IMPORTANT NOTE

The mains lead on this equipment is supplied with a

moulded plug incorporating a fuse. The value of the

fuse is indicated on the pin face of the plug. If it requires

replacing, a fuse approved to BS1362 of the same

rating must be used.

Never use the plug with the fuse cover omitted if the cover

is detachable. If a replacement fuse cover is

required, it must be of the same colour as the pin face of

the plug. Replacement covers are available from your

dealer.

If the fitted plug is not suitable for the power points in your

house or the cable is not long enough to reach a

power point, you should obtain a suitable safety approved

extension lead or consult your dealer for assistance.

However, if there is no alternative to cutting off the plug,

remove the fuse and then safely dispose of the

plug. Do not connect the plug to a mains jack, as there is a

risk of shock hazard from the bared flexible cord.

The product unit accompanying this user manual is

licensed under certain intellectual property rights of certain

third parties. This license is limited to private non-

commercial use by end-user consumers for licensed

contents.

No rights are granted for commercial use.

The license does not cover any product unit other than this

product unit and the license does not extend to any

unlicensed product unit or process conforming to ISO/IEC

11172-3 or ISO/IEC 13818-3 used or sold in combination

with this product unit. The license only covers the use of

this product unit to encode and/or decode audio files

conforming to the ISO/IEC 11172-3 or ISO/IEC 13818-3.

No rights are granted under this license for product features

or functions that do not conform to the ISO/IEC 11172-3 or

ISO/IEC 13818-3.

Warning

Getting Started

2

- English

TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT

REMOVE THE COVER(OR BACK).

NO USER-SERVICEABLE PARTS ARE INSIDE. REFER

SERVICING TO QUALIFIED SERVICE PERSONNEL.

This symbol indicates “dangerous

voltage” inside the product that presents

a risk of electric shock or personal injury.

This symbol indicates important

instructions accompanying the product.

Do not install this equipment in a confined space

such as a bookcase or similar unit.

WARNING : To prevent damage which may result in

fire or electric shock hazard, do not

expose this appliance to rain or

moisture.

CAUTION : DVD RECORDER USES AN INVISIBLE

LASER BEAM WHICH CAN CAUSE

HAZARDOUS RADIATION EXPOSURE

IF DIRECTED.

BE SURE TO OPERATE RECORDER

CORRECTLY AS INSTRUCTED.

CAUTION

THIS PRODUCT UTILIZES A LASER.

USE OF CONTROLS OR ADJUSTMENTS OR

PERFORMANCE OF PROCEDURES OTHER THAN

THOSE SPECIFIED HEREIN MAY RESULT IN

HAZARDOUS RADIATION EXPOSURE.

DO NOT OPEN COVERS AND DO NOT REPAIR

YOURSELF. REFER SERVICING TO QUALIFIED

PERSONNEL.

This product satisfies CE regulations when shielded cables

and connectors are used to connect the unit to other

equipment. To prevent electromagnetic interference with

electric appliances, such as radios and televisions, use

shielded cables and connectors for connections.

00842C-R125-XEB_02~17 2005.6.29 10:15 PM Page 2

English -

3

Important Safety Instructions

Read these operating instructions carefully before using

the unit. Follow all the safety instructions listed below.

Keep these operating instructions handy for future

reference.

1) Read these instructions.

2) Keep these instructions.

3) Heed all warnings.

4) Follow all instructions.

5) Do not use this apparatus near water.

6) Clean only with dry cloth.

7) Do not block any ventilation openings, Install in

accordance with the manufacturer's instructions.

8) Do not install near any heat sources such as

radiators, heat registers, stoves, or other apparatus

(including amplifiers) that produce heat.

9) Do not defeat the safety purpose of the polarized or

grounding- type plug. A polarized plug has two

blades with one wider than the other. A grounding-

type plug has two blades and a third grounding

prong. The wide blade or the third prong are

provided for your safety. if the provided plug does not

fit into your outlet, consult an electrician for

replacement of the obsolete outlet.

10) Protect the power cord from being walked on or

pinched particularly at plugs, convenience

receptacles, the point where they exit from the

apparatus.

11) Only use attachments/accessories specified by the

manufacturer.

12) Use only with the cart, stand, tripod, bracket, or

table specified by the manufacturer, or sold with the

apparatus. When a cart is used, use caution when

moving the cart/apparatus combination to avoid

injury from tip-over.

13) Unplug this apparatus during lightning storms or

when unused for long periods of time.

14) Refer all servicing to qualified service personnel.

Servicing is required when the apparatus has been

damaged in any way, such as power-supply cord or

plug is damaged, liquid has been spilled or objects

have fallen into the apparatus, the apparatus has

been exposed to rain or moisture, does not operate

normally, or has been dropped.

Handling Cautions

● Before connecting other components to this recorder,

be sure to turn them all off.

● Do not move the recorder while a disc is being

played, or the disc may be scratched or broken, the

recorder’s internal parts may be damaged.

● Do not put a flower vase filled with water or any small

metal objects on the recorder.

● Be careful not to put your hand into the disc tray.

● Do not place anything other than the disc in the disc

tray.

Getting Started

Precaution

● Exterior interference such as lightning and static

electricity can affect normal operation of this recorder.

If this occurs, turn the recorder off and on again with

the STANDBY/ON button, or disconnect and then

reconnect the AC power cord to the AC power outlet.

The recorder will operate normally.

● Be sure to remove the disc and turn off the recorder

after use.

● Disconnect the AC power cord from the AC outlet

when you don’t intend to use the recorder for long

periods of time.

● Clean the disc by wiping in a straight line from the

inside to the outside of the disc.

Maintenance of Cabinet

For safety reasons, be sure to disconnect the AC power

cord from the AC outlet.

● Do not use benzene, thinner, or other solvents for

cleaning.

● Wipe the cabinet with a soft cloth.

Disc Handling

● Use discs with regular

shapes. If an irregular disc

(a disc with a special shape)

is used, this DVD recorder may be damaged.

Holding discs

● Avoid touching the surface of a

disc where recording is performed.

DVD-RAM, DVD-RW and DVD-R

● Clean with an optional DVD-

RAM/PD disc cleaner (LF-

K200DCA1 where available).

Do not use cleaners or cloths

for CDs to clean DVD-

RAM/DVD-RW/DVD-R discs.

DVD-Video, Audio CD

● Wipe off dirt or contamination on the disc with a soft

cloth.

Cautions on handling discs

● Do not write on the printed side with a ball-point pen

or pencil.

● Do not use record cleaning sprays or antistatic.

Also, do not use volatile chemicals, such as benzene

or thinner.

● Do not apply labels or stickers to discs. (Do not use

discs fixed with exposed tape adhesive or leftover

peeled-off stickers.)

● Do not use scratch-proof protectors or covers.

● Do not use discs printed with label printers available

on the market.

● Do not load warped or cracked discs.

00842C-R125-XEB_02~17 2005.6.29 10:15 PM Page 3

● Use a 700MB(80 minutes) CD-R/RW disc. If possible,

do not use a 800MB(90 minutes) or above disc, as

the disc may not play back.

● If the CD-R/RW disc was not recorded as a closed

session, you may experience a delay in the early

playback time, all recorded files may not play.

● Some CD-R/RW discs may not be playable with this

unit, depending on the device which was used to

burn them. For contents recorded on CD-R/RW

media from CDs for your personal use, playability

may vary depending on contents and discs.

● Disc : CD-R/RW, DVD-R/RW/RAM

● MPEG4 File with following extensions can be played.

: .avi, .divx, .AVI, .DIVX

● MPEG4 Codec format : DivX 3.11 DivX 4.x DivX 5.x

DivX-Pro (without QPEL and GMC)

● Available Audio Format : “MP3”, “MPEG”, “WMA”,

“LPCM”, “AC3”

●

Supported subtitle file formats: .smi, .srt, .sub, .psb, .txt, .ass

DVD-R Disc Playback and Recording

● Once a DVD-R recorded in Video Mode is finalised, it

becomes DVD-Video.

● You can record onto the available space on the disc

and perform editing functions such as giving titles to

discs and programmes and erasing programmes

before finalising.

● When programming is erased from a DVD-R, that

space does not become available. Once an area on a

DVD-R is recorded on, that area is no longer a

vailable for recording, whether the recording is

erased or not.

● It takes about 30 seconds for the unit to complete

recording management information after recording

finishes.

● This product optimizes the DVD-R for each recording.

Optimizing is carried out when you start recording

after inserting the disc or turning on the unit.

Recording onto the disc may become impossible if

optimizing is carried out too many times.

● Playback may be impossible in some cases due to

the condition of recording.

● This unit can play back DVD-R discs recorded and

finalised with a Samsung DVD video recorder. It may

not be able to play some DVD-R discs depending on

the disc and the condition of the recording.

DVD-RW Disc Playback and Recording

● Recording and playback can be performed on DVD-

RW discs in both the Video and VR Modes.

● Once a DVD-RW recorded in both the Video and VR

Modes is finalised, you cannot perform addtional

recording.

● Once a DVD-RW recorded in Video Mode is finalised,

it becomes DVD-Video.

● In both modes, playback can be performed before

and after finalisation, but additional recording,

deleting and editing can not be performed after

finalisation.

● If you want to record the disc in VR Mode and then

record in V Mode, be sure to execute Format.

Be careful when executing Format because all the

recorded data may be lost.

4

- English

Disc Storage

Be careful not to harm the disc because the data on

these discs is highly vulnerable to the environment.

● Do not keep under direct sunlight.

● Keep in a cool ventilated area.

● Store vertically.

● Keep in a clean protection jacket.

● If you move your DVD recorder suddenly from a cold

place to a warm place, condensation may generate

on the operating parts and lens and cause abnormal

disc playback. If this occurs, remove the disc and

wait for one to two hours with the power on before

atttempting playback.

Disc Specifications

DVD-Video

● A digital versatile disc (DVD) can contain up to

135-minutes of images, 8 audio languages and 32

subtitle languages. It is equipped with MPEG-2

picture compression and Dolby digital surrounding,

allowing you to enjoy vivid and clear theatre quality

images in the comfort of your own home.

● When switching from the first layer to the second

layer of a dual-layered DVD Video disc, there may be

momentary distortion in the image and sound.

This is not a malfunction of the unit.

● Once a DVD-R/RW recorded in Video Mode is

finalised, it becomes DVD-Video.

Audio CD

● An audio disc on which 44.1kHz PCM Audio is

recorded

● Plays CD-DA format audio CD-R and CD-RW discs.

The unit may not be able to play some CD-R or CD-

RW discs due to the condition of the recording.

CD-R/RW

● Only CD-R discs with MP3 files recorded with

ISO9660 or JOLIET format can be played back

● Only MP3 files with the ".mp3", ".MP3" extension can

be used.

● For MP3 files recorded with a VBR(Variable Bit

Rates), from 32 Kbps to 320 Kbps, the sound may

cut in out.

● Playable bitrate range is from 56Kbps to 320Kbps.

● The unit can handle a maximum of 500 files and 100

folders.

● Only JPEG files with the ".jpg", ".JPG" extension can

be used.

● The unit can handle a maximum of 500 files and 100

folders.

● Maximum size of progressive JPEG is 3M pixels.

● MOTION JPEG is not supported.

MP3 CD-R/RW

JPEG CD-R/RW

Using CD-R/RW

Using MPEG4 disc

Getting Started

00842C-R125-XEB_02~17 2005.6.29 10:15 PM Page 4

English -

5

● A DVD-RW blank disc is initialized to VR Mode when

first initialized.

● DVD-RW (VR mode)

- This is a format that is used for recording data on a

DVD-RAM or DVD-RW disc. You can record

multiple titles, edit, delete, partial delete, create a

playlist, etc.

- A disc that is recorded in this mode may not be

played by existing DVD Recorder.

● DVD-RW (Video mode)

- This is a format that is used for recording data on a

DVD-RW or DVD-R disc. The disc can be played

by existing DVD Recorder once it has been

finalised.

- If a disc that has been recorded in Video Mode by a

different maker’s recorder but has not been

finalised, it cannot be played or additionally be

recorded by this recorder.

DVD-RAM Disc Playback and Recording

● Ensure that the recording mode is set to VR mode.

Otherwise, this product will not be able to play the

recording.

● You cannot play a DVD-RAM in most DVD components

due to compatibility issues.

● Only DVD-RAM standard Version 2.0. discs can be

played in this unit.

● DVD-RAM recorded on this unit may not work with other

DVD components. To determine compatibility with these

DVD-RAM discs, refer to the user’s manual for the DVD

recorder.

● For cartridge type DVD-RAM discs, remove the cartridge

and use the disc only.

Protection

This DVD Recorder can allow you to protect the

contents of your discs, as described below.

● Programme-protected: See page 72

“Locking(Protecting) a Title”

● Disc-protected: See page 84 “Disc Protection”

✻

DVD-RAM/DVD-RW/DVD-R discs that are

incompatible with the DVD-VIDEO format cannot be

played with this product.

✻ For more information on DVD recording compatibility,

consult your DVD-RAM/DVD-RW/DVD-R

manufacturer.

✻ Use of poor quality DVD-RAM/DVD-RW/DVD-R discs

may cause following unexpected problems including,

without limitation, recording failure, loss of recorded

or edited materials or damage to the recorder.

Do not use the following discs!

● LD, CD-G, CD-I, CD-ROM, DVD-ROM, DVD+R and

DVD+RW discs should not be used in this product.

[Note]

Disc types that can be played : CD/CD-R/CD-

RW/MP3/JPEG/DVD-Video/DVD-RAM/DVD-RW/

DVD-R. For a DVD-R/DVD-RW disc, which has been

recorded in Video Mode on another component, it

can play only when finalised.

●

Some commercial discs and DVD discs purchased

outside your region may not be playable with this

product. When these discs are played, either “No disc."

or "Please check the regional code." will be displayed.

● If your DVD-RW disc is an illegal copy or is not in

DVD video format, it may also not be playable.

● We take no responsibility and offer no compensation

for any recording failure, loss of recorded or edited

material and/or damage to the recorder arising from

usage of unrecommended discs.

COPY PROTECTION

● Many DVD discs are encoded with copy protection.

Because of this, you should only connect your DVD

recorder directly to your TV, not to a VCR.

Connecting to a VCR results in a distorted picture

from copy-protected DVD discs.

● This product incorporates copyright protection

technology that is protected by methods claims of

certain U.S. patents and other intellectual property

rights owned by Macrovision Corporation and other

rights owners. Use of this copyright protection

technology must be authorised by Macrovision

Corporation, is intended for home and other limited

viewing uses only unless otherwise

authorised by Macrovision Corporation.

Reverse engineering or disassembly is prohibited.

Disc Maximum no. of recordings by disc type

DVD-RAM 100,000

DVD-RW 1,000

DVD-R 1

Getting Started

❇ We recommend using one of the discs in the

table as they have been confirmed to be

compatible with this unit. Other discs may not

perform correctly.

Media Disc SPEED

TDK 4x

Beall 4x

DVD-R That’s 4x

Maxell 4x

Panasonic 4x

TDK 2x

Maxell 2x

DVD-RW Optodisc 2x

Radius 2x

Verbatim 2x

Maxell 3x

DVD-RAM

Fujifilm 3x

TDK 2x

Panasonic 3x

00842C-R125-XEB_02~17 2005.6.29 10:15 PM Page 5

6

- English

Getting Started

Warning........................................................................2

Precaution...................................................................3

Important Safety Instructions.............................................3

Handling Cautions..............................................................3

Maintenance of Cabinet.....................................................3

Disc Handling .....................................................................3

Disc Storage.......................................................................4

Disc Specifications.............................................................4

General Features........................................................8

Before reading the user’s manual...........................9

How to use the DVD Recorder.................................9

Unpacking .................................................................11

Accessories.......................................................................11

Preparing the Remote Control.........................................11

Setting the Remote Control.............................................11

Description................................................................13

Front Panel.......................................................................13

Front Panel Display..........................................................13

Rear Panel........................................................................14

Tour of the Remote Control.............................................15

Connecting & Setting Up

Quick Overview........................................................16

Connecting the DVD-Recorder..............................17

Additional connections...........................................17

Antenna + DVD Recorder +

external decoder box + TV ....................................18

Other type of connecting the Video output cable

.......18

Case 1 : Connecting to a Video (Composite)

output jack ........................................................19

Case 2 : Connecting to an S-Video output jack.............19

Case 3 : Component Video output jacks........................20

Other type of connecting the Audio output cable ..20

Case 1 : Connecting to your TV......................................20

Case 2 : Connecting to a stereo amplifier with AV

output jacks .....................................................21

Case 3: Connecting to an AV amplifier with a digital

output jack ........................................................21

Connecting HDMI/DVI to a TV

..................................22

Case 1 : Connecting to a TV with HDMI Jack...............22

Case 2 : Connecting to a TV with DVI Jack ..................22

Connecting to AV3 IN, DV input jack....................23

Case 1 : Connecting a VCR, Set-Top Box(STB), DVD

recorder or Camcorder to the AV3 IN jacks ...23

Case 2 : Connecting a Camcorder to the DV IN jack ...23

System Setup

On-Screen Menu Navigation..................................24

Plug & Auto Setup...................................................25

Setting the Clock......................................................26

Presetting Channels with the Auto Setup function

.....27

Presetting Channels with the Manual Setup

function......................................................................28

Setting up the Language Options.........................29

EP Mode Time Setting.............................................30

Automatic Chapter Creation..................................30

Setting up the Front Display Options...................31

Setting up NICAM Options.....................................32

DivX(R) Registration................................................33

Setting up the Audio Options................................33

Audio Options...................................................................34

Setting up Video Output Options..........................34

Setting up the Progressive scan...........................35

Canceling the Progressive scan...........................36

Setting up the Display(Video) Options.................36

Display(Video) Options....................................................37

Output selection ...............................................................37

Setting up the Parental Control.............................38

If you forgot your password.............................................38

About the Rating Level....................................................39

About the Change Password..........................................39

Contents

Getting Started

00842C-R125-XEB_02~17 2005.6.29 10:15 PM Page 6

English -

7

Zooming-In........................................................................60

Using Bookmarks.............................................................60

Using Markers..................................................................61

Playing an Audio CD/MP3 .....................................62

Playing an Audio CD (CD-DA)/MP3...............................62

Playing a Picture......................................................66

Playing an MPEG4...................................................67

Playing the Title List................................................68

Editing

Basic Editing (Title List)...................................................71

Renaming(Labeling) a Title..............................................71

Locking(Protecting) a Title...............................................72

Deleting a Title..................................................................72

Deleting a Section of a Title.............................................73

Advanced Editing (Playlist) .............................................

75

Creating a Playlist............................................................75

Playing Entries in the Playlist..........................................76

Renaming a Playlist Entry...............................................77

Editing a Scene for the Playlist .......................................78

Copying a Playlist Entry to the Playlist...........................81

Deleting a Playlist Entry from the Playlist.......................82

Disc Manager

..............................................................83

Editing the Disc Name.....................................................83

Disc Protection.................................................................84

Formatting a Disc.............................................................84

Delete All Title Lists..........................................................85

Finalising a disc................................................................86

Unfinalising a disc (V/VR mode).....................................87

Additional Information

Troubleshooting.......................................................88

Specifications...........................................................92

Recording

Before Recording.....................................................40

Recordable discs..............................................................40

Recording Formats ..........................................................41

Recording Mode...............................................................41

Unrecordable video..........................................................41

About INFO Key...............................................................42

Checking the available disc space (Disc Information)...42

Recording the current TV programme you are

watching....................................................................42

Recording from external equipment you are

watching....................................................................44

Copying from a Camcorder ...................................45

Making a One Touch Recording (OTR)................46

Making a Timer Recording.....................................47

Flexible Recording (for Timer recording only) ...48

Editing the Scheduled Record List.......................48

Deleting the Scheduled Record List.....................49

Using the ShowView Feature.................................50

ShowView Extended................................................51

Recording the Standard Timer List ......................51

Playback

Before Playing..........................................................52

Region code (DVD-Video only).......................................52

Disc types that can be played.........................................52

Discs that cannot be played............................................52

Playing a Disc...........................................................53

Using the Disc Menu & Title Menu .................................54

Using the Search Functions............................................54

Slow Motion Play..............................................................55

Step Motion Play..............................................................55

About ANYKEY ................................................................55

Using the Repeat Function..............................................56

Selecting the Subtitle.......................................................58

Selecting the Audio language..........................................59

Changing the Camera Angle...........................................59

Getting Started

00842C-R125-XEB_02~17 2005.6.29 10:15 PM Page 7

8

- English

General Features

High quality progressive scan

Progressive scanning provides high resolution and

flicker free video. The 10-bit 54-MHz DAC and 2D Y/C

Separating Circuitry provides the highest image

playback and recording quality. (See page 20, 36)

Avariety of functions with an easy-to-use user

interface

The integrated menu system and the messaging

function allow you to perform desired operations both

easily and conveniently. With a DVD-RAM or DVD-RW

disc, you can edit recorded video, create a playlist, edit

video in a specific sequence according to your

requirements.

MPEG4 playback

This DVD Recorder can play MPEG4 formats within an

avi file.

DivX Certification

DivX, DivX Certified, and associated

logos are trademarks of DivXNetworks

Inc. and are used under license.

HDMI (High Definition Multimedia Interface)

HDMI reduces picture noise by allowing a pure digital

video/audio signal path from the DVD recorder to your

TV.

The DVD Recorder allows you to record and play high

quality digital video on DVD-RAM/DVD-RW/DVD-R

discs. You can record and edit digital images on DVD-

RAM/DVD-RW/DVD-R discs as if they were VCR tapes.

High quality digital audio and video recording

and playback

Record up to 16-hours of video with a double sided 9.4

GB DVD-RAM disc, up to 8-hours of images with a 4.7

GB DVD-RAM/DVD-RW/DVD-R disc,

depending on the recording mode.

Selectable Recording Mode

You can set your recorder to one of four different

recording speeds, each varying in recording quality and

length. EP (6Hr or 8Hr) mode yields the most recording

time, LP & SP modes provide less recording time with

higher quality recording, XP mode gives you the highest

quality recording.

Automated Quality Adjustment for Timer

Recording

If FR mode is selected, the video quality is adjusted

automatically so that all video for the scheduled time

can be recorded onto the free disc space.

(See page 48.)

Creating a DVD video title using

DVD-RW/DVD-R disc

With the DVD Recorder, you can create your own DVD

Video titles on 4.7 GB DVD-RW/DVD-R discs.

Copying data from a digital camcorder using a

DV input jack

Record DV Device video onto DVD-RAM or DVD-RW,

DVD-R discs using the DV input jack (IEEE 1394-

4pin/4pin). (See page 45.)

Getting Started

00842C-R125-XEB_02~17 2005.6.29 10:15 PM Page 8

English -

9

1) Be sure to be familiar with Safety Instructions before

using this product. (See pages 2~5)

2) If a problem occurs, check for Troubleshooting.

(See pages 88~91)

About the use of this user’s manual

manual may be reproduced or copied without the prior

written permission of Samsung Electronics Co.

Copyright

How to use the DVD

Recorder

Step 1

Select the disc type

This unit can record on the following types of discs.

If you want to repeatedly record on the same disc or

you want to edit the disc after recording, select a

rewritable DVD-RW or DVD-RAM type disc.

If you want to save recording without any change,

choose a non-rewritable DVD-R.

Before reading the user’s

manual

Make sure to check the following terms before

reading the user’s manual.

Step 2

Format the disc to start recording

Unlike a VCR, the recorder automatically starts

formatting when an unused disc is inserted. This is

required for the preparation of recording on a disc.

Using a DVD-RAM

This type of disc can be formatted in DVD-Video

Recording format (VR mode). You can edit recorded

image and create a playlist and edit images in a

specific sequence according to your requirements.

Using a DVD-RW

This type of disc can be formatted in either DVD-Video

format (Video mode) or DVD-Video Recording format

(VR mode). For an unused disc, a message that asks

whether to format in VR Mode or not is displayed.

You can play a Video mode disc on various DVD

components. A VR mode disc allows more varied

editing.

Using a DVD-R

This type of disc can be formatted in DVD Video

format. After formatting is complete, you can record on

the disc. You can play this type of discs on various

DVD components only when they have been finalised.

■

You can only use either the VR or

Video mode on a DVD-RW, but not

both at the same time.

■

You can change the DVD-RW

format to another format by

reinitializing. It should be noted that

the disc's data will be lost when

changing formats.

NOTE

Getting Started

Icons that will be used in manual

Icon Term Definition
