhoud over aan gekwalificeerd personeel.

Wij raden u niet aan een koptelefoon via de 3,5 mm audio-uitgang op het
apparaat aan te sluiten. In het geval van het gebruik van een koptelefoon,
herinneren wij u eraan dat overmatige geluidsdruk of volume van de
hoofdtelefoon of oortelefoon kan leiden tot gehoorschade. Zet het volume
altijd op een aangenaam, niet te luid niveau. Als u het volume van de
koptelefoon te hoog hebt ingesteld en u gebruikt dat voor een langere
periode, dan kan dat uw gehoor beschadigen.

De stekker wordt gebruikt als schakelaar en moet gemakkelijk bereikbaar blijven.

Batterijen mogen niet aan overmatige hitte, zoals zonlicht, open vuur e.d., worden blootgesteld.
20
2. Productoverzicht
  • Page 1 1
  • Page 2 2
  • Page 3 3
  • Page 4 4
  • Page 5 5
  • Page 6 6
  • Page 7 7
  • Page 8 8
  • Page 9 9
  • Page 10 10
  • Page 11 11
  • Page 12 12
  • Page 13 13
  • Page 14 14
  • Page 15 15
  • Page 16 16
  • Page 17 17
  • Page 18 18
  • Page 19 19
  • Page 20 20
  • Page 21 21
  • Page 22 22
  • Page 23 23
  • Page 24 24
  • Page 25 25
  • Page 26 26
  • Page 27 27
  • Page 28 28
  • Page 29 29
  • Page 30 30
  • Page 31 31
  • Page 32 32
  • Page 33 33
  • Page 34 34
  • Page 35 35
  • Page 36 36
  • Page 37 37
  • Page 38 38
  • Page 39 39
  • Page 40 40
  • Page 41 41
  • Page 42 42
  • Page 43 43
  • Page 44 44
  • Page 45 45
  • Page 46 46
  • Page 47 47
  • Page 48 48
  • Page 49 49
  • Page 50 50
  • Page 51 51
  • Page 52 52
  • Page 53 53
  • Page 54 54
  • Page 55 55
  • Page 56 56
  • Page 57 57
  • Page 58 58
  • Page 59 59
  • Page 60 60
  • Page 61 61
  • Page 62 62
  • Page 63 63
  • Page 64 64
  • Page 65 65
  • Page 66 66
  • Page 67 67
  • Page 68 68
  • Page 69 69
  • Page 70 70
  • Page 71 71
  • Page 72 72
  • Page 73 73
  • Page 74 74
  • Page 75 75
  • Page 76 76
  • Page 77 77
  • Page 78 78
  • Page 79 79
  • Page 80 80
  • Page 81 81

Lenco DIR-110 Manuel utilisateur

Catégorie
Radios
Taper
Manuel utilisateur
