ACCU-CHECK Aviva Combo Manuel utilisateur

Taper
Manuel utilisateur
User’s Manual
Blood Glucose Meter
Manuel de l’utilisateur
Glycomètre
This file may not print or view at 100%.
Die lines and color breaks do not print.
“Holding Area” text, box and rules do not print.
Roche USA –52107
V4/1 – 07111223001 – Black
Roche USA –52107
V4/2 – 07111223001 – Cyan
Roche USA –52107
V4/3 – 07111223001 – Magenta
Roche USA –52107
V4/4 – 07111223001– Yellow
Aviva Connect
52107_07111223001_FCBC.indb 1 4/2/15 11:04 AM
52107_07111223001_FCBC.indb 2 4/2/15 11:04 AM
Contents
Introduction ............................................................................................................................3
Chapter 1: Your New System ..................................................................................................5
Chapter 2: Control Tests ........................................................................................................13
Chapter 3: Blood Glucose Tests .............................................................................................19
Chapter 4: Meter Settings ..................................................................................................... 29
Chapter 5: Review Your Data.................................................................................................41
Chapter 6: Wireless Communication and Meter Pairing .........................................................47
Chapter 7: Data Transfer and PC Reports .............................................................................. 61
Chapter 8: Meter Maintenance and Troubleshooting .............................................................77
Chapter 9: Technical Information ..........................................................................................87
Chapter 10: Guarantee ..........................................................................................................93
Index ....................................................................................................................................95
This file may not print or view at 100%.
Die lines and color breaks do not print.
“Holding Area” text, box and rules do
not print.
Roche USA –52107
V2/1 – 07111223001 – Black
Roche USA – 52107
V2/2 – 07111223001 – PMS 287
52107_07111223001_EN.indb 1 4/2/15 9:22 AM
52107_07111223001_EN.indb 2 4/2/15 9:22 AM
3
Introduction
The Accu‑Chek Aviva Connect System
Intended use
The Accu-Chek Aviva Connect meter is designed to be used with the Accu-Chek Aviva test strip to
quantitatively measure glucose in fresh capillary whole blood as an aid in monitoring the eectiveness of
glucose control.
Capillary whole blood for testing of blood glucose can be obtained from fingertip and approved alternate
sites (for example, forearm). Refer to the Alternate Site Testing (AST) section of this manual for approved
alternate sites and associated limitations. The Accu-Chek Aviva Connect meter with the Accu-Chek Aviva test
strips provide a complete test system that is meant for in vitro diagnostic use by a single person and should
not be shared. The system is not for use in diagnosis or screening of diabetes mellitus or for neonatal use.
For use only with the Accu-Chek Aviva test strips and control solutions
Suitable for self-testing
The system includes:
Accu-Chek Aviva Connect meter with batteries, Accu-Chek Aviva test strips*, Accu-Chek Aviva control
solutions*, and Accu-Chek Connect diabetes management app.**
*Some items may not be included in the kit. They are a separate purchase.
** Download and install the app from the app store.
wWARNING
Choking hazard. Small parts. Keep away from children under the age of 3years.
Any object coming into contact with human blood is a potential source of infection
(see: Clinical and Laboratory Standards Institute: Protection of Laboratory Workers from
Occupationally Acquired Infections; Approved Guideline – Third Edition; CLSI document
M29‑A3, 2005).
wWARNING
The lancing device is for single patient use only and should not be shared.
Introduction
52107_07111223001_EN.indb 3 4/2/15 9:22 AM
4
Introduction
Why Regular Blood Glucose Testing Is Important
Testing your blood glucose regularly can make a big dierence in how you manage your diabetes every day.
We have made it as simple as possible.
Important Information About Your New Meter
The meter prompts you to choose a language the first time you turn it on.
Check the time and date on the meter before you begin testing. Adjust the time and date if necessary.
Sample data displays are shown throughout the manual. Your data will dier.
If you follow the steps in this manual but still have symptoms that do not seem to match your test results,
or if you have questions, talk to your healthcare professional.
52107_07111223001_EN.indb 4 4/2/15 9:22 AM
5
Your New System
1
1. Back Button
Returns to a previous display or field.
2. Up Arrow and Down Arrow Button
Press to move between menu options
or to increase or decrease numbers.
3. Display
Shows results, messages, and test
results stored in memory.
4. Power/Set/OK Button
Turns meter on or o and sets
options.
5. Test Strip Slot
Insert test strip here.
5
6
7
6. Battery Drawer
Pull out to replace
batteries.
2
The Accu‑Chek Aviva Connect Meter
Front View
1
3
4
Chapter 1: Your New System
7. Micro USB Port
Transfers data
from the meter to a
computer (PC).
Back View Side View
52107_07111223001_EN.indb 5 4/2/15 9:22 AM
6
Your New System
1
8
9
10
12
8. Test Strip Container*
(for example)
9. Insert this end into meter.
10. Yellow Window
Touch blood drop or control solution here.
11. Control Solution Bottle*
12. Batteries
13. USB Cable*
Connects the meter to a PC.
13
11
(for example)
Test Strip
*Some items may not be included in the kit. They are a separate purchase.
52107_07111223001_EN.indb 6 4/2/15 9:22 AM
7
Your New System
1
Button Functions
Here are the functions of the back, arrow, and Power/Set/OK buttons on the meter. These functions are used
throughout this manual. See the chapter Meter Settings for specific instructions on setting up the meter.
Button Function
Back Button
Return to the previous display.
Return to the previous field.
Up Arrow and
Down Arrow
Button
Navigate up and down in a menu.
Increase or decrease a number.
Power/Set/OK
Button
Press briefly to turn the meter on.
Press and hold to turn the meter o.
Press to select an option.
Press to move to the next field or display.
Press to save an option.
With the meter o, press and hold to check the meter display.
52107_07111223001_EN.indb 7 4/2/15 9:22 AM
8
Your New System
1
Meter Menus
1 Title of display or menu
2 Menu options
3 Scroll down
4 Scroll up
Display Description
There are more menu options listed beneath the last option. Press on the meter to
view the options.
There are more menu options listed above the first option. Press on the meter to view
the options.
There are more menu options listed above and below the options. Press or on the
meter to view the options.
1
2
3
4
52107_07111223001_EN.indb 8 4/2/15 9:22 AM
9
Your New System
1
Display Description
Highlighted option (Test)
Press
to enter the Test menu.
Highlighted field (Hour)
Press
or to increase or decrease the
hour. Press to set the hour and move to
the minutes field.
52107_07111223001_EN.indb 9 4/2/15 9:22 AM
10
Your New System
1
Icons
Here is a list of the icons on the display.
Icon Description
Above target range
After meal
Bedtime
Before meal
Below target range
Blood glucose test
Checkmark
Control bottle
Control test not OK
Control test OK
Error
52107_07111223001_EN.indb 10 4/2/15 9:22 AM
11
Your New System
1
Icon Description
Fasting
Flight mode
Help
Low battery
My data
No comment
Other
Overall
Selected setting
Settings
Temperature warning
Warning
Within target range
52107_07111223001_EN.indb 11 4/2/15 9:22 AM
12
Your New System
1
Set the Language
The meter prompts you to choose a language the first time you turn it on.
Turn the meter on by briefly
pressing . Language appears.
1
Press or to highlight the language. Press to set the
language and return to Main Menu.
2
NOTE
If you select the wrong language and cannot correct it, contact Accu-Chek Customer Care at
1-800-363-7949.
52107_07111223001_EN.indb 12 4/2/15 9:22 AM
13
Control Tests
2
When to Perform a Control Test
Performing a control test lets you know the meter and test strips are working properly. You should perform a
control test when:
you open a new test strip box.
you left the test strip container open.
you think the test strips are damaged.
you want to check the meter and test strips.
the test strips were stored in extreme temperatures, humidity, or both.
you dropped the meter.
your test result does not match how you feel.
you want to check if you are performing the test correctly.
About the Control Solutions
Use only Accu‑Chek Aviva control solutions.
Close the control solution bottle tightly after use.
Write the date you open the control solution bottle on the bottle label. The control solution must be
discarded 3months from the date the control solution bottle was opened (discard date) or on the use by
date on the bottle label, whichever comes first.
Do not use control solution that is past the use by or discard date.
Refer to the control solution package insert for control solution storage conditions.
The meter automatically recognizes the dierence between the control solution and blood.
The control results are not displayed in memory.
The control solution can stain fabric. Remove stains by washing with soap and water.
Chapter 2: Control Tests
52107_07111223001_EN.indb 13 4/2/15 9:22 AM
14
Control Tests
2
Performing a Control Test
You need the meter, a test strip, and control solution Level 1 or Level 2.
Check the use by date on the
test strip container. Do not use
test strips past the use by date.
1
Insert the test strip into the
meter in the direction of the
arrows. Place the meter on a flat
surface.
The meter turns on. Preparing
to test appears.
Apply drop appears.
2
52107_07111223001_EN.indb 14 4/2/15 9:22 AM
15
Control Tests
2
Select the control solution to
test. You will enter the level later
in the test.
3
Remove the bottle cap. Wipe the
tip of the bottle with a tissue.
Squeeze the bottle until a tiny
drop forms at the tip.
4
Touch the drop to the front
edge of the yellow window of
the test strip. Do not put control
solution on top of the test strip.
Analyzing appears when there
is enough control solution in the
test strip.
5
52107_07111223001_EN.indb 15 4/2/15 9:22 AM
16
Control Tests
2
Control Result and the control
bottle icon appear.
Press
or to select the
control level you tested. If you
do not select a level, the control
level is saved as – –.
If any other action is taken at
this time, the control result is
saved with no control level.
6
Press .
and Within range appear if
the control result is within range.
and Out of range appear if
the control result is out of range.
7
52107_07111223001_EN.indb 16 4/2/15 9:22 AM
17
Control Tests
2
Wipe the tip of the bottle with a
tissue. Cap the bottle tightly.
8
Remove and discard the used
test strip.
9
NOTE
The meter turns o 90seconds after a successful test or 15seconds after the test strip is removed,
provided no other action is taken.
52107_07111223001_EN.indb 17 4/2/15 9:22 AM
18
Control Tests
2
Understanding Out‑of‑Range Control Results
wWARNING
The control ranges are printed on the test strip container label. If the control result is out of range, check this
list to help solve the problem.
Troubleshooting Checks Action
Were the test strips or control solutions expired? Discard the test strips or control solution if either is
past the use by date. If the control solution was
opened more than 3months ago, discard it. Repeat
the control test with an unexpired test strip and an
unexpired control solution.
Did you wipe the tip of the control solution bottle
before use?
Wipe the tip of the bottle with a tissue. Repeat the
control test with a new test strip and a fresh drop of
control solution.
Were the caps on the test strip container and the
control solution bottle always closed tightly?
Replace the test strips or control solution if you think
either was uncapped for some time. Repeat the
control test.
Was the test strip used immediately after it was
removed from the test strip container?
Repeat the control test with a new test strip and a
fresh drop of control solution.
Were the test strips and control solutions stored
in a cool, dry place?
Repeat the control test with a properly stored test
strip or control solution.
Did you follow the directions? Read the chapter Control Tests and repeat the
control test.
Did you choose the correct control solution level,
either 1 or 2, when you performed the control
test?
If you chose the wrong control solution level, you can
still compare the control result to the range printed
on the test strip container.
Are you still unsure of the problem? Contact Accu‑Chek Customer Care at
1
‑800‑363‑7949.
52107_07111223001_EN.indb 18 4/2/15 9:22 AM
  • Page 1 1
  • Page 2 2
  • Page 3 3
  • Page 4 4
  • Page 5 5
  • Page 6 6
  • Page 7 7
  • Page 8 8
  • Page 9 9
  • Page 10 10
  • Page 11 11
  • Page 12 12
  • Page 13 13
  • Page 14 14
  • Page 15 15
  • Page 16 16
  • Page 17 17
  • Page 18 18
  • Page 19 19
  • Page 20 20
  • Page 21 21
  • Page 22 22
  • Page 23 23
  • Page 24 24
  • Page 25 25
  • Page 26 26
  • Page 27 27
  • Page 28 28
  • Page 29 29
  • Page 30 30
  • Page 31 31
  • Page 32 32
  • Page 33 33
  • Page 34 34
  • Page 35 35
  • Page 36 36
  • Page 37 37
  • Page 38 38
  • Page 39 39
  • Page 40 40
  • Page 41 41
  • Page 42 42
  • Page 43 43
  • Page 44 44
  • Page 45 45
  • Page 46 46
  • Page 47 47
  • Page 48 48
  • Page 49 49
  • Page 50 50
  • Page 51 51
  • Page 52 52
  • Page 53 53
  • Page 54 54
  • Page 55 55
  • Page 56 56
  • Page 57 57
  • Page 58 58
  • Page 59 59
  • Page 60 60
  • Page 61 61
  • Page 62 62
  • Page 63 63
  • Page 64 64
  • Page 65 65
  • Page 66 66
  • Page 67 67
  • Page 68 68
  • Page 69 69
  • Page 70 70
  • Page 71 71
  • Page 72 72
  • Page 73 73
  • Page 74 74
  • Page 75 75
  • Page 76 76
  • Page 77 77
  • Page 78 78
  • Page 79 79
  • Page 80 80
  • Page 81 81
  • Page 82 82
  • Page 83 83
  • Page 84 84
  • Page 85 85
  • Page 86 86
  • Page 87 87
  • Page 88 88
  • Page 89 89
  • Page 90 90
  • Page 91 91
  • Page 92 92
  • Page 93 93
  • Page 94 94
  • Page 95 95
  • Page 96 96
  • Page 97 97
  • Page 98 98
  • Page 99 99
  • Page 100 100
  • Page 101 101
  • Page 102 102
  • Page 103 103
  • Page 104 104
  • Page 105 105
  • Page 106 106
  • Page 107 107
  • Page 108 108
  • Page 109 109
  • Page 110 110
  • Page 111 111
  • Page 112 112
  • Page 113 113
  • Page 114 114
  • Page 115 115
  • Page 116 116
  • Page 117 117
  • Page 118 118
  • Page 119 119
  • Page 120 120
  • Page 121 121
  • Page 122 122
  • Page 123 123
  • Page 124 124
  • Page 125 125
  • Page 126 126
  • Page 127 127
  • Page 128 128
  • Page 129 129
  • Page 130 130
  • Page 131 131
  • Page 132 132
  • Page 133 133
  • Page 134 134
  • Page 135 135
  • Page 136 136
  • Page 137 137
  • Page 138 138
  • Page 139 139
  • Page 140 140
  • Page 141 141
  • Page 142 142
  • Page 143 143
  • Page 144 144
  • Page 145 145
  • Page 146 146
  • Page 147 147
  • Page 148 148
  • Page 149 149
  • Page 150 150
  • Page 151 151
  • Page 152 152
  • Page 153 153
  • Page 154 154
  • Page 155 155
  • Page 156 156
  • Page 157 157
  • Page 158 158
  • Page 159 159
  • Page 160 160
  • Page 161 161
  • Page 162 162
  • Page 163 163
  • Page 164 164
  • Page 165 165
  • Page 166 166
  • Page 167 167
  • Page 168 168
  • Page 169 169
  • Page 170 170
  • Page 171 171
  • Page 172 172
  • Page 173 173
  • Page 174 174
  • Page 175 175
  • Page 176 176
  • Page 177 177
  • Page 178 178
  • Page 179 179
  • Page 180 180
  • Page 181 181
  • Page 182 182
  • Page 183 183
  • Page 184 184
  • Page 185 185
  • Page 186 186
  • Page 187 187
  • Page 188 188
  • Page 189 189
  • Page 190 190
  • Page 191 191
  • Page 192 192
  • Page 193 193
  • Page 194 194
  • Page 195 195
  • Page 196 196

ACCU-CHECK Aviva Combo Manuel utilisateur

Taper
Manuel utilisateur

dans d''autres langues
