User Guide | Guide de l’utilisateur | Guía del Usuario
7" Personal DVD Player
Lecteur de DVD individuel de 7 po
Reproductor de DVD personal de 7"
NS-7PDVDD
07-202_NS-7PDVDD.fm Page 1 Wednesday, June 27, 2007 9:35 AM
07-202_NS-7PDVDD.fm Page 2 Wednesday, June 27, 2007 9:35 AM
www.insignia-products.com
3
Insignia NS-7PDVDD
7" Personal DVD Player
Contents
Welcome . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Safety information. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Setting up your player . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Using your player . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Maintaining . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Legal notices. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
90-day limited warranty. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Français . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
Español. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65
Welcome
Congratulations on your purchase of a high-quality Insignia product.
Your NS-7PDVDD represents the state of the art in personal DVD
player design and is designed for reliable and trouble-free
performance.
Safety information
Placement
To prevent fire or electric shock, do not expose your player to rain or
moisture. Do not place your player on an unstable cart, stand, tripod,
bracket, or table to prevent it from falling. Keep your player away from
strong magnets, heat sources, direct sunlight, and excessive dust. If
your player is brought directly from a cold to a warm location,
moisture may condense inside your player. When you move your
player from a cold to a warm location, wait for about one hour before
operating your player, or remove the disc and leave your player
turned on until the moisture evaporates.
Installation
Make sure that your player is installed in accordance with the
instructions and illustrations provided in this guide.
07-202_NS-7PDVDD.fm Page 3 Wednesday, June 27, 2007 9:35 AM
4
Insignia NS-7PDVDD 7" Personal DVD Player
www.insignia-products.com
Cautions
Do not push objects of any kind into your player through
openings in your player.
Do not spill or spray liquid of any kind on or in your player
because liquid can cause a fire or electric shock.
Do not place anything heavy on your player.
To ensure correct ventilation and operation, never cover or
block openings on your player with a cloth or other material.
Keep your player away from an open flame, such as fire or a
candle.
Replace the battery only with the same or equivalent type.
Replacing the battery incorrectly can be hazardous. In order to
protect the environment, dispose the battery as hazardous
waste.
Do not use your player in temperatures higher than 95
°F
(35°C).
Disassembly
Do not attempt to disassemble your player. There is a risk of electric
shock and exposure to laser radiation. Contact qualified service
personnel if your player needs repair.
Cleaning
When cleaning, make sure that your player is unplugged from the
power source. Do not use liquid or aerosol cleaners. Use a cloth,
lightly dampened with water, for cleaning the exterior of your player.
Discs
Do not use irregularly shaped discs, such as heart-shaped or
star-shaped discs, because they may cause your player to
malfunction.
Do not stick paper, tape, or glue on a disc.
Do not expose a disc to direct sunlight or heat sources.
Do not touch the surface of a disc. Handle a disc by its edge.
Clean a disc by wiping the disc from the center out with a
cleaning cloth.
Remove a disc from your player and store it in its case after
playing.
Some playback operations of discs may be intentionally limited
by software producers. Because your player plays discs
according to the disc contents the software producers
designed, some playback features may not be available. Also
refer to the instructions supplied with the discs.
07-202_NS-7PDVDD.fm Page 4 Wednesday, June 27, 2007 9:35 AM
5
Insignia NS-7PDVDD 7" Personal DVD Player
www.insignia-products.com
Features
Front
# Component Description
1 Remote control sensor Receives signals from the remote
control. Do not block.
2 Power/battery charge
indicator
Lights green when your player is
on.
Lights red when the battery is
charging.
3 Open button Press to open the disc tray.
1
2
3
07-202_NS-7PDVDD.fm Page 5 Wednesday, June 27, 2007 9:35 AM
6
Insignia NS-7PDVDD 7" Personal DVD Player
www.insignia-products.com
Right
# Component Description
1 AC to DC jack Plug the AC or cigarette lighter
adapter into this jack.
2 AV OUT jack Plug the A/V cable into this jack
and into the A/V IN jack on another
TV or monitor.
3 Headphone jack Plug headphones into this jack.
When headphones are plugged in,
sound does not come out of your
player’s speakers.
4 Brightness control Rotate to increase or decrease the
brightness.
5 Volume control Rotate to increase or decrease the
volume.
6 ON/OFF switch Slide to the left to turn on your
player, or slide to the right to turn
off your player.
1
2 3
4
5
6
07-202_NS-7PDVDD.fm Page 6 Wednesday, June 27, 2007 9:35 AM
7
Insignia NS-7PDVDD 7" Personal DVD Player
www.insignia-products.com
Inside
# Component Description
1 LCD button Press to turn the LCD off.
2 Press to stop disc playback.
3 Press to pause disc playback.
4 Press to start disc playback.
5 Press to go to the next chapter,
track, or scene during disc
playback.
6 Press to go to the previous
chapter, track, or scene during
disc playback.
7 MENU Press to open the main DVD
menu.
8 WIDE Press to switch the aspect ratio
between 4:3 and 16:9.
9 OK Press to highlight options and
confirm selections.
1
2
3
4
6
5
8
7
9
07-202_NS-7PDVDD.fm Page 7 Wednesday, June 27, 2007 9:35 AM
8
Insignia NS-7PDVDD 7" Personal DVD Player
www.insignia-products.com
Remote control
# Button Description
1 SETUP Press to open or close the Setup
menu.
2 DISPLAY Press to display information about
the disc, such as title, chapter
number, track number, and time.
3 REW Press to fast reverse on the disc.
Each time you press this button
the fast-reverse speed increase
from 2, to 4, to 8, to 16, to 32 times
the normal speed.
123
456
7890
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
07-202_NS-7PDVDD.fm Page 8 Wednesday, June 27, 2007 9:35 AM
9
Insignia NS-7PDVDD 7" Personal DVD Player
www.insignia-products.com
4 FF Press to fast-forward on the disc.
Each time you press this button,
the fast-forward speed increases
from 2, to 4, to 8, to 16, to 32 times
the normal speed.
5 SKIP– Press to go to the previous title,
chapter, or track.
6 SKIP+ Press to go to the next title,
chapter, or track.
7 PLAY/PAUSE Press to start or pause playback.
8 STOP Press once to stop playback. Your
player remembers where you
stopped. If you press
PLAY/PAUSE, your player starts
playing at the point where you
stopped.
Press twice to stop playback. If
you press PLAY/PAUSE, your
player starts playing at the
beginning of the disc.
9 Press to navigate in menus.
10 ENTER Press to confirm selections.
11 Numbers Press to select menu items or to
enter the password.
12 SUBTITLE Press to turn subtitles on and off,
or press to select the subtitle
language. This option works only if
the DVD has subtitles.
13 AUDIO Press to select the DVD audio
language. This option works only if
the DVD has multiple audio
languages.
14 REPEAT Press to repeat the current title,
chapter, or track.
15 AB Press to create a playback loop.
16 MENU Press once to open the main DVD
menu. This option works only if the
DVD has a main menu.
Press twice to open the DVD title
menu. This option works only if the
DVD has a title menu.
17 TITLE Press to open the DVD title menu.
This option works only if the DVD
has a title menu.
# Button Description
07-202_NS-7PDVDD.fm Page 9 Wednesday, June 27, 2007 9:35 AM
10
Insignia NS-7PDVDD 7" Personal DVD Player
www.insignia-products.com
Setting up your player
Package contents
Your box should contain:
DVD player with 7" LCD monitor
AC to DC adapter
Remote control with battery
A/V cable
Cigarette lighter adapter
This user guide
Installing remote control batteries
To install remote control batteries:
1 Remove the battery compartment cover.
2 Insert the battery into the battery compartment. Make sure that the
+ and – symbols on the battery match the + and – symbols in the
battery compartment.
3 Replace the battery compartment cover.
18 RETURN Press once to return to the
previous menu. Press twice to
resume playback.
19 ZOOM Press to enlarge the display
image. You can enlarge the image
for 2 to 3 to 4 times the normal
size.
20 SLOW Press to play forward or backward
at 1/2, 1/4, 1/8, or 1/16 the normal
speed.
21 ANGLE Press to select the viewing angle
on a DVD. This option works only
if the DVD has multiple viewing
angles.
# Button Description
07-202_NS-7PDVDD.fm Page 10 Wednesday, June 27, 2007 9:35 AM
11
Insignia NS-7PDVDD 7" Personal DVD Player
www.insignia-products.com
Connecting to AC power
To connect to AC power:
1 Plug one end of the AC to DC power adapter into the DC jack on
the side of your player.
2 Plug the other end of the adapter into an AC outlet.
Connecting to a car cigarette lighter
To connect to a car cigarette lighter:
1 Plug one end of the cigarette lighter adapter into the DC jack on
the side of your player.
2 Plug the other end of the adapter into a car cigarette lighter
socket.
Charging your player’s battery
To charge your player’s battery:
1 Turn off your player.
2 Plug one end of the AC to DC power adapter into the DC jack on
the side of your player.
3 Plug the other end of the adapter into an AC outlet. The
power/battery charge indicator lights red. When the battery is fully
charged, the indicator turns off. You can unplug the adapter if you
want.
Note
Recharging the battery takes about five hours. A
fully-charged battery can power your player for at least two
hours.
07-202_NS-7PDVDD.fm Page 11 Wednesday, June 27, 2007 9:35 AM
12
Insignia NS-7PDVDD 7" Personal DVD Player
www.insignia-products.com
Connecting a TV or monitor
To connect a TV or monitor:
1 Plug the end of the supplied A/V cable that has one black
connector into the AV jack on your player.
2 Plug the connectors on an optional RCA cable into the connectors
on the other end of the supplied A/V cable. Make sure that the
colors on the connectors match.
3 Plug the other end of the optional RCA cable into the A/V jacks on
the TV or monitor. The white connector goes into the left audio
jack. The red connector goes into the right audio jack. The yellow
connector goes into the video jack.
Using your player
Playing a DVD or audio CD
To play a disc:
1 Make sure that your player is connected to power or that the
battery is charged.
2 Slide the ON/OFF switch on the right side of your player to the ON
position.
Note
Most DVDs and your player have region codes that help
control illegal distribution of DVDs. The region code for your
player is 1. You can only play DVDs with a region code of 1
or ALL. The region code for a DVD is printed on the DVD or
the DVD packaging.
White=left audio
Red=right audio
Yellow=video
07-202_NS-7PDVDD.fm Page 12 Wednesday, June 27, 2007 9:35 AM
13
Insignia NS-7PDVDD 7" Personal DVD Player
www.insignia-products.com
3 Press OPEN on the front of your player. The disc tray opens.
4 Place a disc, label side up, in the disc tray, then press CLOSE to
close the tray. The disc starts playing automatically.
Controlling DVD or audio CD playback
To control disc playback:
Press STOP once to stop playback. Your player remembers
where you stopped. If you press PLAY/PAUSE, your player
starts playing at the point where you stopped.
Press STOP twice to stop playback. If you press
PLAY/PAUSE, your player starts playing at the beginning of
the disc.
Press PLAY/PAUSE to pause playback. Press this button
again to resume playback.
Press FF to fast-forward on the disc. Each time you press this
button, the fast-forward speed changes from 2 to 4 to 8 to 16 to
32 times the normal speed.
Press REW to fast-reverse on the disc. Each time you press
this button, the fast-reverse speed changes from 2 to 4 to 8 to
16 to 32 times the normal speed.
Press SKIP+ to go to the next title, chapter, or track.
Press SKIP– to go to the previous title, chapter, or track.
07-202_NS-7PDVDD.fm Page 13 Wednesday, June 27, 2007 9:35 AM
14
Insignia NS-7PDVDD 7" Personal DVD Player
www.insignia-products.com
Playing an MP3 disc
MP3 is a format for storing digital audio. Your player can play CD-Rs
and CD-RWs that contain MP3 files encoded in the MP3 format.
When you insert an MP3 disc, a menu opens so you can select the
songs you want to play.
To play an MP3 disc:
1 Insert an MP3 disc into the disc tray, then close the tray. A menu
opens and a song begins to play automatically.
2 To go to the next song, press SKIP+, or to go to the previous
song, press SKIP– twice.
Playing a DivX disc
DivX is a compressed video format. Your player can play DVDs,
CD-Rs, and CD-RWs that contain videos encoded in the DivX format.
You play DivX discs in the same way that you play MP3 discs. For
more information, see “Playing an MP3 disc” on page 14.
Adjusting the volume
To adjust the volume:
Rotate the volume control on the right side of your player.
BBBBBBBBBB
CCCCCCC CCCC
DDDDDDDD DDD
EEEEEEEEEE
FFFFFFFFF
07-202_NS-7PDVDD.fm Page 14 Wednesday, June 27, 2007 9:35 AM
15
Insignia NS-7PDVDD 7" Personal DVD Player
www.insignia-products.com
Adjusting the video
To adjust the video:
1 Press SETUP. The
General Setup Page
opens.
2 Press or to select Video Quality Setup, then press ENTER.
The icon is highlighted.
3 Press or to select the option you want to adjust. You can
select:
Brightness–Increases the brightness to add more light to dark
areas of the picture or decreases the brightness to add more
dark to light areas of the picture.
Contrast–Increases the picture level to adjust the white areas
of the picture or decreases the picture level to adjust the black
areas of the picture.
Hue–Increases the color level to add more green to skin tones
or decreases the color level to add more purple to skin tones.
Saturation–Adjusts the color saturation.
4 Press or to adjust the option.
Viewing DVD information
To view DVD information:
1 During playback, press DISPLAY. The following display appears.
1 Current title number.
2 Total number of titles.
07-202_NS-7PDVDD.fm Page 15 Wednesday, June 27, 2007 9:35 AM
16
Insignia NS-7PDVDD 7" Personal DVD Player
www.insignia-products.com
2 Press DISPLAY one or more times to view specific DVD
information. You can view:
Title Elapsed–Shows the elapsed playing time for the title.
Title Remain–Shows the remaining playing time for the title.
Chapter Elapsed–Shows the elapsed playing time for the
chapter.
Chapter RemainShows the remaining playing time for the
chapter.
Display Off–Turns off the information display.
Viewing audio CD information
To view audio CD information:
1 During playback, press DISPLAY. The following display appears.
2 Press DISPLAY one or more times to view specific audio CD
information. You can view:
Single Elapsed–Shows the currently playing track and the
elapsed playing time for the track.
Single Remain–Shows the currently playing track and the
remaining playing time for the track.
3 Current chapter number.
4 Total number of chapters.
5 Elapsed playing time for
the current title.
Note
The information display automatically turns off if you do not
press DISPLAY within three seconds.
Single Elapsed
Track 1/24 00:00
07-202_NS-7PDVDD.fm Page 16 Wednesday, June 27, 2007 9:35 AM
17
Insignia NS-7PDVDD 7" Personal DVD Player
www.insignia-products.com
Total Elapsed–Shows the currently playing track and the
elapsed playing time for the CD.
Total Remain–Shows the currently playing track and the
remaining playing time for the CD.
Display Off–Turns off the information display.
Opening the DVD main menu
To open the DVD menu:
During playback, press MENU. If the DVD has a main menu,
the menu opens.
Selecting a viewing angle
Some DVDs are recorded with multiple viewing angles for some
scenes. When a scene has multiple viewing angles, the angle icon
appears on the screen.
To select a viewing angle:
1 During playback, press ANGLE. The angle display appears
showing the current angle and the total number of angles. In the
following example, the current angle is 1 and the total number of
angles is 3.
Note
Contents of DVD main menus vary from DVD to DVD.
Some DVDs only let you start playback from the main menu.
1 Current angle number.
2 Total number of angles.
1/3
1
2
07-202_NS-7PDVDD.fm Page 17 Wednesday, June 27, 2007 9:35 AM
18
Insignia NS-7PDVDD 7" Personal DVD Player
www.insignia-products.com
2 Press ANGLE one or more times to select a different viewing
angle or to turn off the display and return to normal viewing.
Selecting an audio language
Some DVDs are recorded with multiple audio languages.
To select an audio language:
1 During playback, press AUDIO. The audio display appears
showing the current audio language and the total number of audio
languages.
2 Press AUDIO one or more times to select the audio language you
want.
Enlarging the display image
To enlarge the display image:
1 Press ZOOM one or more times to enlarge the display image from
2 to 3 to 4 times the normal image size. The zoom display
appears.
Note
The audio language display turns off if you do not press
AUDIO within three seconds.
Some DVDs only let you select an audio language from the
DVD main menu.
1 Current amount of
enlargement.
1
2X
07-202_NS-7PDVDD.fm Page 18 Wednesday, June 27, 2007 9:35 AM
19
Insignia NS-7PDVDD 7" Personal DVD Player
www.insignia-products.com
2 Press ZOOM a fourth time to return to normal viewing.
3 Press the arrow buttons to navigate through the enlarged image.
Creating a playback loop
You can create a playback loop by selecting the beginning and end of
the section of the disc that you want to play repeatedly.
To create a playback loop:
1 During playback, find the starting point for the loop, then press
AB.
2 Play the disc until you reach the stopping point for the loop, then
press AB.
Your player repeatedly plays the loop you created.
A
AB
07-202_NS-7PDVDD.fm Page 19 Wednesday, June 27, 2007 9:35 AM
20
Insignia NS-7PDVDD 7" Personal DVD Player
www.insignia-products.com
3 To cancel the loop and return to normal viewing, press AB again.
Repeating a chapter, title, or DVD
To repeat a chapter, title, or DVD:
During playback, press REPEAT. The following display
appears, and your player repeats the currently playing chapter.
Press REPEAT twice to repeat the currently playing title.
Press REPEAT three times to repeat all the chapters and titles.
Press REPEAT four times to turn off the repeat function.
Repeat Off
Chapter
07-202_NS-7PDVDD.fm Page 20 Wednesday, June 27, 2007 9:35 AM
  • Page 1 1
  • Page 2 2
  • Page 3 3
  • Page 4 4
  • Page 5 5
  • Page 6 6
  • Page 7 7
  • Page 8 8
  • Page 9 9
  • Page 10 10
  • Page 11 11
  • Page 12 12
  • Page 13 13
  • Page 14 14
  • Page 15 15
  • Page 16 16
  • Page 17 17
  • Page 18 18
  • Page 19 19
  • Page 20 20
  • Page 21 21
  • Page 22 22
  • Page 23 23
  • Page 24 24
  • Page 25 25
  • Page 26 26
  • Page 27 27
  • Page 28 28
  • Page 29 29
  • Page 30 30
  • Page 31 31
  • Page 32 32
  • Page 33 33
  • Page 34 34
  • Page 35 35
  • Page 36 36
  • Page 37 37
  • Page 38 38
  • Page 39 39
  • Page 40 40
  • Page 41 41
  • Page 42 42
  • Page 43 43
  • Page 44 44
  • Page 45 45
  • Page 46 46
  • Page 47 47
  • Page 48 48
  • Page 49 49
  • Page 50 50
  • Page 51 51
  • Page 52 52
  • Page 53 53
  • Page 54 54
  • Page 55 55
  • Page 56 56
  • Page 57 57
  • Page 58 58
  • Page 59 59
  • Page 60 60
  • Page 61 61
  • Page 62 62
  • Page 63 63
  • Page 64 64
  • Page 65 65
  • Page 66 66
  • Page 67 67
  • Page 68 68
  • Page 69 69
  • Page 70 70
  • Page 71 71
  • Page 72 72
  • Page 73 73
  • Page 74 74
  • Page 75 75
  • Page 76 76
  • Page 77 77
  • Page 78 78
  • Page 79 79
  • Page 80 80
  • Page 81 81
  • Page 82 82
  • Page 83 83
  • Page 84 84
  • Page 85 85
  • Page 86 86
  • Page 87 87
  • Page 88 88
  • Page 89 89
  • Page 90 90
  • Page 91 91
  • Page 92 92
  • Page 93 93
  • Page 94 94
  • Page 95 95
  • Page 96 96
  • Page 97 97
  • Page 98 98
  • Page 99 99
  • Page 100 100

Insignia NS-7PDVDD Manuel utilisateur

Catégorie
Lecteurs DVD / Blu-Ray portables
Taper
Manuel utilisateur

dans d''autres langues
