Operating Instructions
Mode d'emploi
Handleiding
Instrucciones de Funcionamiento
VOL
VOL
CH
CH
MENU
MENU
//
ANGLE
ANGLE
REC
REC
A-B
A-B
Downloaded from www.vandenborre.be
EN
2
You get the smartcard from your cable supplier (CAMs are customary). Insert the
smartcard into the CAM, and then insert the CAM into the CI slot of your TV set.
modules
EN
DVD Player
Downloaded from www.vandenborre.be
it is damaged.
broken glass. You could be hurt or the unit could become damaged.
to allow for air circulation.
100-240V~50/60Hz
EN
3
EN
Downloaded from www.vandenborre.be
Carefully hold the base plate in position and secure it with screws.
To detach the stand, perform these steps in reverse order.
For wall mounting , the stand must be dismantled. To do this, remove screws ( above drawing ) from the
back . Fit a VESA (100 x 100) wall mounting kit. The screw thread length must not exceed 5mm.
Remove the stand as one piece by reversing the fixing procedure described above.
You can refit the screws to the stand for safe keeping, but tighten them only slightly.
VESA screw size 4xM4x5mm
Protect the screen and lay the TV flat on its face, on a stable table, with the stand foot clear of the
table edge.
To ensure a safe installation, please observe the following when hanging the television on a wall:
Warning: This operation requires two people.
Check that the wall can support the weight of the television set and a VESA-standard wall mount
assembly (not supplied).
Be sure to use only screws suitable for the material of the wall.
In case of any doubt please contact a qualified installer.
Beware of electrical cables, gas and water pipes in the wall.
Follow the instructions provided with the wall mount.
The set must be installed on a vertical wall.
Make sure that cables are placed so that there is no danger of tripping over them or damaging
them.
fit in
1. Place the TV with the display side down
on a flat surface. Use a cloth to protect the
display.Position the stand base pillar onto
the bottom of the TV.
2. Attach the stand base plate and washer to
the stand pole by firmly tightening the supplied
screws.
EN
4
EN
1xM4x20mm
Dismantling the stand
3xM4x10mm
Downloaded from www.vandenborre.be
EN
5
EN
Downloaded from www.vandenborre.be
Safety Information
Dangerous voltage constituting a risk
of electric shock is present inside this
equipment.
This equipment is double insulated
and an earth connection is not
required.
This mark is applied to show the
equipment conforms to European
safety and electro-magnetic
compatibility standards.
Safe use and care of your television
We have designed and made this television to meet
European Safety Standards, but as with any
electronic equipment you must take care, to stay
safe and get the best results. Here is some good
advice to help you do this.
Read these instructions carefully before you try to
use the television.
Protect the mains lead. You must ensure the mains
lead cannot be walked on, crushed, chafed, cut or
trapped.
Switch off the mains power or pull out the mains plug
when you leave the television unattended, unless
the function of the television requires a continuous
power supply.
Do not continue to use your television if you have
spilt liquids in it, if it is damaged in any way or if it
does not work normally. Immediately unplug the
television and get expert advice.
Avoid harsh conditions such as wet or damp places,
high humidity, strong vibration, extremely high or
low temperatures, strong sunlight and places that
are very dusty.
Never fit makeshift stands or legs to the television.
Never push objects into holes and ventilation slots.
To prevent electric shock do not remove any cover.
Do not touch the LED display as it gets warm when
in use, this is normal and is not a fault.
If anything goes wrong do not try to fix it yourself,
get a qualified service agent to look at it.
Pull out the mains plug and disconnect the aerial
lead during thunder storms.
Cleaning
Disconnect the mains supply and use only a lightly
dampened soft cloth. Do not use chemical solvents
or strong detergents as these may damage the
cabinet or screen.
Mains Supply
This television is designed to operate from a 100-
240 Volts 50/60Hz AC mains supply. Other power
sources
may damage it. Check that the rating plate (on the
back cover of the television) states 100-240V AC
before you plug it in for the first time.
The manufacturer accepts NO liability for damage
or injury caused by using the product with the
wrong mains voltage.
Never allow water droplets to remain on the
screen as moisture can cause permanent
discolouration.
Greasy marks must only be removed with a
commercial cleaner specifically recommended for
LED screens.
EN
6
EN
Downloaded from www.vandenborre.be
EN
7
EN
Downloaded from www.vandenborre.be
Features...............................................................................................2
Important Safety Information...................................................................3-7
Contents...............................................................................................8
Installation............................................................................................9-12
Remote Control.....................................................................................13-14
Operation.............................................................................................15-24
DVD Operation.....................................................................................25-29
Troubleshooting table............................................................................30-34
Specification.........................................................................................35
License Information...............................................................................36
EN
8
EN
Downloaded from www.vandenborre.be
1: Remote Control Sensor.
2: Power Indicator LED:
RED STANDBY.
3: Side buttons
30 30
1
3
2
KEYBOARD
Front panel
REAR AV Connections
All the terminals are (from left to right): YPbPr INPUT, VIDEO, AUDIO INPUT,COAXIAL OUTPUT, SCART.
Note: VIDEO and YPbPr share one audio channel.
REAR AV Connections(SIDE)
All the terminals are(from left to right):
USB, HDMI2(ARC), HDMI1, HEADPHONE, CI, PC AUDIO, VGA, RF.
Note: 1.When HDMI port gets DVI signal ,the audio signal is received from the PC Audio channel.
2.Insert the plug of the earphone into the headphone jack on the unit.
The speakers are then muted.
EN
9
Installation
EN
VOL CH
FREEZE
EPG
1. OPEN/CLOSE: Open or close DVD slot.
2. PLAY/PAUSE: Play or pause playback.
3. SOURCE: Displays the input source, press “CH+”or
“CH-”to select required source,then press "VOL-" or
"VOL+" to change source.
4. MENU: Display main MENU.
5. CH+/CH-: In TV mode, press "CH+" or "CH-" to
change the channel up and down. In MENU mode,
press "CH+" or "CH-" to select items.
6. VOL+/VOL-: Adjust sound level. In MENU mode,
press "VOL+ " or "VOL- " to adjust the item that you
selected.
7. STANDBY: Press this button to turn the unit ON
from STANDBY mode. Press it again to turn the set
back to STANDBY.
HDMI ARC (Audio Return Channel)
The ARC function allows you to send audio signal from your ARC-compliant TV to ARC-compliant
audio devices (e.g. home theatre) without the need to connect any audio cable (e.g. coaxial, optical
digital audio cable, or analog audio cable).
To enjoy the ARC function:
1. Make sure your ARC- compliant audio devices are connected by an HDMI 1.4 cable to the HDMI 2 (ARC)
port of your ARC- compliant TV. And open the ARC function of ARC-compliant audio devices.
2. Adjust TV setting : press MENU button, choose SETUP, then set HDMI CEC Control on.
3. Then, just use your TV remote control to adjust the volume output (VOL + / - and MUTE) of the
connected audio device.
COAXIAL OUTPUT
SOURCE
MENU
CH+
CH-
VOL+
VOL-
STANDBY
OPEN/CLOSE
PLAY/PAUSE
Note: If the ARC-compliant audio devices do not support sound that TV outputs, such as Dolby
Digital , or Dolby Digital Plus, then ARC function will not work and there may be no sound from
ARC-compliant audio devices. In this case, please set coaxial to PCM.
Downloaded from www.vandenborre.be
STEPS:
PC
Be sure both the TV and computer are set to
Power off.
1.Connect VGA and audio cable.
2.Connect the power cord.
3.Power on the TV, switch to PC mode.
4.Power on the PC.
This sequence is very important.
EN
10
Installation
EN
Downloaded from www.vandenborre.be
PRESET MODE
PC
EN
11
Installation
EN
ANTENNA
Note:
Aerial connections: IEC(female).
Input impedance: 75 unbalanced.
NOTE:
PC V.Freq.(Hz) not more than 60Hz
2
1
3
640*480
800*600
1024*768
60
60
60
31.47
37.88
48.36
RESOLUTION
V.Freq.(Hz) H.Freq.(kHz)
4
1280*960 60 60
1280*720 60 45
1366*768 60 47.7
5
6
Downloaded from www.vandenborre.be
EN
12
This TV provides one group of AV, one group of YPbPr and one SCART for convenient
connection to VCR, DVD or other video equipment. Please refer to the owners manual
of the equipment to be connected.
REAR AND SIDE CONNECTIONS
AV EQUIPMENT
It can be connected to the following appliances: VCR, multi disc player, DVD, camcorder,
video game or stereo system, etc.....
YPbPr can support these video formats: 480i,576i,480p,576p,720p,1080i,1080p.
Installation
EN
HD MI
W R
G
B
R
Yellow (video)
White(audio L)
Red(audio R or Pr)
Y
W
R
Blue(Pb)
Green(Y)
B
G
VIDEO EQUIPMENT with YPbPr
W
R
W
R
W R
TO AUDIO
OUTPUTS
VIDEO EQUIPMENT
TO VIDEO
OUTPUTS
Y
Y
RBG
COAXIAL OUTPUT
Downloaded from www.vandenborre.be
EN
13
REMOTE CONTROL
EN
EN
13
REMOTE CONTROL
1: :To set the TV to standby or power on.
1
VOL
CH
2
4
5
7
6
8
9
10
11
12
13
15
14
16
17
3
18
19
20
21
22
23
24
25
26
27
28
29
30
31
MENU
/
ANGLE
REC
A-B
2: :In DVD mode, used to eject the CD/DVD. Red button (see
footnote).
3:TITLE:In DVD mode, used to access the Title menu. Green
button (see footnote).
4: : In DVD mode or in USB mode, used as reverse key;
in teletext mode, used as subpage key.
5: : In DVD mode or in USB mode, used as forward key; in
teletext mode, used as reveal key.
6: : In DTV mode, used to start timeshift. In DVD/USB mode,
press this button to pause playback.
7: : In DVD mode, used to resume playback during timeshift. In
DVD/USB mode, press this button to begin or resume playback.
8:TEXT:To enter or exit teletext.
9:SUBTITLE:To turn subtitles on or off.
10: : To display the main on-screen menu.
11:NAVIGATION BUTTONS: To move within the menu.
12: OK: To confirm selection.
13: EPG: In DTV mode, used to display information about the
programme being viewed and what's on next.
14: FAV: In TV or DTV mode, used to access your favourite
channels list.
15: VOL +/-: To adjust sound level.
16: NUMERIC BUTTONS: For direct access to channels.
17: AUDIO: To select the available audio language of TV
programmes.
18: : To disable or enable the sound output.
19: A-B: In DVD mode, used to repeat a segment of the disc you
are watching between point A and point B in a loop. Blue button
(see footnote).
20: DVD SETUP: In DVD mode, used to access the DVD setup
menu. Yellow button (see footnote).
21: : In DVD mode or in USB mode, used as previous key;
in teletext mode, used as hold key.
22: : In DVD mode or in USB mode, used as next key; in
teletext mode used as list key. In TV/DTV mode, used as
channel list key except when in teletext mode.
23: : In teletext mode used as index. In DTV, used to access
the Recorded list menu.
Downloaded from www.vandenborre.be
REMOTE CONTROL
EN
REMOTE CONTROL
1
VOL
CH
2
4
5
7
6
8
9
10
11
12
13
15
14
16
17
3
18
19
20
21
22
23
24
25
26
27
28
29
30
31
MENU
/
ANGLE
REC
A-B
24: : In DTV mode, used to stop timeshift or recording. In DVD/
USB mode, used to stop Playback.
25: MENU/INFO: During DVD playback, press MENU to display
the disc menu of the current title. During VCD/SVCD playback,
press MENU to set playback control on or off. In DTV mode, used
as info.
26: DISPLAY: In DVD mode, used to display info.
27: : Press this button to display and select the available video
input sources.
28: EXIT: To return to the previous menu or exit menu.
29: CH+/CH-: To access the next or previous channels.
30: REC: in DTV Mode, press this button to start recording the
TV programme you are watching. In DVD mode, used to repeat
chapter or title.
31: RECALL/GOTO: In DTV Mode, RECALL jumps to the last
channel viewed. In DVD Mode, GOTO allows direct chapter/
title/track/time input.
Remote Control Battery Installation
The remote control requires two AAA batteries ( not supplied).
Below are steps to assist you with replacing the batteries.
1.Open the back cover of the battery compartment.
2.Install the batteries into the battery tray. There are +/- polarity
markings in the battery compartment. Please ensure the battery
polarity is correct.
3.Close the battery cover.
Footnote:
Red, green, yellow and blue buttons are multi-function;
please follow on-screen prompts and section
instructions.
EN
14
Downloaded from www.vandenborre.be
TELETEXT
Teletext is an information system broadcast by certain channels which can be like a
newspaper. It also offers access to subtitles for viewers with hearing problems or who are not
familiar with the transmission language (cable networks, satellite channels, etc.)
read
REMOTE CONTROL
EN
E
SELECTING A PAGE
INDEX
(BUTTON 19)
DIRECT ACCESS
TO THE ITEMS
SUB PAGE
(BUTTON 2)
HOLD
(BUTTON 18)
REVEAL
(BUTTON 3)
Press :
You will obtain :
LIST
(BUTTON 17)
Enter the number of the page required using the numeric buttons and up
and down arrow buttons. Example: page 120, enter 120. The number is
displayed top left, the counter turns and then the page is displayed.
Repeat this operation to view another page. If the counter continues to
search, this means that the page is not transmitted. Select another
number.
Coloured areas are displayed at the bottom of the screen. The 4 coloured
keys are used to access the items or corresponding pages. The coloured
areas flash when the item or the page is not yet available.
This returns to the contents page (usually page 100).
Certain pages contain sub-pages which are automatically displayed
successively. This key is used to stop or resume sub-page
acquisition. The number appears top left.
To freeze the page.
To display or hide the concealed information (games solutions).
The user can set four favourite pages to be directly linked to the four
colour keys. The favourite page numbers should be stored and restored
to/from nonvolatile memory for each channel by the system software.
This is used to enter or exit teletext mode. The summary appears with a
list of items that can be accessed. Each item has a corresponding 3 digit
page number.
T
EXT
(BUTTON 6)
EN
15
EN
Downloaded from www.vandenborre.be
OPERATION
EN
EN
16
Downloaded from www.vandenborre.be
OPERATION
EN
EN
17
Downloaded from www.vandenborre.be
OPERATION
EN
18
EN
Downloaded from www.vandenborre.be
OPERATION
EN
EN
19
Downloaded from www.vandenborre.be
OPERATION
EN
.
EN
20
Downloaded from www.vandenborre.be
  • Page 1 1
  • Page 2 2
  • Page 3 3
  • Page 4 4
  • Page 5 5
  • Page 6 6
  • Page 7 7
  • Page 8 8
  • Page 9 9
  • Page 10 10
  • Page 11 11
  • Page 12 12
  • Page 13 13
  • Page 14 14
  • Page 15 15
  • Page 16 16
  • Page 17 17
  • Page 18 18
  • Page 19 19
  • Page 20 20
  • Page 21 21
  • Page 22 22
  • Page 23 23
  • Page 24 24
  • Page 25 25
  • Page 26 26
  • Page 27 27
  • Page 28 28
  • Page 29 29
  • Page 30 30
  • Page 31 31
  • Page 32 32
  • Page 33 33
  • Page 34 34
  • Page 35 35
  • Page 36 36
  • Page 37 37
  • Page 38 38
  • Page 39 39
  • Page 40 40
  • Page 41 41
  • Page 42 42
  • Page 43 43
  • Page 44 44
  • Page 45 45
  • Page 46 46
  • Page 47 47
  • Page 48 48
  • Page 49 49
  • Page 50 50
  • Page 51 51
  • Page 52 52
  • Page 53 53
  • Page 54 54
  • Page 55 55
  • Page 56 56
  • Page 57 57
  • Page 58 58
  • Page 59 59
  • Page 60 60
  • Page 61 61
  • Page 62 62
  • Page 63 63
  • Page 64 64
  • Page 65 65
  • Page 66 66
  • Page 67 67
  • Page 68 68
  • Page 69 69
  • Page 70 70
  • Page 71 71
  • Page 72 72
  • Page 73 73
  • Page 74 74
  • Page 75 75
  • Page 76 76
  • Page 77 77
  • Page 78 78
  • Page 79 79
  • Page 80 80
  • Page 81 81
  • Page 82 82
  • Page 83 83
  • Page 84 84
  • Page 85 85
  • Page 86 86
  • Page 87 87
  • Page 88 88
  • Page 89 89
  • Page 90 90
  • Page 91 91
  • Page 92 92
  • Page 93 93
  • Page 94 94
  • Page 95 95
  • Page 96 96
  • Page 97 97
  • Page 98 98
  • Page 99 99
  • Page 100 100
  • Page 101 101
  • Page 102 102
  • Page 103 103
  • Page 104 104
  • Page 105 105
  • Page 106 106
  • Page 107 107
  • Page 108 108
  • Page 109 109
  • Page 110 110
  • Page 111 111
  • Page 112 112
  • Page 113 113
  • Page 114 114
  • Page 115 115
  • Page 116 116
  • Page 117 117
  • Page 118 118
  • Page 119 119
  • Page 120 120
  • Page 121 121
  • Page 122 122
  • Page 123 123
  • Page 124 124
  • Page 125 125
  • Page 126 126
  • Page 127 127
  • Page 128 128
  • Page 129 129
  • Page 130 130
  • Page 131 131
  • Page 132 132
  • Page 133 133
  • Page 134 134
  • Page 135 135
  • Page 136 136
  • Page 137 137
  • Page 138 138
  • Page 139 139
  • Page 140 140
  • Page 141 141
  • Page 142 142
  • Page 143 143
  • Page 144 144
  • Page 145 145
  • Page 146 146
  • Page 147 147
  • Page 148 148
  • Page 149 149
  • Page 150 150

JVC LT-24HD7WU Le manuel du propriétaire

Catégorie
Lecteurs DVD
Taper
Le manuel du propriétaire
